Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Color
Volkswagen Jetta 2010
Ignition
Black/Violet
Starter
Red/Black
Accessory
Black/Red
Parking Light
White/Black
Parking Light Interrupt
Red/White
HS CAN High
Orange/Black
HS CAN Low
Orange/Brown
FT CAN High
Orange/Green
FT CAN Low
Orange/Brown
12V
Red/White or Red/Yellow
Brake
Black/Red
Doorlocks [4]
Blue/Red
Trunk Release [4]
Violet
Volkswagen Jetta 2011-2014 with Autolights
Ignition
Black/Violet
Starter
Red/Black
Accessory
Black/Red
Parking Light
White/Black
Parking Light Interrupt
Gray/Red
HS CAN High
Orange/Black
HS CAN Low
Orange/Brown
FT CAN High
Orange/Green
FT CAN Low
Orange/Brown
12V
Red/White or Red/Yellow
Brake
Black/Red
Doorlocks [4]
Blue/Red
Trunk Release [4]
Violet
14
Pin
Polarity
Location
8
(+)
Ignition switch.
4
(+)
Ignition switch.
3
(+)
Ignition switch.
1
(+)
Headlight switch.
8
Cut
Headlight switch.
6
Data
OBDII.
14
Data
OBDII.
20
Data
VESCM connector B, under drivers dash.
21
Data
VESCM connector B, under drivers dash.
68
(+)
VESCM connector A, under drivers dash.
39
(+)
VESCM connector A, under drivers dash.
24
MUX
VESCM connector A, under drivers dash.
23
(-)
VESCM connector A, under drivers dash.
8
(+)
Ignition switch.
4
(+)
Ignition switch.
3
(+)
Ignition switch.
1
(+)
Headlight switch.
8
Cut
Headlight switch.
6
Data
OBDII.
14
Data
OBDII.
20
Data
VESCM connector B, under drivers dash.
21
Data
VESCM connector B, under drivers dash.
68
(+)
VESCM connector A, under drivers dash.
39
(+)
VESCM connector A, under drivers dash.
24
MUX
VESCM connector A, under drivers dash.
23
(-)
VESCM connector A, under drivers dash.
Connector Information
Color
Black
Black
Black
Black
Black
Violet/Black
Violet/Black
White
White
Black
Black
Black
Black
Black
Black
Black
Black
Black
Violet/Black
Violet/Black
White
White
Black
Black
Black
Black
Directed Digital Solutions VW10
© 2017-06-22 Directed. All rights reserved.
Pins
Ref.
10
A
10
A
10
A
10
B
10
B
16
C
16
C
73
D
73
D
73
E
73
E
73
E
73
E
10
A
10
A
10
A
10
B
10
B
16
C
16
C
73
D
73
D
73
E
73
E
73
E
73
E
