18
PostBase Vision
Feeder plus – rear view
Tray with sponge
Catches (lugs) for coupling
with the postage meter housing
FP. "PostBase Vision User Manual (Full Reference Guide)." PostBase Vision Support Semi-Auto, Auto & Advanced, Apr. 2020,
download.fp-usa.com/product_docs/PostBase/Vision/Technical/PostBase_Vision_Reference_Guide_USA_Rev02_20200423.pdf.
Ramp connection
Power connection
Termination plug (plugged in the factory)
CAN BUS (connection to
postage meter)
Works Cited:
Connection cable
