TASKING iSYSTEM NXP S32K344 User Manual page 13

The Power converter can supply either 3.3 V or 5 V. The array of jumpers J0–J9 selects 3.3 V or 5 V
voltage on the P3 connector, which connects to the Emulation Adapter.
Signal
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
GND
GND
GND
For example, when J2 is in the 3V3 position, it supplies 3.3 V to pin 6 of the P3 connector. When J2
is in the 5V position, it supplies 5 V to pin 6 of the P3 connector pin.
Be careful not to supply 5 V to the microcontroller power supply pin, which has declared a
maximum voltage 3.3 V! Refer to the microcontroller documentation for detailed information
on power supply.
External power supply requirements:
Min Voltage
8 V
Clock source
If the target's crystal circuit microcontroller oscillator (if available) is not an adequate clock source,
insert the appropriate crystal into the Q1 socket, replace the default 22pF C1 and C2 capacitors
when necessary, and DIP switch DIP2 to position away from the white dot.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
P3 connector and J0–J9 jumper correlation table
P3 connector on the Power Supply board
Max Voltage
12 V
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
Min Power
5 W
Signal
J0
J1
J2
J3
J4
J5
J6
J7
J8
J9
GND
GND
KEY
