Opening Your Personal Workstation and Installing Accessories
Installing and Removing a Voltage Regulator Module (VRM)
3. Push downward on the VRM connector's ejector tabs. See Figure 2-90.
Figure 2-90 Ejector Tabs in the Downward Position
130
Note that the arrow points to the top inside of the Personal
Workstation.
Top
Ejector Tab
Voltage
Regulator
Module (VRM)
Chapter 2
