Type 2; Type 10 - Directed VW10 Installation Manual

Type 2

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 11 for important information on this installation.
Steering column module
(behind steering column
(+) Brake: Black/Red, pin 17
(+) 12V:
Red/White or
Diode 1A
Red/Yellow,
42 25 1
pin 42
28
29 12
52 41 24 11
Brown VESCM connector C
C B A
VESCM - Driver side under dashboard
10
FT CAN Low: Orange/Brown, pin 3
FT CAN High: Orange/Green, pin 4
(+) Starter: Red/Black or
Red/Brown,pin 6
1 6 8
14
9 16
trim)
HS CAN Low: Orange/Brown, pin 14
(+) Starter / Brake Activation Output: White/Red: 12
(+) Ignition Output: Green/Red: 14
Hood Pin
Siren
HS CAN High: Orange/Black, pin 6
Diagnostic
1 8
Connector OBDII
9 16
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
Parking Lights Interrupt: Red/White, pin 8
CUT
10 8 7 6 Headlight switch
9
(black conn. at
5 2
4 3
light switch)
(+) Parking Lights: White/Black, pin 1
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
12: Brown: (+) Parking Light Output
11: Orange/Yellow: Parking Light Interupt (conn. side)
10: Red: (+) 12V Input
9: Black: (-) Ground
5: Orange/Red: Key Wrap
4: Yellow/Red: Key Wrap
3: Brown/Red: Key Wrap
Directed Digital Solutions VW10
