Directed VW10 Installation Manual page 29

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Volkswagen Passat 2006-2011
12V Red/White
Parking Light Gray/Yellow
Parking Light Interrupt Red/White or Red/Black
Starter Red/Gray or Red/Violet
Ignition Red/Violet
FT CAN High Orange/Green
FT CAN Low Orange/Brown
Keysense Green
12V Interrupt Green/Red
Brake Black/Red
HS CAN High Orange/Black
HS CAN Low Orange/Brown
Volkswagen Passat CC 2008-2010
12V Red/White
Parking Light Gray/Yellow
Parking Light Interrupt Red/White or Red/Black
Starter Red/Gray or Red/Violet
Ignition Red/Violet
FT CAN High Orange/Green
FT CAN Low Orange/Brown
Keysense Green
12V Interrupt Green/Red
Brake Black/Red
HS CAN High Orange/Black
HS CAN Low Orange/Brown
29
Pin Polarity Location
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
16 (+) Keyport switch.
3 (+) Keyport switch.
2 (+) VESCM connector E, under drivers dash.
6 Data OBDII.
14 Data OBDII.
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
16 (+) Keyport switch.
3 (+) Keyport switch.
2 (+) VESCM connector E, under drivers dash.
6 Data OBDII.
14 Data OBDII.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions VW10
© 2017-06-22 Directed. All rights reserved.
Pins Ref.
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
16 E
16 F
16 F
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
16 E
16 F
16 F
