1.2
Package Contents
Table 1-3 Package Contents
Item
RG-AP820-I Access Point
Mounting Bracket
Wall Anchor
Phillips Pan Head Screws M4 x 20
Warranty Card
Installation Guide
1.3
Technical Specifications
1.3.1
Size and Weight
Table 1-4 Size and Weight
Item
Main Unit
Dimensions
(W x D x H)
Weight
Anti-theft lock hole
2.5G SFP port
Reset button
Console port
1000 BASE-T Ethernet port
DC power plug
Parameter
220 mm × 220 mm × 49 mm (8.66 in. x 8.66 in. x 1.93 in.)
Main Unit: 1.0 kg (2.20 lbs.)
Bracket: 0.2 kg (0.44 lbs.)
Connect to the anti-theft lock.
The
uplink
SFP
transmission.
Reboot the device or restore the device to factory
settings.
Connect to the device that is managed with the
serial cable.
The uplink adaptive Ethernet port for service data
transmission.
Support IEEE 802.3af standard PoE power
supply.
Connect to the DC power adapter to supply
power to the AP.
Quantity
1
1
2
4
1
1
3
Product Overview
port
for
service
data
