Summary of Contents for AXIOMTEK mBOX100
- Page 1 Medical Embedded System User’s Manual...
-
Page 2: Disclaimers
Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd. -
Page 3: Safety Precautions
Safety Precautions Before getting started, please read the following important safety precautions. The mBOX100 does not come with an operating system which must be loaded first before installation of any software into the computer. Use a wrist grounding strap and place all electronic components in any static-shielded devices. -
Page 4: Explanation Of Graphical Symbols
13. Environmental Conditions 0 ºC to +40 ºC Temperature (C) Operation Relative Humidity (%) 10 to 90%RH Atmospheric Pressure (kPa) 106 to 80 kPa 0°C to +40°C Temperature (C) Storage / Transportation Relative Humidity (%) 10 to 90%RH Atmospheric Pressure (kPa) 106 to 80 kPa 14. - Page 5 CAUTION: Medical electrical equipment needs special precautions regarding electromagnetic compatibility (EMC) and needs to be installed and put into service according to the EMC information in the XXX sections of this document. Portable and mobile RF communications equipment can affect medical electrical equipment. Classifications Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.
-
Page 6: General Cleaning Tips
General Cleaning Tips Please keep the following precautions in mind while understanding the details fully before and during any cleaning of the computer and any components within. A piece of dry cloth is ideal to clean the device. Be cautious of any tiny removable components when using a vacuum cleaner by the system. -
Page 7: Scrap Computer Recycling
Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. -
Page 8: Table Of Contents
Quick Start ................... 7 COM Ports Setup ................. 7 2.2.1 COM Ports Pin Definition ................7 2.2.2 COM Ports Mode Selection ................. 7 Section 3 mBOX100 Medical Computer Cleaning and Disinfecting ..............9 mBOX100 Medical Computer Cleaning and Disinfecting ....9 viii... -
Page 9: Introduction
User’s Manual Section 1 Introduction This section contains general information and detailed specifications of the mBOX100. Section 1 includes the following sub-sections: ◼ General Descriptions ◼ System Specifications ◼ Dimensions ◼ I/O Outlets ◼ Packing List Please take a few moments to review the contents of this document to ensure that the setup and startup proceed smoothly. -
Page 10: System Specifications
DisplayPort, one HDMI port, two GbE LAN ports, one Mic-in and one Line-out. Embedded O.S. Supported The mBOX100 supports Windows and Linux. ® Easy maintain storage Supported The mBOX100 supports one SATA SSD and one M.2 NVMe SSD slot. System Specifications 1.2.1 ⚫ ◼ Intel® 8th Gen Core™ i7/i5/i3 & Celeron® processor ⚫... -
Page 11: I/O System
User’s Manual 1.2.2 I/O System ⚫ Display ◼ One DisplayPort supports DP 1.2. The DP resolution is up to 3840x2160 @60Hz. ◼ One HDMI support HDMI 1.4a. The HDMI resolution is up to 3840x2160 @30Hz. ⚫ Ethernet ◼ Two 1000/100/10 Ethernet ports (i210-AT, i219-LM) ®... -
Page 12: System Specification
3 kg (6.61 lb) without package ⚫ Dimensions ◼ 250 mm (9.84") x 220 mm (8.66") x 60 mm (2.36") 1.2.4 Driver CD Content Please download system drivers and user’s manual from Axiomtek website. ⚫ Chipset ⚫ Ethernet ⚫ Graphic ®... -
Page 13: Dimensions
User’s Manual Dimensions The following diagrams show dimensions and outlines of the mBOX100. I/O Outlets The following figures show I/O outlets on the mBOX100. Introduction... -
Page 14: Packing List
User’s Manual Packing List The mBOX100 comes with the following bundle package: ⚫ mBOX100 system unit x1 ⚫ Medical grade 65W adapter x1 (FSP Technology Inc.- FSP065M-DAA3) ⚫ Power cord x1 Grounding reliability can only be achieved when the equipment is connected to an equivalent receptacle marked “Hospital Only”... -
Page 15: System Setup
User’s Manual Section 2 System Setup Quick Start Connect the adapter to the “DC Input Jack”. Please note that using a non-genuine adapter may pose a potential risk to the system. Press “Power On/Off”. The button will turn white. - Page 16 User’s Manual This page is intentionally left blank. System Setup...
-
Page 17: Section 3 Mbox100 Medical Computer Cleaning And Disinfecting
Medical Computer Cleaning and Disinfecting mBOX100 Medical Computer Cleaning and Disinfecting During normal use of the mBOX100, the device may become dirty and should be regularly cleaned. Steps: Prepare cleaning fluid as below list. Wipe the mBOX100 with a clean antistatic cloth that has been moistened in the cleaning solution.
