Section 2: Basic Setup & Settings

Setting the Date

To change the date:
1. Tap SETTINGS
2. Tap DATE.
3. Select the desired date format (either month/day/year or day/month/year).
4. Tap the desired MONTH, DAY or YEAR fi eld to select and then enter the date using the onscreen keypad.
5. Tap CONFIRM

Display Brightness

To adjust the display brightness:
1. Tap SETTINGS
2. Use the DISPLAY BRIGHTNESS slider to adjust the touchscreen brightness to the desired level.

Dispense Completion Alerts

When Sound Dispense is enabled a short beep will sound at the completion of each pump dispense.
To enable or disable the dispense completion alert:
1. Tap SETTINGS
2. Tap the SOUND DISPENSE toggle to select either ON or OFF.

Batch Completion Alerts

When Sound Batch is enabled a single long beep will sound at the completion of each batch cycle.
To enable or disable the batch cycle completion alert:
1. Tap SETTINGS
2. Tap the SOUND BATCH toggle to select either ON or OFF.

Analog Output

Th e REGLO supports and controls analog output through the pump drive's 25-pin connection (for further
information see "DB-25 Electrical
1. Tap SETTINGS
2. Tap ANALOG OUTPUT. Th e Analog Output Screen will be displayed.
3. Tap to select the desired analog output type from the available list.
4. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Tap EDIT
b. Select the desired current or voltage operating range from the available list.
c. Tap CONFIRM
displayed.
5. Tap CONFIRM
3-4 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
from any of the mode screens. Th e Settings Screen will be displayed.
to save or CANCEL
from any of the mode screens. Th e Settings Screen will be displayed.
from any of the mode screens. Th e Settings Screen will be displayed.
from any of the mode screens. Th e Settings Screen will be displayed.
Connections" on page <OV>.
from any of the mode screens. Th e Settings Screen will be displayed.
. Th e Analog: Voltage Edit Screen or Analog: Current Edit Screen will be displayed.
to save or CANCEL
.
to discard changes.
to discard changes. Th e Analog Output Screen will be
