filter can handle. If you exceed these limits, filter the air in the room in
which the library is housed.
Particle Size
(microns)
0.1
0.5
5.0

Unpacking the Spectra 12000 Library

Use the Spectra 12000 Installation and Unpacking Guide, P.N. 90910884
to unpack and install the library.
Caution: The Spectra 12000 library is heavy. Use extreme
caution when unpacking and lifting the library. You will
need more than two people to position the library.
The Spectra 12000 library is shipped with the following items:
Š
Spectra 12000 Installation and Unpacking Guide
Š
Release Notes: Spectra 12000, Spectra 64000.
Š
Spectra 12000 Library User Guide (this guide).
Š
15-slot cartridge pack, with cover.
Š
AC power cord.
Š
Front panel filter element.
Š
One or two Quad Interface Processors (QIPs) already installed for
Fibre Channel, SCSI, Ethernet, or some combination; with two SCSI
terminators per S-QIP or L-QIP.
Š
Optionally, up to eight drive sleds ordered with this library. Drives
are boxed separately and shipped in the crate with the Spectra 12000
library. See Adding Drives on page 144 for more information.
Number of Particles
Particle Size per Cubic Meter
7
8.8 x 10
7
3.5 x 10
5
2.5 x 10
Chapter 2. Installing the Spectra 12000 Library 31
Number of Particles
Particle Size per Cubic Foot
6
2.5 x 10
6
1.0 x 10
3
7.0 x 10
