Section 4: Communication Specification
Output data; 28 bytes of output data from master to pump.
Bytes
0
1
2
3
4
5
6
7
8 - 11
12 - 15
16 - 19
20 - 23
24 - 27
Masterfl ex Flow Units Correlation Table
Index
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
4-5 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Data Type Description
BYTE Pump Control
Bit 0: Run/Pause (1 = RUN; 0 = PAUSE)
Bit 1: Stop and Reset Dispense (1 to 0 transition)
Bit 2: Toggle Remote/Local Control (1 to 0 transition)
Bit 3: Clear Cumulative Volume (1 to 0 transition)
Bit 4: Reserved
Bit 5: Reserved
Bit 6: Set Flow Direction CCW (1 = CCW, 0 = CW)
Bit 7: Reserved
BYTE Reserved Pad
BYTE Reserved Pad
BYTE Reserved Pad
BYTE Set Dispense Mode ( 0 = CONT, 1 = TIME, 2 = VOL)
BYTE Set Tube Size (see Table 4)
BYTE Set Flow Units (see Table 3)
BYTE Reserved pad
FLOAT Set Flow Rate
FLOAT Set Dispense Volume
FLOAT Set Dispense On Seconds
FLOAT Set Dispense Off Seconds
32- bit INT Set Batch Count Total (0 = infinite)
600 & 100 RPM L/S
mL/min
mL/hr
L/min
L/hr
L/day
uL/min
uL/hr
gal/min
gal/hr
gal/day
oz/min
oz/hr
cum/hr
RPM
%
