Directed VW10 Installation Manual page 9

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Volkswagen EOS 2010-2014
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Ignition Black
Starter Red/Brown or Red/Black
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
12V Red /Yellow
Brake Black/Red
Volkswagen Tiguan 2012-2016
Parking Light Gray/Yellow
Parking Light Interrupt Red/Blue
Ignition Black
Starter Red/White or Red/Black
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
12V Red/Violet
Brake Black/Red
9
Pin Polarity Location
3 (+) Headlight Switch.
8 Cut Headlight Switch.
14 (+) Steering column module.
6 (+) Steering column module.
4 Data Steering column module.
3 Data Steering column module.
6 Data OBDII.
14 Data OBDII.
42 (+) VESCM connector C, under drivers dash.
17 (+) VESCM connector C, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
14 (+) Steering column module behind steering column trim. Black
6 (+) Steering column module behind steering column trim. Black
4 Data Steering column module behind steering column trim. Black
3 Data Steering column module behind steering column trim. Black
6 Data OBDII.
14 Data OBDII.
42 (+) VESCM connector C, under drivers dash.
17 (+) VESCM connector C, under drivers dash.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Violet/Black
Violet/Black
Brown
Brown
Black
Black
Violet/Black
Violet/Black
Brown
Brown
Directed Digital Solutions VW10
© 2017-06-22 Directed. All rights reserved.
Pins Ref.
10 A
10 A
16 B
16 B
16 B
16 B
16 C
16 C
52 D
52 D
10 A
10 A
16 B
16 B
16 B
16 B
16 C
16 C
52 D
52 D
