SpectraLink Corporation
Phone Config
License Option
License Option lets you select the VoIP protocol that your site is licensed to
download and run. The SpectraLink Radio Protocol (SRP) used for the NetLink
e340/h340/i640 Wireless Telephones in a NetLink Telephony Gateway system
requires License Option Selection
malfunction.
Push-to-talk
All eight push-to-talk channels are allowed by default. To toggle the allowed status of
any channel, select
press the
Select
column. Only those channels allowed in the Admin menu will appear on the Standby
menu where they can be enabled or disabled by the end user. To disallow push-to-
talk entirely, select
Admin Password
The Admin Password controls access to the administration functions in the Admin
menu. The password must be set in each handset for which controlled access is
desired. Handsets are shipped without any Admin menu password. Data entry for
the password uses the alphanumeric string entry technique. Type the password and
press the
Save
and press the
Save
set.
If you
require it before displaying the Admin menu.
Network Config
IP Address
There are two modes in which the handset can operate: DHCP enabled or Static IP.
Select the mode for operation from the IP Address menu:
* Use DHCP
Address each time the handset is turned on. If DHCP is enabled, the handset
also receives all other IP Address configurations from the DHCP server.
Allows you to manually set a fixed IP Address. If selected, the handset
Static IP
will prompt for the IP Addresses of each configurable network component.
When entering addresses, enter the digits only, including leading zeroes. No
periods are required.
Regardless of the mode in which the handset is operating, the following
components must be configured:
Phone IP
The IP Address of the handset. This is automatically assigned if
DHCP is used. If using Static IP configuration, you must obtain a unique IP
Address for each handset from your network administrator.
Default Gateway and Subnet Mask
complex network which includes routers. Both of these must be configured
either with an IP address under Static IP (not set to 000.000.000.000 or
255.255.255.255) or with DHCP for the handset to contact any network
PN: 72-1065-09-H.doc
Configuration and Administration–NetLink e340,/h340/ i640 Wireless Telephone
007
Allowed Channels
, scroll to the channel to be disallowed and
side button. Allowed channels are displayed with an
Allow
/
Disallow
, scroll to and select
softkey. A confirmation prompt will appear. Type the password again
softkey. If the passwords match, the Admin password has been
with no entry, the password is erased and the display will not
Save
Will use Dynamic Host Configuration Protocol to assign an IP
NetLink Telephony Gateway and SpectraLink Radio Protocol
. Any other protocol will cause the handset to
Disallow PTT
Used to identify subnets, when using a
in the left
*
.
Page 16
