Section 1: Introduction

ABOUT THE REGLO

Th e REGLO Digital Pump Drive with Advanced Connectivity off ers precise fl ow control and highly accurate
fl uid dispensing ideal for laboratory, process, and fi eld use. All REGLO precision drives include a highly
accurate, maintenance-free motor and an easy to navigate touchscreen that makes setup and operation easier
than ever. Th e REGLO range features Ethernet and Wi-Fi connections for web-based monitoring using the
Masterfl exLive™ website (see
the pump drive's DB-25 female connection port.

Package Contents

NOTE: Please check the package and its contents for any visible signs of damage. If any damage is found
please contact Technical Assistance immediately (see
• Pump Drive
• 24 VDC Desktop Power Supply Set
• Quick Start Guide
• Flash Drive Containing the Operating Manual

Peristaltic Cassette Models

Features:
• A 5-inch multi-language touchscreen display providing easy access to user-defi ned operation parameters
and direct readouts of pump operation data, including pump speed, fl ow rates, fl ow direction, and batch
totals.
• Volume, Time, Continuous, and Analog Input modes for quick and easy operation.
• User selectable dispense volumes, tube diameters, fl ow rates, pump speeds, and run times.
• Anti-drip control.
• Easy user management with three levels of access: ADMIN, SUPER USER and USER.
• Wi-Fi and Ethernet connectivity.
• Brushless, maintenance-free motor off ering ±0.1% speed control accuracy with a turndown ratio greater
than 1500:1.
• Easy pump priming and tube calibration.
• Peristaltic Cassette models have a maximum speed of 160 RPM and fl ow rate capacities that range from
0.001 mL/min through to 68 mL/min (depending on the model and tubing size selected).
• Takes MS/CA Click'n'go tube cassettes for easy loading and removal.
• Can take up to two channels or up to four channels (depending on the model) allowing simultaneous
multiple fl uid channels on the same pump.
1-2 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
www.masterfl ex.com), and remote analog input control and monitoring through
"Technical Assistance" on page 5-10).
