Onboard Speaker Enable/
Disable
The JD1 header allows you to use
either an external speaker or the
internal (onboard) speaker. To use
the internal (onboard) speaker, close
pins 6 and 7 with a jumper. To use an
external speaker, connect the speaker
wires to pins 4 through 7 of JD1. See
the table on the right for settings and
the table associated with the Power
LED/Speaker connection (previous
section) for pin defi nitions.

PCI-X Slot Speed

Jumpers JPXA1 can be used to change
the speed of PCI-X slot #6. See the
table on the right for jumper settings.

VGA Enable/Disable

JPG1 allows you to enable or disable
the VGA port. The default position is
on pins 1 and 2 to enable VGA. See
the table on the right for jumper set-
tings.

LAN Enable/Disable

Change the setting of jumper JPL to
enable or disable the LAN1 and LAN2
Gb Ethernet ports. See the table on
the right for jumper settings.
default setting is enabled.
Chapter 5: Advanced Motherboard Setup

Onboard Speaker Enable/Disable

Pin Defi nitions (JD1)
Pins Defi nition
6-7 Jump for onboard speaker
4-7 Attach external speaker wires
PCI-X Slot Speed Jumper Settings
Jumper Setting
Open
Pins 1-2
Pins 2-3
VGA Enable/Disable
Jumper Settings (JPG1)
Jumper Setting
Pins 1-2
Pins 2-3
JLAN1/2 Enable/Disable
Jumper Settings (JPL)
Jumper Setting
Pins 1-2
The Pins 2-3
5-19
(JPXA1)
Defi nition
Auto
PCI-X 66 MHz
PCI 66 MHz
Defi nition
Enabled
Disabled
Defi nition
Enabled
Disabled
