Chapter 2: Jumpers and Connectors
Jumper
RTC Clear
Connector type: 1x3 3-pin header
Connector location: JP8
1
3
Pin
Function
1-2 On
Normal
2-3 On
Clear CMOS
1-2 On: default
Pin
Definition
1
NC
2
RST_RTCRST_N
3
GND
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
8
NSA 7146 User Manual
