2.8

Handset Displays

Status display
Displays information from the PBX in two lines of text and displays available
softkeys in the softkey display area. The PBX text may be truncated as some PBXs
send 24 characters and the handset display area is 16 characters.
LINE display
Most, but not all, PBXs allow for more than one line appearance. The line
appearances are mapped to corresponding line icons across the top of the handset
display.
display
MENU
Most, but not all, PBXs have expanded features that are programmed to the softkeys
on the handset. Pressing the
features that have been programmed to the softkeys and their shortcut. OAI
features, if assigned, will also be displayed with their shortcuts. If configured,
pressing
MENU
display
FCN
The FCN key is used to scroll through the softkey display area. Pressing the
will display the next level of programmed softkeys. Pressing it repeatedly will scroll
through all four levels, or as many levels as have been programmed.
PN: 72-1065-09-H.doc
Configuration and Administration–NetLink e340,/h340/ i640 Wireless Telephone
MENU key from the active state displays the full list of
in an active state will display the diagnostic menus.
NetLink Telephony Gateway and SpectraLink Radio Protocol
FCN key
