Hardware Installation and Reference Guide
Radio Specifications
Max. Data Rate
Antenna Type
Antenna Gain
Max. Transmit Power
Power Adjustment
Modulation
Receive Sensitivity
1.4.3

Port Specifications

Table 1-5 Port Specifications
Port Specifications
Bluetooth
RG-AP680-L
Radio2: 802.11a/n/ac/ax, 5.150 GHz to 5.350 GHz
Note: The operating radio is country-specific.
2.4 GHz: 575 Mbps
5 GHz: 2.4 Gbps
Combined: 2.975 Gbps
Built-in smart antennas
2.4 GHz: 4 dBi
5 GHz: 6 dBi
28 dBm
Note: The transmit power is country-specific.
Configurable in increments of 1 dBm
802.11b: BPSK, QPSK, CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11b: –91 dBm (1 Mbps), –88 dBm (5 Mbps), –85 dBm (11 Mbps)
802.11a/g: –89 dBm (6Mbps), –80 dBm (24Mbps), –76 dBm (36Mbps), –71 dBm
(54Mbps)
802.11n: –83 dBm@MCS0, –65 dBm@MCS7, –83 dBm@MCS8, –65
dBm@MCS15
802.11ac HT20: –83 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT40: –79 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT80: –76 dBm (MCS0), –51 dBm (MCS9)
802.11ax HE80: –76 dBm (MCS0), –49 dBm (MCS11)
802.11ax HE160: –45 dBm (MCS10), –43 dBm (MCS11)
RG-AP680-L
Bluetooth 5.0
5
Product Overview
