172 PostBase Vision
17.5 Correcting the moistening felt position on the rocker
(Sealer)
Hold leg spring
in place!
Moistening felt correctly
positioned:
Projection 0.04 - 0.08"
(1 - 2 mm)
FP. "PostBase Vision User Manual (Full Reference Guide)." PostBase Vision Support Semi-Auto, Auto & Advanced, Apr. 2020,
download.fp-usa.com/product_docs/PostBase/Vision/Technical/PostBase_Vision_Reference_Guide_USA_Rev02_20200423.pdf.
Rocker with moistening felt
Moistening felt
Aligned with
stop edge
• Slightly tilt the rocker and pull it off in an
obliquely upward direction.
Caution! Always hold the leg spring on the
pin with one hand while positioning the moist-
ening felt. This will prevent the leg spring
from jamming or jumping out.
• Push the long moistening felt side fully
underneath the clamping strip such that
– the felt's recesses are perfectly aligned
with the rocker stop edge and
– both moistening felt outer edges uni-
formly project over the rocker edge by
approximately 0.04 - 0.08" (1 - 2 mm).
See illustration.
• Carefully displace the moistening felt in the
clamping strip if necessary.
• Reattach the rocker on the sealer
(see page 157).
