This section contains general information and detailed specifications of the mBOX600. Section
1 includes the following sub-sections:
◼

General Descriptions

◼ System Specifications
◼ Dimensions
◼ I/O Outlets
◼ Packing List
Please take a few moments to review the contents of this document to ensure that the setup
and startup proceed smoothly. The Medical-Grade System is ready for use, out of the box, in
its default configuration when powered by the power source provided. The following
documentation offers guidance on the hardware elements and features of the computer. Please
refer to your device provider for information pertaining to the software operating system or
software applications.
1.1 General Descriptions
The mBOX600 is powered by the high-performance 9th/8th Intel
processor, COM Express
The system offers two RS-232/422/485, four USB 3.1 Gen 2 ports, two Gigabit Ethernet ports,
two DisplayPort output, one HDMI output and one LED power status light. Moreover, it's
equipped with one M.2 2280 Key M slot for NVMe SSD, one swappable 2.5'' SATAIII SSD with
security lock, one PCIe x16 slot for expansion use, and one screw-type 12V-24VDC power input
connector.

Introduction

® structure.
mBOX600 User's Manual
Section 1
Introduction
® Core™ i7/i5/i3 & Celeron ®
