Type 3; Type 11 - Directed VW10 Installation Manual

Type 3

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 14 for important information on this installation.
37
73
16
White VESCM Connector B
(under drivers kick)
FT CAN Low:
Orange/Brown, pin 21
FT CAN High:
Orange/Green, pin 20
1 17 63
Ignition Switch
(black conn. at ignition switch)
(+) Ignition:
Black/Violet, pin 8
8
10 7 6
9
5 1
3 2
4
(+) Starter:
Red/Black, (+) Accessory:
pin 4 Black/Red, pin 3
Black VESCM connector A
(under drivers kick)
16
37 73
(+) 12V:
(MUX) Doorlock:
Red/White or
Blue/Red,pin 24
Red/Yellow, pin 68
(-) Trunk
Release:
(+) Brake:
Violet, pin 23
Black/Red, pin 39
1 17 63
13
HS CAN High: Orange/Black, pin 6
1
9
HS CAN Low: Orange/Brown, pin 14
(MUX) Lock/Unlock Output: Violet/Brown: 1
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
(+) Starter / Brake Activation Output: White/Red: 12
(+) Ignition Output: Green/Red: 14
Hood Pin
(-) Hood Input: Gray: 3
(-) Trunk Release Output: Red/White: 9
(+) Siren Output: Brown: 17
Siren
CUT
Diagnostic
8
Connector OBDII
16
10 9
5 4
12: Brown: (+) Parking Light Output
11: Orange/Yellow: Parking Light Interupt (conn. side)
10: Red: (+) 12V Input
9: Black: (-) Ground
5: Orange/Red: Key Wrap
4: Yellow/Red: Key Wrap
3: Brown/Red: Key Wrap
2 & 8: White/Brown: (+) 12V Input
1 & 7: White: (+) Accessory Output
Parking Lights Interrupt : Gray/Red or
Red/White, pin 8
8 7 6 Headlight Switch
(black conn. at
1
3 2
light switch)
(+) Parking Lights:
White/Black, pin 1
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
VESCM - (under drivers kick)
Connector Connector
A
B
