Type 12 with T-Harness (THTON4)

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 44 for important information on this installation.
Steering Sensor
3 2
5 4
Body ECU
HS CAN 2
Connector
High: Pink, pin 3
RDA: Pink, pin 16
6 5 4
16
18 17 15 14 13
30 29 28 27 26 25
Dash Fuse Box
(white conn.)
36 27
12
35 26
11
34 25
Cut
33 24
10
32
23
9
31 22
SIL:
30 21
8
Blue,
29 20
pin 32
7
28 19
18 6
17 5
16 4
15 3
14 2
13 1
42
1 8
9 16
Diagnostic Connector OBDII
1
HS CAN 2
Low: White, pin 2
(-) Trunk Release Output: Red/White
Body ECU
3 2 1
Connector
12 11 10 9 8 7
(middle connector
left side
23 19
24 22 21 20
of steering column)
(-) Trunk Release: Blue, pin 23
SIL Interrupt (conn. side): Blue/White
Autolight Interrupt (veh. side): Lt. Green
Cut
Autolight Interrupt (conn. side): Lt. Green/White
Autolight: Violet
or Red, pin 19
10 9 8 7 6 5 4 3 2 1
19
20 18 17 16 15 14 13 12 11
Headlight Switch
THTON4
(optional T-Harness)
Refer to the "Vehicle
wiring reference chart"
for more specific T-harness
compatibility.
HS CAN 2 Low: Orange/Brown
HS CAN 2 High: Orange/Green
RDA: Orange/Black
Siren
Hood Pin
SIL Interrupt (veh. side): Blue
Ignition Connector
8-pin White
Connector
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
12-pin Black
Proper Fuse
Connector
Positioning
10-pin White
Connector
Slide
to open
It is important to check that the
fuses are positioned correctly.
