NOTE
Figure 2-44
Figure 2-45
Opening Your Personal Workstation and Installing Accessories
Removable Media Devices
3. Attach the guide rails to both sides of the floppy disk drive. See
Figure 2-44 and Figure 2-45.
The Floppy disk drive guide rails are color coded green. They are located
on the chassis of the CD drive bay area.
Floppy Disk Drive and Guide Rails
Guide Rail
Attaching the Guide Rails to the Floppy Disk Drive
Guide Rail
Pin
Guide Rail
90
Floppy Disk
Drive Top
Guide Rail
Floppy Disk
Drive Front
Floppy Disk
Drive Top
Floppy Disk
Drive Front
Ejector Tab
(on both sides)
Chapter 2
