Crystal socket Q1 schematics below:
Trace port
The superset microcontroller device being used on the Emulation Adapter features Slow and Fast
trace signals. Slow trace signals are connected to ARM Mictor 38 and ARM CoreSight 20 target
connectors provided by the Emulation Adapter. Fast trace signals share microcontroller I/O ports
with other peripheral functionalities, and for this reason, they are connected towards the target for
the user to use them according to their target application configuration and usage.
List of used microcontroller ports:
TRACECLK - PTG6
·
TRACEDATA[0] - PTG7
·
TRACEDATA[1] - PTG15
·
TRACEDATA[2] - PTG16
·
TRACEDATA[3] - PTF31
·
TRACEDATA[4] - PTG17
·
winIDEA configuration
By running the New Workspace Configuration
be configured. In the Wizard, select
P2: Power supply configuration
The power supply of the Emulation Adapter is configured via the unshrouded 26-pin 2.54 mm
header (P2).
Signal direction
Target board
Target board
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Ground
Ground
Ground
Signal Direction is described from the BlueBox perspective.
TRACEDATA[5] - PTF28
·
TRACEDATA[6] - PTG18
·
TRACEDATA[7] - PTG19
·
TRACEDATA[8] - PTG20
·
TRACEDATA[9] - PTG21
·
TRACEDATA[10] - PTG22
·
iSYSTEM S32K344 Emulation
Signal
TVDD_HV_A
TVDD_HV_B
TVREFH
NC
NC
NC
NC
NC
NC
NC
GND
GND
GND
Wizard, the correct emulation adapter trace port will
Pin Pin
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
P2 Signal description
TRACEDATA[11] - PTG23
·
TRACEDATA[12] - PTG24
·
TRACEDATA[13] - PTG25
·
TRACEDATA[14] - PTG26
·
TRACEDATA[15] - PTG27
·
Adapter.
Signal Signal direction
VDD_HV_A Emulation device
VDD_HV_B Emulation device
VREFH
NC
NC
NC
NC
NC
NC
NC
GND
GND
KEY
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Ground
Ground
