EVAL-M1-IM535 user guide
iMOTION™ modular application design kit
The board at a glance
1.3

Main features

The EVAL-M1-IM535 is an evaluation board for motor drive applications. Combined in a kit with one of the
available MADK control board options, it demonstrates Infineon's motion control IC and IPM technology for
motor drives.
The evaluation board characteristics include:
• Input voltage 85~265 V
• Maximum 20 A input and output current
• Maximum 3000 W motor power output
• On board EMI filter
• Current sensing operational amplifier (OPA) with single shunt
• Auxiliary power supply with 15 V, 5 V
• Overcurrent hardware protection & over temperature protection
• Sensing of DC-link voltage
• Thermistor output
• PCB is 166 mm × 166 mm, two layers with 2 oz. copper
• RoHS compliant
1.4

Board parameters and technical data

Table 2 depicts the important specifications of the evaluation board EVAL-M1-IM535.
Table 2 EVAL-M1-IM535 board specifications
Parameter
Input voltage
Maximum input current
Maximum input power
Maximum motor
current
Maximum DC bus
voltage
Minimum DC bus
voltage
Shunt Resistance
Protections
Motor current
protection trigger level
1
For iMOTION™ IC IMCxxx, there are three types of Gatekill input source options in MCEWizard setup: Gatekill-pin, Comparator and
1
Both. If you select "comparator" mode, the external Gatekill signal will be not used, and the signal I_Shunt will be compared by the
internal comparator with the "Device overcurrent trigger level setting" value set in MCEWizard.
AC
Symbol Conditions / comments
V Optimized design for 220 V
ac
Lower AC input, less motor power output
I
Input 220 V
ac(max)
P Input 220 V
in(max)
Force cooling mode
I Input 220 V
mtr(max)
Force cooling mode
V DC bus capacitors are 400 V, 820µFX4
dc(max)
(or 1000µF X4)
V Aux power supply brown-in voltage
dc(min)
R Two 5 mΩ in parallel, with external OPA gain 10
sh
I Wizard setup for OC trigger level, related to shunt
trip
resistor RS1 & RS2 and current sensing bias
application
AC
, T =25C
AC a
, f = 6 kHz, T =25° C, T
PWM
AC a
, f =5 kHz, T =25° C, T
PWM
AC a
7 of 39
Value
85 ~ 265
20
= 105° C 3000
case
= 105° C 20
case
400
80
2.5
30
1
Unit
V
rms
A
rms
W
A
rms
V
V
mΩ
A
peak
V1.0
2020-09-30
