Type 12 - Directed VW10 Installation Manual

Type 12

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 33 for important information on this installation.
37
16 73
White VESCM Connector B
(under drivers kick)
FT CAN Low:
Orange/Brown, pin 21
FT CAN High:
Orange/Green, pin 20
1 17 63
Ignition Switch
(black conn. at ignition switch)
(+) Ignition:
Black/Violet, pin 8
8 7 6
10 9
1
5 3
4 2
(+) Starter:
Red/Black, (+) Accessory:
pin 4 Black/Red, pin 3
Black VESCM connector A
(under drivers kick)
16
37 73
(+) 12V:
(MUX) Doorlock:
Red/White or
Blue/Red,pin 24
Red/Yellow, pin 68
(-) Trunk
Release:
(+) Brake:
Violet, pin 23
Black/Red, pin 39
63
1 17
32
HS CAN High: Orange/Black, pin 6
1
9
HS CAN Low: Orange/Brown, pin 14
(MUX) Lock/Unlock Output: Violet/Brown: 1
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
(+) Starter / Brake Activation Output: White/Red: 12
(+) Ignition Output: Green/Red: 14
Hood Pin
(-) Hood Input: Gray: 3
(-) Trunk Release Output: Red/White: 9
(+) Siren Output: Brown: 17
Siren
Diagnostic
8
Connector OBDII
16
12: Brown: (+) 12V Input
10: Red: (+) 12V Input
9: Black: (-) Ground
5: Orange/Red: Key Wrap
4: Yellow/Red: Key Wrap
3: Brown/Red: Key Wrap
2 & 8: White/Brown: (+) 12V Input
1 & 7: White: (+) Accessory Output
(+) Parking Lights:
Gray/Red, pin 14
10 14 17
1 9
Parking Light Switch
(black conn. at light switch)
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
VESCM - (under drivers kick)
Connector Connector
A
B
Directed Digital Solutions VW10
© 2017-06-22 Directed. All rights reserved.
