Directed VW10 Installation Manual page 20

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Volkswagen Passat CC 2011-2015
Gray/Yellow or Gray/
Parking light
Green
Parking light Interrupt Red/White or Red/Black
Red/Green or Violet/
Ignition
Yellow
Red/Brown or Red/Gray
Starter
or Red/Yellow
Keysense Green or Green/Blue
HS CAN High Orange/Black
HS CAN Low Orange/Brown
12V Red/Yellow
FT CAN High Orange/Green
FT CAN Low Orange/Brown
Brake Black/Red
20
Pin Polarity Location
3 (+) Headlight switch.
8 Cut Headlight switch.
5 (+) Ignition switch port.
6 (+) Ignition switch port.
16 (+) Ignition switch port.
6 Data OBDII.
14 Data OBDII.
42 (+) VESCM connector C, under drivers dash.
15 Data VESCM connector C, under drivers dash.
16 Data VESCM connector C, under drivers dash.
17 (+) VESCM connector C, under drivers dash.
Connector Information
Color
Black
Black
Black
Black
Black
Violet/Black
Violet/Black
Brown
Brown
Brown
Brown
Directed Digital Solutions VW10
© 2017-06-22 Directed. All rights reserved.
Pins Ref.
10 A
10 A
16 B
16 B
16 B
16 C
16 C
52 D
52 D
52 D
52 D
