EVAL-M7-D112T user guide
iMOTION™ evaluation board for smart driver
The board at a glance
1.3

Main features

EVAL-M7-D112T is an evaluation board with Infineon's smart driver, IMD112T. This board is suitable for PMSM or
BLDC motor control for home appliances, fans, pumps, and so on, and for applications that require PFC.
The main features of the IMD112T smart driver are as follows:
Motor controller with integrated high-voltage gate driver and voltage regulator
•
Integrated 5 V low dropout regulator (LDO) that allows single 15 V supply voltage input
•
Robust 600 V gate driver with thin-film silicon-on-insulator (SOI) technology
•
Gate driver integrated with ultra-fast bootstrap diodes
•
Space saving LQFP-40pin package with high-voltage creepage
•
Motion control engine (MCE) as ready-to-use solution for variable speed drives
•
Sensor less field oriented control (FOC) for permanent magnet synchronous motor
•
Flexible space vector PWM (3-phase or 2-phase)
•
Motor current sensing via single or leg shunt
•
Optional analog or digital Hall sensor interface
•
Flexible host interface options for motor control commands — Universal asynchronous receiver/transmitter
•
(UART), frequency/duty cycle, or analog variable speed control (VSP)
Boost PFC control
•
The main features of the EVAL-M7-D112T evaluation board are as follows:
Debug included onboard
•
iMOTION Link connector as an optional communication interface
TM
•
Single-shunt current feedback configuration for the inverter
•
Boost PFC configuration
•
Optional VSP or duty/frequency control
•
51 mm x 70 mm PCB with two layers and 1 oz copper
•
1.4

Board parameters and technical data

Table 2 lists the parameters and technical data of the evaluation board.
Board specification
Table 2
Parameter
15 V input voltage
5 V output voltage
Communication
Mini USB
iMOTION Link
TM
connector
PCB characteristics
Material
dimension
Symbol Conditions
+15V Maximum 25 mA current for controller
+5V Maximum 10 mA output for external devices 5±4%
X101 On board debug incorporated
J3 iMOTION
TM
be used
1.6 mm thickness, 1 oz copper, 2 layers
Length × width × height
Link isolated debug probe must
7
Value Unit
15±5% V
V
UART0
UART0
FR4
77 × 51 × 14 mm
