Hardware Installation and Reference Guide
Table 1-1 Button and Ports
No. Item
1 Console/Reset
2 DC Connector
3 Ethernet/PoE Port
4 LED
5 Grounding Screw
6 SFP Port
Note
The nameplate is at the bottom of the access point.
1.3

Package Contents

Table 1-2 Package Contents
Item
RG-AP680-L Access Point
Mounting Plate Assembly (Including a mounting plate and a mounting arm)
Mounting Bracket
M5 Screw
M8 Screw
M6 x 50 mm Expansion Anchor
Hose Clamp
Cable Gland for Ethernet Cable
Cable Gland for Fiber-Optic Cable
Dust Cap
Grounding Cable
Warranty Card
Description
The console port is used to manage devices.
The reset button is used to restart the access point or restore the
access point to factory settings.
Connected to the DC power supply
Uplink service port for data transmission, compliant with the
802.3af/at standard
Indicates the system status, including one system status LED and
three RSSI LEDs
Secures the grounding cable
Uplink service port for data transmission
3
Product Overview
IEEE
Quantity
1
1
1
4
2
4
2
2
1
3
1
1
