Wire Information
Function
Color
Volkswagen Golf 2011-2014
Parking Light
White/Black
Parking Light Interrupt
Red/White or Red/Yellow
Ignition
Black
Starter
Red/Black or Red/Brown
FT CAN High
Orange/Green
FT CAN Low
Orange/Brown
HS CAN High
Orange/Black
HS CAN Low
Orange/Brown
12V
Red/White or Red/Yellow
Brake
Black/Red
Volkswagen GTI 2011-2014
Parking Light
White/Black
Parking Light Interrupt
Red/White
Ignition
Black
Starter
Red/Black or Red/Brown
FT CAN High
Orange/Green
FT CAN Low
Orange/Brown
HS CAN High
Orange/Black
HS CAN Low
Orange/Brown
12V
Red/White or Red/Yellow
Brake
Black/Red
Volkswagen Passat 2012-2017
Parking Light
White/Black
Parking Light Interrupt
Red/White or Red/Yellow
Ignition
Black
Starter
Red/Black or Red/Brown
FT CAN High
Orange/Green
FT CAN Low
Orange/Brown
HS CAN High
Orange/Black
HS CAN Low
Orange/Brown
12V
Red/White or Red /Yellow
Brake
Black/Red
12
Pin
Polarity
Location
1
(+)
Headlight Switch.
8
Cut
Headlight Switch.
14
(+)
Steering column module.
6
(+)
Steering column module.
4
Data
Steering column module.
3
Data
Steering column module.
6
Data
OBDII.
14
Data
OBDII.
42
(+)
VESCM connector C, under drivers dash.
17
(+)
VESCM connector C, under drivers dash.
1
(+)
Headlight Switch.
8
Cut
Headlight Switch.
14
(+)
Steering column module.
6
(+)
Steering column module.
4
Data
Steering column module.
3
Data
Steering column module.
6
Data
OBDII.
14
Data
OBDII.
42
(+)
VESCM connector C, under drivers dash.
17
(+)
VESCM connector C, under drivers dash.
1
(+)
Headlight Switch.
8
Cut
Headlight Switch.
14
(+)
Steering column module.
6
(+)
Steering column module.
4
Data
Steering column module.
3
Data
Steering column module.
6
Data
OBDII.
14
Data
OBDII.
42
(+)
VESCM connector C, under drivers dash.
17
(+)
VESCM connector C, under drivers dash.
Connector Information
Color
Black
Black
White
White
White
White
Violet/Black
Violet/Black
Brown
Brown
Black
Black
White
White
White
White
Violet/Black
Violet/Black
Brown
Brown
Black
Black
Black
White
Black
Black
Violet/Black
Violet/Black
Brown
Brown
Directed Digital Solutions VW10
© 2017-06-22 Directed. All rights reserved.
Pins
Ref.
10
A
10
A
16
B
16
B
16
B
16
B
16
C
16
C
52
D
52
D
10
A
10
A
16
B
16
B
16
B
16
B
16
C
16
C
52
D
52
D
10
A
10
A
16
B
16
B
16
B
16
B
16
C
16
C
52
D
52
D
