Section 2: Basic Setup & Settings
7. Press and hold PRIME
8. Tap SIZE from the Continuous Mode Screen or tap EDIT
Time Mode Screen is displayed. Th e Tube Size Screen will be displayed.
a. Select the desired tube size from the list of available options.
b. Tap CONFIRM
9. Tap CALIBRATE
10. Tap CALIBRATION VOLUME. Th e Calibration Volume Screen will be displayed.
a. Enter the desired calibration volume using the onscreen keypad. NOTE: Th e default volume or great-
er will ensure the best calibration.
b. Tap CONFIRM
11. Tap FLOW RATE. Th e Calibration Flow Rate Screen will be displayed.
a. Enter the desired fl ow rate using the onscreen keypad.
b. Tap CONFIRM
NOTE: Th e drive will adjust the displayed fl ow rate after calibration is complete.
12. Tap START
13. When calibration is complete use the onscreen keypad to enter the measured volume of fl uid from the
tube outlet container.
14. Tap CONFIRM
Complete
tube size, tube volume, and fl ow rate.
NOTE:
• Th e estimated accuracy for the selected calibration settings is shown in the Calibration Strength Bar on
the Tube Calibration Screen. Calibration accuracy can be improved by using a larger calibration volume
and/or altering the fl ow rate.
• Calibration settings are retained and transferred to other mode screens when entering or leaving the Tube
Calibration Screen.
• If the drive is stopped during calibration the calibration will be discarded and the previous mode screen
will be displayed. Empty the container before restarting the procedure.
• Calibration time at the maximum allowable fl ow rate (default max fl ow rate) is approximately 10 seconds.
Calibration time at the minimum allowable fl ow rate (approximately 4% of the maximum fl ow rate) is 4
minutes.
• Minimum and maximum fl ow rates will change after calibration due to a recalculation of the volume of
fl uid per pump revolution.
• Th e best results are obtained after tubing has been run in the pump for approximately 20-30 minutes.
• Steps 9–14 can be repeated as necessary to optimize the accuracy of the tubing calibration.
3-15 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
to prime the pump. Priming will stop when PRIME
to save or CANCEL
. Th e Tube Calibration Screen will be displayed.
to save or CANCEL
to save or CANCEL
to begin calibration. NOTE: Calibration progress will be displayed on the touchscreen.
to complete calibration and return to the previous mode screen. Calibration
should now be displayed to indicate that calibration has been completed for the current
and then SIZE if either the Volume or
to discard changes and return to previous screen.
to discard changes and return to the previous screen.
to discard changes and return to the previous screen.
is released.
