Type 7 - Directed VW10 Installation Manual

Type 7

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 22 for important information on this installation.
FT CAN Low: Orange/Brown, pin 15
FT CAN High: Orange/Green, pin 14
(+) Starter: Red/Black or Red/Brown,pin 18
Ignition Switch
1
(black conn.
10 17
at ignition switch)
(+) Brake: Black/Red, pin 17
(+) 12V: Red/White or
[5] Diode 1A
Red/Yellow,
42 25 1
pin 42
28
29 12
52 41 24 11
Brown VESCM connector C
C B A
VESCM - Driver side under dashboard
21
20
HS CAN High: Orange/Black, pin 6
HS CAN Low: Orange/Brown, pin 14
HS CAN High: Tan/Black: 5
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
(+) Starter / Brake Activation Output: White/Red: 12
(+) Ignition Output: Green/Red: 14
Hood Pin
(+) Siren Output: Brown: 17
Siren
Diagnostic
1 8
Connector OBDII
9 16
HS CAN Low: Tan: 4
(-) Hood Input: Gray: 3
Parking Lights Interrupt: Red/White
or Red/Yellow, pin 8
CUT
8 7 6 Headlight switch
10 9
(black conn. at
5 4 3 2
light switch)
(+) Parking Lights:
White/Black, pin 1
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
12: Brown: (+) Parking Light Output
11: Orange/Yellow: Parking Light Interupt (conn. side)
10: Red: (+) 12V Input
9: Black: (-) Ground
5: Orange/Red: Key Wrap
4: Yellow/Red: Key Wrap
3: Brown/Red: Key Wrap
Directed Digital Solutions VW10
