Section 3: Operation
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection Screen.
• If there are multiple programs tapping SCROLL

Using Program Modes

Custom programs will appear in alphabetical order at the bottom of the Mode Selection Screen. If there are
multiple programs tapping SCROLL
General Preparation:
• Confi rm the correct tubing has been selected and is properly loaded into the pump drive (for further
information see
• Confi rm all fl uids and containers are ready.
• Switch the drive on using the power switch located at the rear of the drive. NOTE: If User Management
is enabled you may be prompted for a username and password (For further information see
Management" on page 3-7). Th e touchscreen display will revert to the previously used operation mode.
• Confi rm that the tubing has been calibrated by checking that Calibration Complete
the Program Information
• If required, prime the pump before operation (for further information see
page 3-13).
To use a program:
1. Select the desired program from the Mode Selection Screen. Th e Program Run Screen will be displayed.
2. Tap START
3. If required, Tap PAUSE
Continuous Mode operation.
NOTE:
• Tap INFORMATION
• Individual settings cannot be edited from the Program Run Screen.

Editing a Program

NOTE: If User Management is enabled only users with authorization can create and modify programs (for
further information see
To edit a program:
1. Tap EDIT
multiple programs, tap SCROLL
2. Edit the settings for the selected mode as desired. For instructions on editing individual mode settings see:
• "Adding a New Program: Continuous
• "Adding a New Program: Time
• "Adding a New Program: Volume
3-36 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
will display additional pages.
"Loading Tubing" on page 3-9).
Screen (for further information see
to begin the pump drive operation using the displayed program settings.
or STOP
to view the selected program's settings.
"User Management" on page 3-7).
located next to the desired program name on the Mode Selection Screen (NOTE: If there are
to display additional pages). Th e Program Edit Screen will be displayed.
Mode" on page 3-32.
will display additional pages.
during operation. NOTE: Th e pump cannot be paused during
Mode" on page 3-32.
Mode" on page 3-34.
"Tube Calibration" on page 3-14).
"Priming the Pump
"User
is displayed on
Drive" on
