Chapter 2: Jumpers and Connectors
BMC Debug Header
Connector type: 1x2 2-pin header
Connector location: JP10
1
2
Pin
Definition
1
BMC_COM_SW_N
2
GND
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
USB 2.0 Connectors
Connector type: 1x6 6-pin header
Connector location: CN7
6
1
6
1
Pin
Definition
1
P5V_USB_P34
3
USB2P3_C
5
USB2P4_C
10
Pin
Definition
2
USB2N3_C
4
USB2N4_C
6
GND
NSA 7146 User Manual
