5-11 Onboard Indicators

LAN1/LAN2 LEDs

The Ethernet ports (located beside
the VGA port) have two LEDs. On
each Gb LAN port, the yellow (right)
LED indicates activity while the left
LED may be green, orange or off to
indicate the speed of the connection.
See the table on the right for the func-
tions associated with the left (activity
speed) LED.

SATA Activity LEDs

When illuminated, the DP1, DP2,
DP3 and DP4 LEDs indicate activity
on SATA channels SATA3, SATA2,
SATA1 and SATA0, respectively
Chapter 5: Advanced Motherboard Setup
LAN LED
(Connection Speed Indicator)
LED Color
Off
Green
Amber
SATA Activity LEDs
(DP1-DP3)
State System Status
On SATA channel active
Off SATA channel inactive
5-21
Defi nition
10 MHz
100 MHz
1 GHz
