SpectraLink NetLink e340 Configuration And Administration Manual page 44

SpectraLink Corporation
Message Description
No IP Address Invalid IP.
No Net Access Cannot authenticate / associate with AP.
No Net Found This indicates the handset cannot find
any access points due to:
No radio link.
No ESSID – Auto-learn not supported (or)
Incorrect ESSID.
AP does not support appropriate data
rates.
Out of range.
Incorrect Security settings.
No Net Found x...x = AP MAC address
xxxxxxxxxxxx yy yy = AP signal strength
Handset cannot find a suitable access
point; displays MAC and signal strength
of "best" non-suitable AP found.
No Reg Domain Regulatory Domain not set.
No PBX No communication with host telephone
system.
No SW found A required software component has not
been identified.
Server Busy Handset is attempting to download from
a Download Master that is busy
downloading other handsets and refusing
additional downloads.
SKT Open Failed Socket open fail. Occurs when the
handset tries to connect to the PBX but
there is no response. If resiliency is
active, the handset will keep trying.
PN: 72-1065-09-H.doc
Configuration and Administration–NetLink e340,/h340/ i640 Wireless Telephone
NetLink Telephony Gateway and SpectraLink Radio Protocol
Action
Check the IP address of the handset and re-
configure if required.
Verify the AP configuration.
Verify that all the WEP settings in the handset
match those in the APs.
Verify that the AP is turned on.
Verify the ESSID of the wireless LAN and enter
or Auto-learn it again if required. See
Wireless Telephone Configuration
Check the AP configuration against
Configuration Note
Try getting closer to an AP. Check to see if
other handsets are working within the same
range of an AP. If so, check the ESSID of this
handset.
Verify that all the security settings in the WT
match those in the APs.
Check AP and handset network settings such
as ESSID, Security, Reg domain and Tx power.
Ensure APs are configured per
Note
Try Site Survey mode to determine more
specific cause.
Configure the Regulatory Domain of the
handset.
Displays before the system has synchronized
ports with the host telephone system. Should
disappear when the ports are correctly wired
and programmed.
Make sure the proper PBX switch has been
selected within the NetLink Telephony
Gateway.
Check that the correct software has been
downloaded and is available.
None. The handset will automatically retry the
download every few seconds.
If the PBX is inoperative and resiliency is not
active or the handset cannot locate a backup
PBX, turn off the handset and repair the
primary PBX. Note that it may be advisable to
reconfigure the backup PBX to be the primary
PBX if the repair is more time-consuming than
the reconfiguration.
for AP.
Configuration
.
NetLink
.
section
Page 44
