・Explanation
Send back the set speed. The speed setting range is 1~48.

Chapter 4 Specifications

10. Specifications
(1) General Specifications
Power supply DC6V
voltage
AC Adapter
AC100～240V±10％ （ 50／60Hz ）
Apparent power 30VA
Operating
5～40℃
temperature
Storage
－20～60℃
temperature
Ambient humidity20~80%RH (non-condensing)
External (W)82×(D)100×(H)24mm (excluding protrusions)
dimensions
mass
0.15kg
(2) Performance
Specifications
Number of 1-axis
control axes
Fine motion knob life 15,000 revolutions
Interface USB Interface
Communication Parameters
・Baud rate
・Data bits
・Parity
・Stop bit
・Flow control
・Delimiter

11. Connector Pin Assignment

11-1. MOTOR CONNECTOR
number
1
2
Connector
excluding
( the weight of AC adapter and cables)
38400bps
8bit
without
1bit
without
CR+LF
name number
3
Motor ＋
4
Motor ＋
TCS7147-012177 (equivalent to Hosiden Corporation)
19
name
Motor －
Motor －
