OPERATOR'S MANUAL

OPERATOR'S MANUAL

vhd,vn

vhd,vn

Volvo Trucks. Driving Success.

R

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the VNL 780 and is the answer not in the manual?

Questions and answers

Summary of Contents for Volvo VNL 780

Page 1 OPERATOR'S MANUAL OPERATOR'S MANUAL vhd,vn vhd,vn Volvo Trucks. Driving Success.
Page 2 Your new Volvo truck contains many new technological advancements that may require new servicing techniques and methods. An authorized Volvo truck dealer is in the best position to provide technicians who have the necessary training, experience and tools to properly service your truck.
Page 3 VN, VHD SERIES OPERATOR’S HANDBOOK THE INFORMATION CONTAINED IN THIS HANDBOOK IS CURRENT AT TIME OF PUBLICATION. © Volvo Group North America, Inc. 2009...
Page 4 NOTES...
Page 5: Table Of Contents
ADVISORY LABEL DEFINITIONS (IN HANDBOOK) ....1 INFORMATION FOR THE OWNER ..........2 EMISSIONS CONTROL COMPLIANCE ........5 Exhaust and Noise Emissions ............5 B20 Approval For Volvo EPA 07 Certified Products ....6 CALIFORNIA EMISSION CONTROL SYSTEMS WARRANTY ................... 7 MANUFACTURER’S WARRANTY COVERAGE: ...... 7 OWNER’S WARRANTY RESPONSIBILITIES: ......
Page 6 General Entry Guidelines ............43 Driver Side Entry/Exit ..............44 ENTERING SLEEPER FROM SEAT ........... 50 Standard Gear Lever ..............50 SAFETY EQUIPMENT ..............52 Warning Triangles, Day Cab ............53 Sleeper Cab .................. 54 SAFETY BELT SYSTEM ............. 55 SRS AIRBAG ................
Page 7 CLIMATE CONTROL SYSTEMS ........... 114 AIR CONDITIONING MANUAL CLIMATE CONTROL (MCC) ..................119 SLEEPER CLIMATE UNIT ............123 LIGHT CONTROL PANEL ............124 SLEEPER CONTROL PANEL (SLEEPER MODELS ONLY) .. 127 Sleeper Control Panel, High ............130 Sleeper Control Panel, Basic ............. 132 MISCELLANEOUS CAB EQUIPMENT ........
Page 8 CONTROL AWARENESS FEATURE ........294 FUEL ECONOMY DRIVING ............. 295 CRUISE CONTROL ..............302 Volvo Engine Brake (I-VEB) ............. 304 BRAKE OPERATION ..............305 Parking Brake/Trailer Supply Valves ......... 314 Trailer Brake Hand Control ............320 ANTI-LOCK BRAKING SYSTEM (ABS) ........ 322 VOLVO ENHANCED STABILITY TECHNOLOGY ....
Page 9 Safety Information IMPORTANT: Before driving this vehicle, be certain that you have read and that DANGER you fully understand each and every step of the driving and handling information Danger indicates an unsafe practice that in this manual. Be certain that you fully could result in serious personal injury or understand and follow all safety warnings.
Page 11: Introduction
INTRODUCTION ADVISORY LABEL DEFINITIONS (IN HANDBOOK) Cautionary signal words (Danger-Warning-Caution) may appear in various locations throughout this manual. Information accented by one of these signal words must be observed to minimize the risk of personal injury to service personnel, or the possibility of improper service methods which may damage the vehicle or cause it to be unsafe.
Page 12: Information For The Owner
If you are not the original owner of this vehicle, please notify us about the change in ownership at the address below or through an authorized Volvo Truck dealer. This is the only way we will be able to contact you if necessary.
Page 13 Note: Illustrations in this manual are used for reference only and may differ slightly from the actual vehicle; however, key components addressed in the manual are represented as accurately as possible. This manual covers Volvo VN and VHD series vehicles manufactured by Volvo Trucks North America with any of the following designations: •...
Page 14 INTRODUCTION W0028048...
Page 15: Emissions Control Compliance
INTRODUCTION EMISSIONS CONTROL COMPLIANCE Exhaust and Noise Emissions General The Federal Clean Air Act, Section 203 (a) (3), states the following concerning the removal of air pollution control devices or modification of a certified engine to a non-certified configuration: (3) For any person to remove or render inoperative any device or element of design installed on or in a motor vehicle or motor vehicle engine in compliance with regulations under this part prior to its sale and delivery to the ultimate purchaser, or for any manufacturer or dealer knowingly to remove or render inoperative any such design after sale and delivery to...
Page 16: B20 Approval For Volvo Epa 07 Certified Products
Alternative fuels, including biodiesel, that are not substantially similar to the required test fuels may adversely affect engine emissions compliance. As a result, Volvo does not warrant the engine will conform to applicable Federal or California emissions limits when operated on biodiesel or other alternative fuels that are not substantially similar to specified test fuels used for certification.
Page 17: California Emission Control Systems Warranty
INTRODUCTION CALIFORNIA EMISSION CONTROL SYSTEMS WARRANTY Note: Warranty coverage is subject to change without notice. Contact your Volvo Truck dealer for the current warranty statement. The California Air Resources Board and Volvo Trucks North America are pleased to explain the California emission control system warranty on your new motor vehicle engine.
Page 18: Owner's Warranty Responsibilities
You are responsible for presenting your motor vehicle engine to a VOLVO dealer as soon as a problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
Page 19: Qualifications And Limitations
• Damage resulting from accident, acts of nature or other events beyond the control of Volvo Trucks North America. • Inconvenience, loss of use of the vehicle, commercial loss of any kind including, but not limited to, consequential, incidental damages.
Page 20 INTRODUCTION Turbocharger Assembly VGT Actuator Control Valve Charge Air Cooler Unit Injectors Engine Wiring Harness Electronic Control Module EGR Mixer EGR Cooler Crankcase Breather 10 Diesel Particulate Filter (DPF) Assembly 11 DPF Components: • Aftertreatment Hydrocarbon Injector (AHI) • AHI Shutoff Valve •...
Page 21 Normal maintenance, such as cleaning ash from the filter at regular maintenance intervals, is not covered by the emission warranty. Note: In response to customer requests, Volvo Trucks North America may build vehicles with engines supplied by other manufacturers, including, but not limited to, Cummins. In these cases, each engine manufacturer through its service organization, is responsible for emission control systems warranty on all parts of the engine assembly, as furnished.
Page 22 Repairs covered by the California Emission Control Systems Warranty will be performed by any authorized VOLVO repair facility at his place of business with no charge for parts and labor (including diagnosis), using VOLVO parts for any part of the emission control systems covered by this warranty and found defective.
Page 23 Owners may elect to have maintenance, replacement, or repair of emission control systems performed by any repair facility, and may elect to use parts other than VOLVO parts without invalidating the warranty on other components, but the cost of such service or parts will not be covered by VOLVO under its warranty.
Page 24 7. Customer Assistance Volvo Trucks North America wishes to assure that the California Emission Control Systems Warranty is properly administered. In the event that owners do not receive the warranty service to which they believe they are entitled under the California Emission Control Systems Warranty, they should contact Volvo Trucks North America Warranty Administration, (336) 393-2000.
Page 25: California Emission Control Systems Service Record
INTRODUCTION CALIFORNIA EMISSION CONTROL SYSTEMS SERVICE RECORD CALIFORNIA EMISSION CONTROL SYSTEMS SERVICE RECORD DATE MILES/KM SERVICE SERVICED BY PERFORMED __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__ __/__/__...
Page 26: Gaseous Emission Control Systems Warranty
Volvo Trucks North America warrants the Emission Control Systems on each new VOLVO diesel engine in a new VOLVO truck to comply with all United States Federal and Canadian emissions regulations applicable at the time of manufacture of the engine, and to be...
Page 27: Qualifications And Limitations
• Damage resulting from accident, acts of nature or other events beyond the control of Volvo Trucks North America. • Inconvenience, loss of use of the vehicle, commercial loss of any kind including, but not limited to, consequential, incidental damages.
Page 28 Normal maintenance, such as cleaning ash from the filter at regular maintenance intervals, is not covered by the emission warranty. Note: In response to customer requests, Volvo Trucks North America may build vehicles with engines supplied by other manufacturers, including, but not limited to, Cummins. In these cases, each engine manufacturer through its service organization, is responsible for emission control systems warranty on all parts of the engine assembly, as furnished.
Page 29: Federal Emission Requirements
INTRODUCTION FEDERAL EMISSION REQUIREMENTS This section covers the requirement of the United States Clean Air Act which states: “The manufacturer shall furnish with each new motor vehicle or motor vehicle engine such written instructions for the maintenance and use of the vehicle or engine by the ultimate purchaser as may be reasonable and necessary to assure the proper functioning of emission control devices and systems.”...
Page 30 Volvo Trucks North America was designed, built and equipped to conform, at the time it left the control of Volvo Trucks North America, with all applicable U.S. EPA Noise Control Regulations.
Page 31 INTRODUCTION Tampering with Noise Control System Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person, other than for purposes of maintenance, repair, or replacement, of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use;...
Page 32 INTRODUCTION Noise Shielding and Insulation Devices Maintenance Ensure sound shielding and insulating devices are intact. Inspect components for damage. Primary system components requiring noise related inspection include the hood, engine compartment insulating materials (including hood insulation, bulkhead insulation, doghouse insulation, etc.) splash shields, cab skirts, fender shields, and body panels. Inspect all related fasteners, brackets, and clamps for damage and tightness.
Page 33 INTRODUCTION Maintenance Visually inspect cooling system components for damage, and/or misalignment. Primary system components requiring noise related inspection include fan blades, fan clutch, fan shroud, fan ring, and recirculation shields. Check fan blades, fan ring, fan shroud, belt tensioner and recirculation shields for any damage. Verify that fan blades clear the fan ring.
Page 34 INTRODUCTION Air Intake/Air Induction System Maintenance Make sure the air intake system is intact. Inspect components for damage, misalignment and/or leakage. Primary system components requiring noise related inspection include the air cleaner housing, air cleaner element, turbocharger, charge air cooler and intake manifold. Also inspect all ducts, pipes, hoses, tubing and elbows used to interconnect the system.
Page 35 INTRODUCTION Noise Control Log NOISE CONTROL SYSTEM MAINTENANCE LOG DATE MILEAGE MAINTENANCE MAINTENANCE PERFORMED FACILITY...
Page 36: Vehicle Data
INTRODUCTION VEHICLE DATA Identification and Labels It is extremely important that the correct vehicle model and serial number are given whenever replacement parts or service literature are ordered. Using these numbers, as well as giving the major component model and serial numbers, will prevent delay and errors in obtaining the correct material.
Page 37 Note: To deter tampering with the original build information, the information on the label will be destroyed if the label is removed. If for any reason a label is damaged, contact your authorized Volvo Truck dealer for a replacement. Vehicle Order The Vehicle Order is a complete and detailed record of all data pertaining to the assembly of the vehicle.
Page 38 INTRODUCTION Vehicle Identification Label The VIN is shown on the Vehicle Identification label. The VIN includes the vehicle make, model series, weight class, engine model, where the vehicle was built and the vehicle serial number. This label also shows the truck model designation, major component model and serial number, cab model and serial number, cab and chassis paint colors, and color numbers.
Page 39 INTRODUCTION Clean Idle Engines The California Air Resources Board (ARB) requires that 2008 model year vehicles be equipped with engines having tamper-resistant software which limits the time at which the engine can idle at speeds above low idle (550?700 rpm). At speeds above low idle, and without a PTO engaged, idle time will be limited to five minutes, after which the engine will revert back to low idle.
Page 40 INTRODUCTION Component Labels The Volvo engine serial number is located on the front left side of the cylinder block. The serial number can also be found on the certification label on the valve cover. The axle model and serial number is located on the front left side of the forward drive axle and the front right side of the rear drive axle.
Page 41: Service Literature
SERVICE LITERATURE To order a single Service Manual or a Service Manual Set for your vehicle, contact your authorized Volvo Truck dealer. In order to handle the request correctly, you must give the model, year and VIN (last six digits of VIN only).
Page 42: Service Assistance
There is also a direct number to Volvo Action Service (VAS), staffed 24 hours a day, if you are in need of assistance. The number to the Customer Support Center is: 1 (800) 528–6586 [or (800) 52–VOLVO].
Page 43: Reporting Safety Defects
Safety website at http://www.tc.gc.ca/roadsafety/menu.htm. Mexico Volvo Trucks de Mexico, S.A. de C.V. should be informed immediately if you believe the vehicle has a defect that could cause a vehicle accident, injury or death. Contact Volvo Trucks de Mexico by calling 011-52-55-50-81-68-50 or by writing to: Volvo Trucks de Mexico, S.A.
Page 44: Event Data Recording Devices
INTRODUCTION EVENT DATA RECORDING DEVICES Your Volvo vehicle is equipped with a device generally referred to as an "event data recorder" or "EDR." Please note that while the term "event data recorder" is typically used throughout the motor vehicle industry, not every EDR is the same; i.e., they do not all record the same data elements.
Page 45: Safety Information
The safe operation of this vehicle is determined by the you, the driver. Because of your special preferences, needs and circumstances, you may choose to add extra mirrors and/or other visibility enhancement devices. If so, contact an authorized Volvo Truck dealer to obtain parts which best fit your personal needs and preferences.
Page 46: Operating In Bobtail Mode
SAFETY INFORMATION Operating in Bobtail Mode CAUTION When operating bobtail, be certain that glad hands, trailer air hoses, electrical cable and connectors are properly stowed and secure. Do not allow them to rub or chafe on other components. Depending on customer specification, some tractors may be equipped with a bobtail air brake proportioning valve which automatically redistributes the braking force between front and rear axles when not hooked up to a semitrailer (bobtail operation).
Page 47 SAFETY INFORMATION DANGER DO NOT exceed the load rating of the tires or the vehicle weight ratings. Overloading may result in tire failure causing loss of vehicle control, leading to an accident resulting in severe personal injury or death. This vehicle has been designed and assembled for a maximum gross vehicle weight rating (GVWR) and a maximum front and rear axle weights rating (FAWR and RAWR).
Page 48: Vorad ® Collision Warning System
SAFETY INFORMATION ® VORAD COLLISION WARNING SYSTEM ® ® The Eaton VORAD computerized Collision Warning System constantly monitors vehicles ahead with a front end-mounted radar and in a blind spot area with an optional side-mounted radar. The Collision Warning System warns the driver of potentially dangerous situations by activating visual and audible alerts.
Page 49: Advisory Labels
SAFETY INFORMATION ADVISORY LABELS Throughout this book you will find paragraphs labeled Danger, Warning, Caution, Note and Service Hint. Danger, Caution and Warning labels are also found in various locations on the vehicle to alert drivers, operators and service technicians to situations which can cause personal injury or equipment damage.
Page 50: Cab Entry And Exit
SAFETY INFORMATION CAB ENTRY AND EXIT General WARNING DANGER Both the operator and passenger should DO NOT stand on the steps or any other exercise caution when entering or exiting part of the vehicle while it is in motion. the cab. Use the steps and grab handles to The steps and the back of cab access deck safely get in and out of the cab.
Page 51 SAFETY INFORMATION W8003120...
Page 52 SAFETY INFORMATION W8003127 VN without Fairings or VHD...
Page 53: General Entry Guidelines
SAFETY INFORMATION General Entry Guidelines WARNING To avoid personal injury due to a slip and/or fall, observe the following guidelines. BE SURE TO FOLLOW ALL OF THESE INSTRUCTIONS BEFORE ENTERING OR EXITING THE CAB OR THE AREA BEHIND THE CAB. Always have three limbs (one foot and two hands or two feet and one hand) in contact with the vehicle at all times when entering or exiting the cab or the area behind the cab.
Page 54: Driver Side Entry/Exit
SAFETY INFORMATION 14. Make sure your safety belt is disconnected before exiting the cab. 15. Make sure the safety belt is fully retracted and out of the way prior to entering or exiting the cab. 16. DO NOT put your foot on any surface that does not have slip resistant, self- cleaning material.
Page 55 SAFETY INFORMATION W8003112 Slide hands up on the handles, if necessary. Put the left foot on the top step and step up. Step into the cab with the right foot first. To exit, reverse the process. Do not attempt to exit the cab while carrying any items in your hands.
Page 56 SAFETY INFORMATION Passenger Side Entry/Exit Open the door. Place any hand-carried items on the cab floor. Grasp the left grab handle with your left hand and the right grab handle with your right hand. Put the left foot fully on the bottom step and pull yourself up to the opening.
Page 57 SAFETY INFORMATION Behind the Cab Access WARNING Be careful when entering the back-of-cab area with dirty or wet soles. Wearing shoes with soles that are dirty or wet increases the chance of slipping or falling. When trailer air and electrical connections can not be coupled from the ground, Federal Regulations require commercial carriers to provide back-of-cab access steps, grab handles and plates.
Page 58 SAFETY INFORMATION Grasp the grab handle to the left with both hands. Put the left foot onto the bottom step and pull yourself up. Put the right foot on the top step and step onto the deck plate with the left foot.
Page 59 SAFETY INFORMATION Stand on the ground when connecting the air and electrical connections to the trailer. W3005321...
Page 60: Entering Sleeper From Seat
SAFETY INFORMATION ENTERING SLEEPER FROM SEAT Standard Gear Lever CAUTION Be careful when standing to your feet in the seat area, headroom is limiting. When moving from the driver seat to the sleeper section, follow this procedure: • Make sure the parking brakes are set. •...
Page 61 SAFETY INFORMATION W4001391...
Page 62: Safety Equipment
SAFETY INFORMATION SAFETY EQUIPMENT Safety triangles and fire extinguishers are available as optional equipment. The fire extinguisher should be located by the base of the driver seat, between the seat and the door. W1000176 Note: Always store the warning triangles in the box after use.
Page 63: Warning Triangles, Day Cab
SAFETY INFORMATION Warning Triangles, Day Cab The warning triangles are stored in a box that is strapped behind the passenger seat. W1000177...
Page 64: Sleeper Cab
SAFETY INFORMATION Sleeper Cab The warning triangles are stored in a box, which is inside the exterior luggage compartment. W8003517...
Page 65: Safety Belt System
SAFETY INFORMATION SAFETY BELT SYSTEM The safety belt system is the main restraint application in the vehicle. All vehicles are equipped with this system. For additional information on the safety belt system refer to “SAFETY BELTS” page 259. The safety belt system monitors the safety belt latch and vehicle speed. When the vehicle is started the safety belt telltale displays in the cluster.
Page 66: Srs Airbag
The Volvo SRS Airbag provides increased protection in frontal collisions, where the vehicle collides with a fixed or heavy object with enough force to activate the sensors which then activate the airbag.
Page 67 SAFETY INFORMATION The inflatable airbag is folded into the center of the steering wheel. It inflates in the event of a serious collision above a certain level, where the angle of impact, crash severity, speed and nature of the object involved in the collision all play a part in whether or not the airbag is activated.
Page 68 In the event of a problem in the SRS system, an icon is shown in the graphic display in the instrument cluster. T3008842 CAUTION The vehicle should be taken to an authorized Volvo Truck dealer immediately if the SRS icon comes on or remains on while the vehicle is being driven.
Page 69 The label attached to the left-hand sun visor shows the year and month when an authorized Volvo Truck dealer should be contacted for a specific inspection and for a possible replacement of the airbag. This is done to guarantee the function of the airbag after the indicated date.
Page 70 SAFETY INFORMATION Steering shafts and steering wheel should not be removed, adjusted or replaced without following the proper work procedure. Failure to do so can damage the SRS system, which can result in malfunction of the SRS. A warning label is located on the upper steering shaft. T8006842 There is also a label on the inside of the windshield that indicates the inclusion of an airbag to the vehicle safety features.
Page 71 SRS system. Any interference with the system may cause it to malfunction and result in serious injury or death. Work on the system may only be carried out by an authorized Volvo Truck dealer. To allow the SRS system to work as designed: •...
Page 72 Note: The SRS system is only activated once in a collision. If the airbag has deployed, the following is recommended: * Have the vehicle towed to an authorized Volvo Truck dealer. Even if the vehicle can be driven after a collision, it is not recommended to drive the truck with the airbag deployed.
Page 73 Heart of the Volvo Safety System The three-point anchored safety belt is the heart of the Volvo safety system. The belt should be worn at all times. The SRS system is intended as a supplement to the three-point...
Page 75: Instruments And Controls
INSTRUMENTS AND CONTROLS CAB INTERIOR W8003838 Instrument Cluster Brake Pedal Cab Climate Control Panel Clutch Pedal (if equipped) Accelerator Pedal Steering Column Tilt Control Pedal...
Page 76: Instrument Panel
INSTRUMENTS AND CONTROLS INSTRUMENT PANEL Tell-Tales A tell-tale is a display that indicates the actuation of a device, a correct or defective condition, or a failure to function. The operator should become familiar with these symbols in order to recognize and react (if necessary) to the indicated condition.
Page 77: Panel Arrangement
INSTRUMENTS AND CONTROLS Panel Arrangement Your view from the driver seat should look something like the illustrations shown. The layout is designed to provide the operator with a good view of the gauges and controls (which are placed so they are within easy reach). The instrument panel, as shown in the following drawing, is broken down into several main sections.
Page 78: Instrument Panel Gauge Layout
INSTRUMENTS AND CONTROLS INSTRUMENT PANEL GAUGE LAYOUT W3007473 Panel Arrangement...
Page 79: Panel A
INSTRUMENTS AND CONTROLS Panel A W3007469 Light Control Panel Instrument Cluster Trailer Air Supply Tractor Parking Brake...
Page 80: Panel B
INSTRUMENTS AND CONTROLS Panel B W3007470...
Page 81 INSTRUMENTS AND CONTROLS 5. Inter-Wheel Differential Lock 15. VN: Engine Brake Mode Select (ISX) 6. Inter-Axle Differential Lock or I-Shift Hill Start Assist VHD: Optional 7. VN: Idle Management Indicator Switch or I-Shift Hill Start Assist Lamp (ISX ICON) or Optional Switch or 16.
Page 82: Panel C
INSTRUMENTS AND CONTROLS Panel C W3007471 30. VN: Optional Switch or Passenger Window Lift VHD: Optional Switch 31. Water in Fuel (Purge Switch) 32. Optional Switch or AUX/USB Port 33. VN: Sleeper Fan Speed VHD: Snow Plow Lamps 34. VN: Optional Switch or Beacon Lamps VHD: Beacon Lamps...
Page 83: Panel D
INSTRUMENTS AND CONTROLS Panel D W3007472 35. Back of Cab Light 36. Optional Switch 37. Optional Switch or Power Take-Off (PTO) 38. VN: Overhead Bunk Lamp or Passenger Side Mirror IN/OUT VHD: Power Take-Off (PTO) 39. VN: Side Mirror Heat or Power Take-Off (PTO), VHD: Power Take-Off (PTO)
Page 84: Panel E
Depending on the options selected, all gauges and tell-tales may not be used in all vehicles. Note: The dash layout is the same for all Volvo vehicles. However, the switches and certain switch positions are different depending on vehicle options.
Page 85 INSTRUMENTS AND CONTROLS 1. Light Control Panel — For more information, please refer to “LIGHT CONTROL PANEL” page 124 2. Instrument Cluster There are three instrument cluster levels available: High, Mid and Basic. W3030734 High Level Cluster 1. Tachometer 8. Lower Tell-Tales 2.
Page 86 INSTRUMENTS AND CONTROLS W3030731 Mid Level Cluster 1. Tachometer 6. Oil Pressure 2. Upper Tell-Tales 7. Coolant Temperature 3. Speedometer 8.Lower Tell-Tales 4. Front Brake Air Pressure 9. Driver Information Display (DID) 5. Rear Brake Air Pressure 10. Fuel Level...
Page 87 INSTRUMENTS AND CONTROLS W3030729 Basic Level Cluster 1. Tachometer 7. Coolant Temperature 2. Upper Tell-Tales 8. Middle and Lower Tell-Tales 3. Speedometer 9. Driver Information Display (DID) 4 . Front Brake Air Pressure 10. Fuel Level 5. Rear Brake Air Pressure 11.
Page 88: Tachometer
INSTRUMENTS AND CONTROLS Tachometer The tachometer has two colored fields: green and red. Use the green field for normal driving (1000 to 1600 rpm). Use higher engine speeds for maximum engine brake performance. Never allow the engine to go into the red field (greater than 2200 rpm). To achieve maximum fuel economy, use the Performance Bonus Guide feature.
Page 89: Oil Pressure Gauge
INSTRUMENTS AND CONTROLS If the pressure in a brake circuit air tank drops below approximately 420 kPa (65 psi), the red LED light in the lower left corner of the gauge will come on and the STOP tell-tale warning indicator comes on. In addition, the buzzer comes on if the vehicle starts to move at speed higher than 1.6 km/h (1 mph).
Page 90 INSTRUMENTS AND CONTROLS W3005171 Stop Tell-Tale W3003613 Oil Pressure Symbol Note: The engine will shut down within 30 seconds from when the red STOP tell-tale comes on. Pull off the road as soon as possible without creating a safety hazard.
Page 91: Coolant Temperature Gauge
Coolant Temperature Gauge The coolant temperature gauge indicates engine coolant temperature. The normal operating temperature for Volvo engines is 80 to 105 C (170 to 215 F). Under normal driving conditions, the temperature must be below the red sector. The temperature range for the coolant will vary depending on the type of engine, load, grade, ambient air temperature and operating conditions.
Page 92: Voltmeter Gauge (Basic Level Cluster Only)
INSTRUMENTS AND CONTROLS Voltmeter Gauge (Basic Level Cluster Only) The voltmeter gauge shows the battery voltage. The voltmeter gauge is included only in the basic level instrument cluster. Battery voltage is displayed in the DID for the mid and high level instrument clusters.
Page 93: Exhaust Pyrometer Gauge (High Level Cluster Only)
INSTRUMENTS AND CONTROLS Exhaust Pyrometer Gauge (High Level Cluster Only) The exhaust pyrometer gauge indicates the exhaust temperature, which helps the operator get the best efficiency from the engine. Variations in engine load can cause the exhaust temperature to vary. For example, high exhaust gas temperature is the result of prolonged engine lugging or over-fueling.
Page 94 INSTRUMENTS AND CONTROLS T4015831 Interwheel Differential Lock When the lock is engaged, a telltale lights up in the instrument cluster. T3014470 Inter-Wheel Tell-Tale A differential lock should only be used on a slippery surface, NOT when driving on good road conditions. If a differential lock telltale is activated in the instrument cluster, do not make turns until the telltale has gone out.
Page 95 INSTRUMENTS AND CONTROLS 6. Inter-Axle Differential Lock The inter-axle differential lock eliminates slipping between axles to improve traction. The switch has a safety latch to prevent accidental engagement. 6. Inter-Axle Differential Lock The inter-axle differential lock eliminates slipping between axles to improve traction. The switch has a safety latch to prevent accidental engagement.
Page 96 INSTRUMENTS AND CONTROLS 7. Idle Management Indicator Lamp (CUMMINS ISX ICON) For more information on this lamp, please refer to your vendor engine manual supplied with this vehicle. Electronically Controlled Suspension (ECS) (ON/OFF) For more information on this lamp, please refer to your vendor engine manual supplied with this vehicle.
Page 97 INSTRUMENTS AND CONTROLS Optional Switch 8. Electronically Controlled Suspension (ECS) (Up/Down) This is the switch that is defined by the body builder. Lift Axle The vehicle may be equipped with auxiliary lift axles. The lift mechanism operates with air pressure. Press the top part of the switch to raise the axle and press the lower part of the switch to lower the axle.
Page 98 INSTRUMENTS AND CONTROLS Optional Switch 9. Auxiliary Switches Generic switches are available for auxiliary functions that are installed by the customer. These switches can be purchased from your authorized Volvo Truck dealer. W3005502 Auxiliary Switch 10. Temp-A-Start (TAS) Indicator Lamps For more information on this lamp, refer to the operator information that is supplied with this vehicle.
Page 99 INSTRUMENTS AND CONTROLS Auxiliary Switches Generic switches are available for auxiliary functions that are installed by the customer. These switches can be purchased from your authorized Volvo Truck dealer. W3005502 Auxiliary Switch 11. Temp-A-Start (TAS) Indicator Lamps For more information on this lamp, refer to the operator information that is supplied with...
Page 100 INSTRUMENTS AND CONTROLS Lift Axle The vehicle may be equipped with auxiliary lift axles. The lift mechanism operates with air pressure. Press the top part of the switch to raise the axle and press the lower part of the switch to lower the axle. For information about lift axles, refer to “AXLES” page 378. W3005503 Pusher Axle W3005507...
Page 101 INSTRUMENTS AND CONTROLS Auxiliary Switches Generic switches are available for auxiliary functions that are installed by the customer. These switches can be purchased from your authorized Volvo Truck dealer. W3005502 Auxiliary Switch...
Page 102 Engine/Transmission Temperature Gauge Front/Rear Axle Temperature Gauge 14.Engine Brake For more information about the engine brake, see “Volvo Engine Brake (I-VEB)” page 304. I-Shift Eco-Roll For more information on this feature, please refer to the I-Shift Transmission Manual supplied with your vehicle.
Page 103 INSTRUMENTS AND CONTROLS 15. Engine Brake Mode Select (ISX) For more information about the engine brake, see “Volvo Engine Brake (I-VEB)” page 304. W3002303 I-Shift Hill Start Assist For more information on this feature, please refer to the I-Shift Transmission Manual supplied with your vehicle.
Page 104 INSTRUMENTS AND CONTROLS 16. Fifth Wheel Touch Lock. • Park the vehicle and apply parking brake for tractor trailer. DANGER • Put gearshift in neutral and chock trailer Activation of the kingpin lock release wheels. switch ONLY unlocks the kingpin latch mechanism.
Page 105 INSTRUMENTS AND CONTROLS Transmission Retarder For more information about the transmission retarder, see “Transmission Retarder, VHD Only” page 327. W3004428 17. Marker Interrupt Switch This switch interrupts power to the marker lights when held down. When released, it springs back to the ON position and returns power to the marker lights. W3001352 Marker Interrupt Switch...
Page 106 INSTRUMENTS AND CONTROLS Secondary Gauge Cluster The secondary gauge is an optional feature, which is available only with the Mid and High level instrument clusters. The instrument cluster receives temperature information from the datalink and then passes the information to the secondary gauge for viewing. W3006081 W3006082 Engine/Transmission Temperature Gauge...
Page 107 INSTRUMENTS AND CONTROLS 18. Secondary Gauge Cluster The secondary gauge is an optional feature, which is available only with the Mid and High level instrument clusters. The instrument cluster receives temperature information from the datalink and then passes the information to the secondary gauge for viewing. W3006081 W3006082 Engine/Transmission Temperature Gauge...
Page 108 This may be useful for decreasing the chances of getting bogged down when driving in heavy snow, slush or muddy conditions. Refer to Volvo Exhaust Brake for more information. 20. Suspension Dump Switch Vehicles with rear air suspension have a control for deflating the air springs.
Page 109 INSTRUMENTS AND CONTROLS 21. Fifth Wheel Slide Switch DANGER The release must never be operated while the vehicle is operating on the road. Fifth wheel position adjustment must only be done when stationary. Damage to the fifth wheel, trailer kingpin and slider may occur if not operated properly and may lead to an accident, causing serious personal injury or death.
Page 110 INSTRUMENTS AND CONTROLS Engine Air Control Switch The engine fresh air control switch controls air flow to the engine air cleaner. In the normal OFF position, air is pulled through the side hood vent, and into the air cleaner. In the ON position, air is pulled from within the engine compartment into the air cleaner.
Page 111 “Trailer Brake Hand Control” page 320. 31. Water-In-Fuel (Purge Switch) (Optional) The water-in-fuel drain switch is a non-locking switch used to drain the fuel water separator on Volvo engines. W3005378 Water-In-Fuel Drain Switch A symbol displayed in the instrument panel indicates when it is recommended to drain the water separator.
Page 112 INSTRUMENTS AND CONTROLS Draining Procedure Note: If the engine is started before draining is complete, the process is interrupted. Stop the vehicle. Apply the parking brake. Turn off the engine. Place a container under the water separator. Turn the ignition key counterclockwise to the "Radio, Accessories" position. If the vehicle is equipped with a Basic Instrument Cluster, press the Water-In-Fuel Drain Switch.
Page 113 INSTRUMENTS AND CONTROLS 33. Sleeper Fan Speed Switch The sleeper fan switch located in the dash, controls the sleeper fan speed. The switch in the sleeper control module performs the same function as the dash switch. Press the top part of the switch to increase the fan speed, press the lower part to decrease fan speed.
Page 114 INSTRUMENTS AND CONTROLS Snow Plow Lamps Vehicles specified with this option have the following: • Turn ON low beam snow plow head lamps. • Turn OFF main head lamps, high beam, fog and driving lights. • In driving mode, DRL remains ON. •...
Page 115 INSTRUMENTS AND CONTROLS Optional Switch 35. Back of Cab Light Switch (Optional) To activate the back of cab light, press the bottom part of the switch. The light will stay on until the switch is turned to the OFF position. Back of cab lights are available as a flush-mounted light in the middle of the cab rear wall or as a high-mounted light on the side of the cab.
Page 116 INSTRUMENTS AND CONTROLS 38. Sleeper Overhead Bunk Lamp This switch operates the overhead lighting in the VN sleeper cabs. It is situated on the left-hand side of the dash to allow access to the switch without entering the sleeper section of the cab.
Page 117: Dash Switches
INSTRUMENTS AND CONTROLS 41. Optional Switch 42. Optional Switch 43. Power Outlet For information about power outlets, refer to “12 Volt Power Outlets” page 159. 41. Microphone The microphone is located above the driver in the headliner. It is available on the Mid-Level radio with Blue Tooth/Hands free option.
Page 118 INSTRUMENTS AND CONTROLS Transmission-Mounted PTO The transmission-mounted PTO is clutch dependent, which means that operation can be regulated by depressing or releasing the clutch pedal. This PTO should NOT be in use while driving. Engage the PTO by depressing the clutch pedal and pressing in the bottom part of the switch. Release the clutch pedal to start the PTO.
Page 119 PTO dash switch is activated (Volvo engines only). If NOT, then • Volvo engines: Press the RESUME button to achieve the preset PTO engine speed. Alternatively, the accelerator pedal can be used to achieve the desired engine speed, and press SET+ or SET- to hold that speed •...
Page 120 INSTRUMENTS AND CONTROLS To increase/decrease engine speed: Volvo engines: Press and release the SET+ or SET- toggle switch to increase/decrease speed in increments (increment size depends on programmed value). Cummins engines: Press and hold the SET+ or SET- toggle switch to increase/decrease speed.
Page 121 The I-VEB is standard equipment on the Volvo 16F engine and optional on the 13F and 11F engines. The I-VEB has a six position control located on the steering column, just forward of the wiper stalk.
Page 122 (within the limits of the engine brake) to maintain that speed • 1 = 40% Engine Braking • 2 = 70% Engine Braking • 3 = 100% Engine Braking • B = I-Shift Brake Program — When ordered in conjunction with the Volvo I-Shift Transmission, the controls are integrated...
Page 123 INSTRUMENTS AND CONTROLS Cummins ISX Intebrake Standard: Two dash switches control the 3-level engine brake; the left dash switch controls ON/OFF, the right dash switch controls LOW/MED/HIGH. W3005433...
Page 124: Climate Control Systems
INSTRUMENTS AND CONTROLS Optional: A 6-level retarder stalk switch mounted to the right of the steering column. An ON/OFF switch at the end of the stalk lever enables/disables the engine brake. W3005373 CLIMATE CONTROL SYSTEMS There are two different air conditioning systems. Depending on your vehicle, you will have one of these two air conditioning units installed: Electronic Climate Control (EEC) Manual Climate Control (MCC)
Page 125 INSTRUMENTS AND CONTROLS AIR CONDITIONING ELECTRONIC CLIMATE CONTROL (ECC) W8003062 AC OFF button: turns the air conditioning OFF. The arrow in the illustration shows the LED light which is AMBER or RED indicating the AC compressor is OFF. The ECC will still try to maintain the selected temperature in the cab without the compressor.
Page 126 INSTRUMENTS AND CONTROLS Recirculation Press recirculation to circulate the air in the cab. Only a small amount of air is taken directly from outside. The light in the button comes on when the button is pressed for air recirculation. Temperature Control Settings ECC Maximum Cold Setting The temperature knob should be set to the far left.
Page 127 INSTRUMENTS AND CONTROLS Mist and Ice Removal DANGER DO NOT attempt to drive with the windshield covered by mist, or fog or frost. The visibility is reduced, which could lead to an accident causing severe personal injury or death. Turn knob to defrost. Rotate the temperature knob to add heat as necessary.
Page 128 INSTRUMENTS AND CONTROLS ECC Air Distribution W8003067 Temperature Sensor CAUTION The temperature sensor shown in the illustration, detects the temperature in the cab. DO NOT cover the sensor, and DO NOT place warm objects, like coffee makers or refrigerators, close to the sensor.
Page 129: Air Conditioning Manual Climate Control (Mcc)
INSTRUMENTS AND CONTROLS AIR CONDITIONING MANUAL CLIMATE CONTROL (MCC) One difference in the Manual Climate Control unit is the AC ON button. W8003066 AC ON button turns the air conditioning ON. Temperature Control Knob Fan Speed Knob Recirculation Button Air Distribution Knob Note: The LED light is green when the AC button is depressed.
Page 130 INSTRUMENTS AND CONTROLS Recirculation Press recirculation to circulate the air in the cab. Only a small amount of air is taken directly from outside. The light in the button comes on when the button is pressed for air recirculation. Temperature Control Settings MCC Move the knob to the blue bar for cool air to circulate in the cab, and to the red bar for warm to hot air to circulate in the cab.
Page 131 INSTRUMENTS AND CONTROLS MCC Air Distribution W8003110 Always allow the dashboard vents (see arrows in illustration) to remain open. Irrespective of how the air distribution is set, a small amount of air will always come from the dashboard vents to ensure the temperature in the cab is correct. Note: Floor Mode: Unheated air is leaked to the panel vent to balance the heat rising from the floor.
Page 132 INSTRUMENTS AND CONTROLS If at any time there is any question whether fumes are entering the cab, determine the cause of the fumes and have it corrected as soon as possible. If the vehicle must be driven under these conditions, drive only with all windows open. Protect against carbon monoxide entry into the cab.
Page 133: Sleeper Climate Unit
INSTRUMENTS AND CONTROLS SLEEPER CLIMATE UNIT The sleeper cabs have an A/C and heater unit that is located in the passenger side luggage compartment. The sleeper unit operates from the same heater and air conditioning supply as the main unit. The heater can be operated independently from the main unit as long as the engine is running.
Page 134: Light Control Panel
INSTRUMENTS AND CONTROLS LIGHT CONTROL PANEL Exterior lighting is controlled through the light control panel. The rotary knob controls the parking lights, headlights, and the optional fog and driving lights. The panel also has a dimmer control switch and hazard switch. W3005377 Parking Lights Headlights...
Page 135 INSTRUMENTS AND CONTROLS Fog and Driving Lights Fog and driving lights are wired so they are turned on only when the headlight control is on. Fog lights are used with the low beam headlights. Driving lights are used with the high beam headlights.
Page 136 INSTRUMENTS AND CONTROLS W3005274 VNL Fog and Driving Lights...
Page 137: Sleeper Control Panel (Sleeper Models Only)
INSTRUMENTS AND CONTROLS SLEEPER CONTROL PANEL (SLEEPER MODELS ONLY) The sleeper control module is located behind the driver’s seat. It provides precise temperature control to the sleeper unit. There are separate temperature and fan control systems for the sleeper and the cab area. The driver can control the fan speed in the sleeper using a control switch on the dash.
Page 138 INSTRUMENTS AND CONTROLS W3030107 Panel in VN 730 and 780 Panel in VN 430, 630, 670 and VHD 430...
Page 139 INSTRUMENTS AND CONTROLS This dual control usage provides optimum comfort to the driver and passenger (if any) in both compartments. The sleeper control module is used to operate the following: • Auxiliary Heating, Venting and Air Conditioning • Alarm Clock/Timer •...
Page 140: Sleeper Control Panel, High
INSTRUMENTS AND CONTROLS Sleeper Controls Sleeper Control Panel, High W3030106...
Page 141 INSTRUMENTS AND CONTROLS Display Screen: Displays selected information. On/Off button Radio Forward Scan/Search/Next Track Radio Power Menu/Snooze Button: This button allows you to adjust settings in the display screen and activate the clock’s snooze option. Fan Speed Control and Battery Protection Override Switch: This can be controlled from the sleeper control module or from the dash rocker switch.
Page 142: Sleeper Control Panel, Basic
INSTRUMENTS AND CONTROLS Sleeper Control Panel, Basic W3030078...
Page 143 INSTRUMENTS AND CONTROLS Overhead Lamp Switch: This can be controlled from the sleeper control module or from the dash rocker switch. Speaker: Sounds when the alarm or timer goes off, or when entering battery protection mode. Display Screen: Displays selected information. Menu/Snooze Button: This button allows you to adjust settings in the display screen and activate the clock’s snooze option.
Page 144 INSTRUMENTS AND CONTROLS Dimmer To adjust the backlighting brightness level, perform the following: Press the MENU button. Press the SET button. Use the “+” or “-”knob to adjust the brightness level. Press the SET button. Once the backlighting brightness is set to the desired level, the display goes back to the clock. Note: After 5 minutes of inactivity the display will shut off.
Page 145 INSTRUMENTS AND CONTROLS Turning Heater On/Off To turn the heater On/Off , perform the following: Press the MENU button three times. The Heat icon blinks. The heat control value displays either as OFF, Auto or Cycle depending on the previous setting. Press ON/OFF button to toggle between the On/Off position.
Page 146 INSTRUMENTS AND CONTROLS Setting Sleeper Control Panel Heat Control Value to Cycle To set the Sleeper Control Panel heater to Cycle, perform the following: Press the MENU button three times. The Heat icon blinks. The heat control value displays either as OFF, Auto or Cycle depending on the previous setting.
Page 147 INSTRUMENTS AND CONTROLS Setting Sleeper Control Panel Timer To set the Sleeper Control Panel Timer, perform the following: Press the MENU button four times. The TIMER icon blinks. Press the SET button. To set the Timer minutes, use the “+” or “-”knob. Press the SET button.
Page 148 INSTRUMENTS AND CONTROLS Turning the Lamp Timer ON/OFF To turn the Lamp Timer On/Off for the Sleeper Control Panel, perform the following: Press the MENU button six times. The Lamp Icon flashes. Press ON/OFF. The Lam p Timer is turned On/Off. The Lamp icon toggles between On/Off accordingly. Setting the Lamp Timer To set the Lamp Timer, perform the following: Press the MENU button six times.
Page 149 INSTRUMENTS AND CONTROLS Set Clock To set the clock for the Sleeper Control Panel, perform the following: Press the SET button. To set the clock to either ’12’ or ’24’ hour increments, use the “+” or “-”knob. Press the SET button. To set the clock hour, use the “+”...
Page 150: Miscellaneous Cab Equipment
INSTRUMENTS AND CONTROLS MISCELLANEOUS CAB EQUIPMENT Cup Holders and Trash Compartment There is a trash bin holder at the lower part of the dash. To open, press the top part of the lid in and the lid will fold out. To close, press the lid in until the latch closes. There are also two dash-mounted cup holders convenient to the driver and passenger.
Page 151 INSTRUMENTS AND CONTROLS Sleeper cup holder: Located on the left lower tower cabinet, for the bottom bunk. There is another cup holder located on the left upper tower cabinet for the upper bunk. W8003181...
Page 152 INSTRUMENTS AND CONTROLS Curtains Curtains are available for all the sleeper cabs to ensure privacy and to darken the cabin from outside light. Various configurations are available. Curtains can cover the whole windshield area or go across the sleeper opening. When the curtains are not in use, they are stored out of the way and held in place with velcro straps.
Page 153: Steering Column
The ignition switch is located on the right side of the steering column just under the steering wheel. Standard equipment is a normal ignition switch. Note: The vehicle is delivered with 2 identical keys. If more keys are needed, order them through your authorized Volvo Truck dealer. The ignition positions are: •...
Page 154 INSTRUMENTS AND CONTROLS W3028429...
Page 155 INSTRUMENTS AND CONTROLS Windshield Wiper/Washer Note: Make sure the ignition is in the Off position to avoid draining the battery. The wiper/washer functions are operated by the same lever. The wipers have normal and fast speeds which are activated by moving the lever down one or two positions. To let the wipers engage for a few passes, lightly depress the lever until the wipers start and hold it there.
Page 156: Adjustable Steering Column
INSTRUMENTS AND CONTROLS ADJUSTABLE STEERING COLUMN DANGER DO NOT try to make adjustments to the steering wheel while the vehicle is moving. Never operate the vehicle with the steering wheel adjusted to its uppermost position (exiting cab position). Make all adjustments before starting the vehicle, to prevent loss of vehicle control, which can cause personal injury or death.
Page 157: Steering Wheel Controls
INSTRUMENTS AND CONTROLS STEERING WHEEL CONTROLS Left-Hand Controls • Headlamp Interrupt (Top) • Marker Interrupt (Bottom) When either switch is pressed, the corresponding lights toggle from their current state. If OFF they change to ON and if ON they change to OFF. When pressed for more than 3 seconds, the lights revert automatically to the initial state.
Page 158 INSTRUMENTS AND CONTROLS Right-Hand Controls • Radio controls Press +, up or -, down to change the radio volume. Press the switch left or right to change radio stations. The radio will seek the next station with a strong signal. W3005304...
Page 159: Miscellaneous Switches
INSTRUMENTS AND CONTROLS MISCELLANEOUS SWITCHES Horn Switches Electric and air horns are standard equipment. They are both operated from the steering wheel or center pad. The airbag can be pressed down anywhere around the edge to engage the air horn. W6001503 Air Horn Electric Horn (city horn)
Page 160: Interior Lights
INSTRUMENTS AND CONTROLS INTERIOR LIGHTS The cab is equipped with separate and combined interior and reading lights in various locations in the cab. The front seat overhead lights can be turned on at any time using the switch in the fixture. This is a three-way switch, pressing the lamp turns the light ON, OFF or the light comes on with the door being opened.
Page 161 INSTRUMENTS AND CONTROLS Interior Lights Chart Number Description Overhead Dome Lamp Overhead Dome/Spot Lamp connected to door Door Courtesy Lamp Dome Lamp — Sleeper Reading Lamp under bunk storage Reading Lamp Overhead Lamp — Short Overhead Lamp — Long Overhead Dome/Spot Lamp Control Panel Lamp Note: To prevent short service lift, DO NOT touch the glass surface of the replacement bulb.
Page 162 INSTRUMENTS AND CONTROLS The red courtesy light comes on when the door is opened. The lens is red to alert oncoming traffic from the rear that the door is open. It is also used during night driving to light up the floor area and steps without distracting the driver with a glaring light.
Page 163 INSTRUMENTS AND CONTROLS The door latch has an internal switch that operates all door-activated lights. W8003522...
Page 164: Fresh Air Vent
INSTRUMENTS AND CONTROLS Fresh Air Vent A. Closed B. Open C. Vertical Air Flow D. Lateral Air Flow T0008094 When heating the cab, all vents should be closed. However, the vents on the outer parts of the dash can be used for defrosting the cab door windows. When operating the air conditioning, all air vents should be completely open and the air flow directed upward.
Page 165: Cab Ventilation, Sleeper
INSTRUMENTS AND CONTROLS CAB VENTILATION, SLEEPER In sleeper versions (except the VN 780 and VN 730) there is a fresh air vent located on each cab side wall. It opens to two positions so the air flow can be regulated. W8003135...
Page 166 INSTRUMENTS AND CONTROLS The vent also opens toward the front or toward the rear. This can be used for forcing air into the cab (open toward the front) or for venting air out of the cab (open toward the rear). CAUTION The vent should not be used during rain, while washing the vehicle or other...
Page 167 INSTRUMENTS AND CONTROLS W8003823 VN 780 and VN 670 Vent Window VN 780 Hinged Side Window...
Page 168 INSTRUMENTS AND CONTROLS The VN 730 is equipped with two hinged side windows in the sleeper area. DO NOT force the window crank mechanism in the fully open position. The mechanism can be damaged if you try to open the window beyond the stop position. CAUTION Make sure the windows are closed before washing the cab.
Page 169 INSTRUMENTS AND CONTROLS 12 Volt Power Outlets CAUTION DO NOT connect a device with a current rating in excess of 10 amps or the amount labeled. There are a number of 12 V outlets that can be accessed in the cab. There is a power outlet on the sleeper control panel.
Page 170 INSTRUMENTS AND CONTROLS 12 Volt Locations There is an optional power outlet in the driver and passenger side cabinets. Accessories for this cabinet will have ON/OFF switches of their own. The cabinet 12 V outlets are made for 12 V accessory-type plugs. W3005508 VN 780, VN 730...
Page 171 INSTRUMENTS AND CONTROLS W3005500 VN 780, VN 730...
Page 172: Inverter Switch ? 12 V Dc To 120 V Ac
INSTRUMENTS AND CONTROLS Inverter Switch ? 12 V DC to 120 V AC DANGER When parked on wet ground, avoid using an external power source to connect the cab power plug. Water is a conductor of electricity. In wet conditions, electrical shock can occur which can result in personal injury or death.
Page 173 INSTRUMENTS AND CONTROLS W3005980 This is a typical setup with a factory-installed inverter. External Power Plug Load Center Inverter (if equipped)
Page 174 INSTRUMENTS AND CONTROLS Note: A tripped circuit is usually an indication of a fault in the circuit, or of an appliance being supplied with power. Every effort should be made to identify and correct any fault that exists. 120 Volt System and Outlets DANGER When parked on wet ground, avoid using an external power source to connect the...
Page 175 INSTRUMENTS AND CONTROLS W3005284 Power goes through a circuit breaker box located on the front wall in the driver side luggage compartment. On the right is an ON/OFF switch and on the left is the ground fault circuit interrupter. The controls may also be reached from inside the cab through the hatch under the mattress or cushion.
Page 176 INSTRUMENTS AND CONTROLS W3005967...
Page 177 INSTRUMENTS AND CONTROLS From the breaker box in the VN 780 and 730, power goes to the three outlets as a standard feature. In the VN 670 and 630 models, the outlet on the driver side lower bunk box is standard, and the tower cabinet middle compartments (1) each have an optional outlet.
Page 178 INSTRUMENTS AND CONTROLS W3005343 120 Volt System Wiring, VN 670, VN 630...
Page 179 INSTRUMENTS AND CONTROLS W3005342 120 Volt System Components, VN 670, VN 630 120 Volt Outlet External 120 Volt Receptacle Circuit Breaker Box...
Page 180 Some of these may deform the lighter socket’s tangs and cause it not to work properly. If an auxiliary socket is needed, the cigar lighter assembly may be replaced with the approved Volvo 12 V power socket. CAUTION...
Page 181: Parking Heater (Optional, Sleeper Models Only)
INSTRUMENTS AND CONTROLS PARKING HEATER (OPTIONAL, SLEEPER MODELS ONLY) DANGER DO NOT fuel the vehicle or handle flammable liquids in the vicinity of an operating parking heater. The fuel vapors can be ignited, causing an explosion or fire resulting in severe personal injury or death.
Page 182 INSTRUMENTS AND CONTROLS WARNING The parking heater is a very hot object. DO NOT touch the heater when it is in operation or shortly thereafter. Touching a heater may cause burns to exposed skin. CAUTION The heater air inlet is located in the bunk wall in front of the heater.
Page 183 INSTRUMENTS AND CONTROLS Fuel Parking Heater Note: The parking heater is not available if the vehicle is equipped with a sink. A fuel heated parking heater is available as an option. It is located in the left-hand luggage compartment. The heater provides automatically regulated heat that is distributed through its own vents into the sleeper section of the cab.
Page 184: Antennas
INSTRUMENTS AND CONTROLS ANTENNAS General Multiband Antenna Multiband Multiplexer (Rami) Radio AM/FM TV Antenna There are antennas mounted on the top of the mirror brackets for wideband reception. They receive or send signals for radio, CB and telephone. Each antenna carries multiple wire windings that work together with mirror bracket devices to cover the needs of many uses.
Page 185 INSTRUMENTS AND CONTROLS Antenna Multiplexer W3005509 Cellular Phone Antenna Cable Radio Antenna Cable Connection Phone Cable Connection CB Radio Antenna Cable Connection Communication signals that travel to and from the antennas go through the antenna multiplexer. It is standard in the VN 670 and VN 780, and optional on other models. Coaxial cables for the cellular phone, CB radio and radio are included in the multiplexer system —...
Page 186: Television
The multiplexer is accessed through the lower dash panels. Cable routing is as shown in the illustration above. Use only genuine Volvo replacement parts for this multiplexer system; standard antennas will give unsatisfactory performance. The windings in the antennas are specific to this system: different sections of the antenna are used for the cellular phone, radio and CB.
Page 187 INSTRUMENTS AND CONTROLS W0002361 There is an optional television speaker available, located in the top of the sleeper switch panel. Beside the speaker, there is a jack for headphones. This is provided for silent viewing of the TV. When the headset jack is plugged in, the speaker is cut out. Note: The TV prep kit is optional.
Page 188: Communication Equipment
INSTRUMENTS AND CONTROLS COMMUNICATION EQUIPMENT CB Radio There is an optional platform provided for a CB radio on top of the dash. The unit is held in place with a strap which can accommodate a variety of sizes. W3006382 The CB radio can also be mounted in the overhead storage. See "STORAGE COMPARTMENTS"...
Page 189 INSTRUMENTS AND CONTROLS Telephone There is room on the dash for a mobile telephone. This can be hooked up to the multiplex box. If the vehicle is delivered with a multiplex box, the connecting end of the telephone coaxial cable should be located at the lower dash cover. Note: The panel must be removed to access the cable.
Page 190: Storage Compartments
INSTRUMENTS AND CONTROLS STORAGE COMPARTMENTS DANGER Heavy objects must be stored only in the outside storage areas or secured on the floor. Cabinets and storage compartments are designed for clothing and lighter personal effects only. In the event of a collision, heavy, unsecured objects in overhead storage can come loose and cause severe personal injury or death to...
Page 191 INSTRUMENTS AND CONTROLS W0002361...
Page 192 INSTRUMENTS AND CONTROLS Front Overhead Storage There are two configurations of overhead storage compartments mounted over the windshield: five openings with nets, or CB radio, switch panel, and three openings with nets. The storage compartments have a maximum storage weight limit of approximately 1.1 kg (2.5 lb.) per opening or a total of 5.6 kg (12.5 lb.) evenly distributed.
Page 193 INSTRUMENTS AND CONTROLS W8003821 CB Radio, Switch Panel and Three Openings with Nets...
Page 194 INSTRUMENTS AND CONTROLS There are two configurations of forward overhead shelves at the front of the sleeper: without cabinets or with cabinets. The storage compartments have a maximum storage weight limit of approximately 3.6 kg (8 lb.) per section. W8003794 Forward Overhead Shelf without Cabinets...
Page 195 INSTRUMENTS AND CONTROLS W8003793 Forward Overhead Shelf with Cabinets...
Page 196 INSTRUMENTS AND CONTROLS VN 780 Storage W8003805 1. 3 kg (6.6 lb.) 9. 4 kg (8.8 lb.) +2. 3 kg (6.6 lb.) 10. 15 kg (33.1 lb.) with TV, 3. 4 kg (8.8 lb.) 6 kg (13 lb.) without TV 4.
Page 197 INSTRUMENTS AND CONTROLS VN 780 Bunk Storage W8003157 Storage Bins Storage Compartment Storage Compartment Exterior Side Storage Compartment...
Page 198 INSTRUMENTS AND CONTROLS VNL 730 Storage W0002358 1. 6 kg (13 lb.) without 5. 3 kg (6.6 lb.) refrigerator, 45 kg (99 lb.) 6. 3 kg (6.6 lb.) equally distributed with 78 L 7. 13.6 kg (30 lb.) refrigerator 8. 10 kg (22 lb.) on hanger 2.
Page 199 INSTRUMENTS AND CONTROLS W8028486 Load Limits 1. 5 kg (9.9 4. 3 kg (6.6 lb.) lb.) with 44 L 5. 13.6 kg (30 lb.) refrigerator 6. 10 kg (22 lb.) on 2. 4 kg (8.8 lb.) if hanger rod shelf, 5 kg (9.9 lb.) if refrigerator 3.
Page 200 INSTRUMENTS AND CONTROLS W8028487 Load Limits 1. 15 kg (33 lb) with 44 L refrigerator 2. 10 kg (22 lb)
Page 201 INSTRUMENTS AND CONTROLS VNL 730 Bunk Storage W8028488 Load Limits 1. Storage Compartment 2. Storage Compartment 3.Exterior Side Storage Compartment...
Page 202 INSTRUMENTS AND CONTROLS VN 670, 630, 430 and VHD 430 Storage W8028489 Load Limits 1. Lower Bunk Floor Panel 2. Release Handle 3. Restraint Cylinders 4. Outside Storage Compartments...
Page 203: Sleeper Bunks
INSTRUMENTS AND CONTROLS SLEEPER BUNKS General Upper and lower bunks are available in the VN 780, 730, 670 and 630 models. The lower bunk is standard while the upper bunk is optional. The VN 430 and VHD 430 are equipped with one lower bunk.
Page 204 INSTRUMENTS AND CONTROLS W8028490 Cushions: These can be moved and placed to the side. Cushions...
Page 205 INSTRUMENTS AND CONTROLS VN 780 Sleeper Upper Bunk DANGER Always have three limbs (one foot and two hands or two feet and one hand) in contact with the floor, bunk or step at all times when entering or exiting the upper bunk.
Page 206 INSTRUMENTS AND CONTROLS W8028491 Upper Bunk Upper Bunk in Lowered Position Release/Pull Strap Upper Bunk in Raised Position...
Page 207 INSTRUMENTS AND CONTROLS VNL 730 Sleeper Bunk DANGER Always have three limbs (one foot and two hands or two feet and one hand) in contact with the floor, bunk or step at all times when entering or exiting the upper bunk.
Page 208 INSTRUMENTS AND CONTROLS W8028491 Upper Bunk Upper Bunk in Lowered Position Release/Pull Strap Upper Bunk in Raised Position The VNL 730 can be equipped with a single 53-inch lower bunk, or a 42-inch lower bunk and an upper bunk. For information on bunk safety restraints, see “Safety Restraint VN 430, VN 630, VN 670 and VHD 430”...
Page 209 INSTRUMENTS AND CONTROLS W8028524 53-Inch Lower Bunk...
Page 210 INSTRUMENTS AND CONTROLS The 42-inch bunk cushions cover the luggage compartment. They can be moved for access to luggage from inside the cab. W8028524 Cushions: These can be moved for access to the luggage compartment. Cushions: These can be moved and placed to the side.
Page 211 INSTRUMENTS AND CONTROLS The upper bunk is hinged and can be raised out of the way. The bunk is supported by a strut on each side in the raised and lowered positions. Use the handle in the middle of the bunk to raise and lower it.
Page 212 INSTRUMENTS AND CONTROLS VN 670, 630 42-Inch Sleeper Bunk W8028526 VN 670, 630 Lower Bunk WARNING Support the bunk with one hand while releasing the latch. Failure to support the bunk may lead to the bunk falling without control, causing personal injury.
Page 213 INSTRUMENTS AND CONTROLS W8028527 VN 670, 630 Lower and Upper Bunks...
Page 214 INSTRUMENTS AND CONTROLS VN 670 Optional Fold Down Step In the VN 670 sleeper there is an option on the passenger side which offers a fold down step. See illustration. W8028528 Fold Down Step Cabinet Grab Handle...
Page 215 INSTRUMENTS AND CONTROLS VN 670 W8028529 Moveable Cushions in Lower Bunk...
Page 216 INSTRUMENTS AND CONTROLS VN 430 and VHD 430 Sleeper Bunk W8028530 Bunk Bunk Restraints Lower Bunk Restraint Attachment Buckles Tenting Buckles...
Page 217 INSTRUMENTS AND CONTROLS Upper Bunk Access VN 780 DANGER Always have three limbs (one foot and two hands or two feet and one hand) in contact with the floor, bunk or step at all times when entering or exiting the upper bunk.
Page 218 INSTRUMENTS AND CONTROLS W8028531 1.Ladder in 4.Ladder (Stored) Down Position 5.Cabinet Grab Handle 2.Retainer 6.Ladder Security 3.Grab Handle Positioning (on Optional Fixed Bunk, Grab Handle is Not Available)
Page 219: Vn 780, Vnl 730, Vn 670 Office
INSTRUMENTS AND CONTROLS VN 780, VNL 730, VN 670 OFFICE DANGER Do not sit at the table when the vehicle is moving. It is intended for use only when the vehicle is parked. Passengers should be in the passenger seat wearing the safety belt or in the bunk with the bunk restraint attached.
Page 220 INSTRUMENTS AND CONTROLS W8003158...
Page 221: Sleeper Compartment Sink
INSTRUMENTS AND CONTROLS SLEEPER COMPARTMENT SINK A built-in sink is available as optional equipment in some sleeper models. It is located on the left side, in the cabinet behind the driver. The sink is mounted in the drawer space. To pull out, grasp the drawer lip and release the latch.
Page 222 INSTRUMENTS AND CONTROLS To operate the water pump, there is a combined valve and switch in the knob (see arrow in illustration) on the base. Turn the knob slightly toward you to start the pump; see arrow in illustration. Turn the knob further to increase water flow. When the knob is turned fully back to rest position, the pump will stop.
Page 223 INSTRUMENTS AND CONTROLS It is not recommended to keep unused water in the tank for over one month. Clean and refill as necessary. W8002168 CAUTION USE POTABLE DRINKING WATER ONLY. Verify with the supplier of any water prior to filling the fresh water tank that it is potable to avoid contamination of the tank.
Page 224 INSTRUMENTS AND CONTROLS CAUTION Fresh water and waste water tanks must be drained if the vehicle is not being used and the outside temperature is below freezing. Also drain the hose from the pump to the faucet. Failure to drain the system may result in component damage due to water forming ice.
Page 225 INSTRUMENTS AND CONTROLS When the tank is full, reinstall the fill hose on the elbow fitting. Do not tighten more than finger tight. Make sure that the valve handle is fully open (1) to allow venting. If the valve is left in any of the closed positions (2), the pumped out water may generate an under-pressure in the tank, interfering with the pump operation.
Page 226 INSTRUMENTS AND CONTROLS Waste Water Tank When the water is drained from the sink, it is collected in a waste water tank behind the fresh water tank. Waste water tank volume is 19 liters (5 gallons). The tank is fastened to the floor with a strap that can be easily opened for tank removal.
Page 227: Operation
If any component or system does not pass this inspection, it must be corrected before operating the vehicle. Whenever equipment requires adjustment, replacement, repair or lubrication, refer to the Service Manuals or contact an authorized Volvo Truck dealer for the correct procedures, specifications and intervals.
Page 228: Pre-Trip Assistance
OPERATION Pre-Trip Assistance The Pre-Trip Assistance option is a tool to assist the driver in completing the pre-trip inspection of the vehicle. This option is not a substitute for a complete pre-trip inspection. If any system of the vehicle does not pass inspection, the error must be corrected before operating the vehicle.
Page 229 OPERATION Switch/Circuit Status Check The Switch/Circuit Status check tests the functionality of the switches and their corresponding circuits. To start the check the driver must turn the individual switches on/off. As the switches turn on/off, the cluster updates the DID to show switch option being tested and it’s status.
Page 230 OPERATION Exterior Light Inspection Check The Exterior Light Inspection check repeatedly turns all exterior lights on/off for the vehicle. This allows the operator to start the test, exit the vehicle and do a visual check that all exterior lighting is functioning properly. The following exterior lights are cycled through the check: •...
Page 231 OPERATION 2. The Test Started screen displays. You can stop the test by pressing ’ESC’ on the stalk or by starting the ignition. W3030325 Once the test is started all exterior lights flash on and off so that you can perform a visual check.
Page 232 OPERATION Air Leakage Check The Air Leakage check allows the driver to accurately measure the amount of air pressure drop in the front and rear brake air systems. After selecting this test from the DID, you are prompted to apply the service brake for 60 seconds. After applying and holding the service brake for 60 seconds, the DID will display the amount of pressure drop in the brake system.
Page 233 OPERATION If the air tanks are not full, in order to complete the air leakage test, the following screen displays. W3030327...
Page 234 OPERATION 2. When the system is ready to be checked, the following screen displays. Press Enter to begin the test. W3030328 Press and hold the brake pedal for 60 seconds. If the brake pedal is not pressed and held for 60 seconds the following warning screen displays.
Page 235 OPERATION 3. Once the brake pressure test is completed the pressure leak test results are displayed. W3030048...
Page 236 OPERATION Take your time going through the pre-trip inspection. Remember that a careful pre-trip inspection saves time by eliminating unscheduled stops for correcting a faulty item. The following information has been provided by the American Trucking Association as developed by the D.O.T. Office of Motor Carriers (BMCS). Pre-Trip Inspection Quick List W0001230 VN Shown VHD Similar...
Page 237 OPERATION Pre-Trip Inspection Quick List • Check under the vehicle for oil, fuel, coolant leaks or other signs of damage. • Check body surfaces for signs of breaks or damage. Preparation • Open drain cocks on air tanks to let the tanks drain. •...
Page 238 OPERATION Left Front Brake • Condition of brake drum. With brakes released, look for a noticeable gap between lining and drum. (This check cannot be made if dust covers are in place.) • Condition of brake air hose. • Check brake chamber mounting bolts and bracket. •...
Page 239 OPERATION Grille • Check that charge air cooler and radiator or bug screens are clean and undamaged. Step 3: Right Side of Cab Area Right Front Wheel • Check condition of wheel rim. Especially look for cracks, missing lockrings, bent or broken studs, clamps or lugs.
Page 240 OPERATION Under Hood, Right Side • Check condition of coolant and heater hoses. • Check condition of fan drive belts. • Check engine and surrounding areas for coolant, oil and fuel leaks. • Check fuel separator sight glass and drain if necessary. Check for leaks. •...
Page 241 OPERATION Step 5: Right Rear Vehicle Area Dual Wheels, One or Two Axles • Check condition of wheels and rims. Especially look for cracks, missing lock rings, bent or broken spacers, studs, clamps or lugs. • Check condition of tires: properly inflated, no serious cuts, bulges, tread wear or any signs of misalignment;...
Page 242 OPERATION Step 6: Rear of Vehicle Area Frame Area • Frame or cross members not bent, cracked or otherwise damaged or missing. • Check that air tubing and electrical lines are properly secured to the frame with no damage or chafing. Lights and Reflectors •...
Page 243 OPERATION Step 8: Left Saddle Tank and Left Rear Vehicle Wheels Area Dual Wheels, One or Two Axles • Check condition of wheels and rims. Especially look for cracks, missing lock rings, bent or broken spacers, studs, clamps or lugs. •...
Page 244 OPERATION • Frame and cross members: no bends, cracks or breaks. • Air tubing and electrical wiring: secured against snagging and chafing. Left Fuel Tank(s) • Securely mounted and not damaged or leaking. • Fuel lines secure and not leaking. Check that shut-off valves are open. •...
Page 245 OPERATION • Clean inside windshield, door windows and instruments. Clean mirrors. • Check temperature control and defroster. If equipped, check mirror heater. • Check condition of warning triangles, fire extinguisher and flares. • Adjust the seat. Check mirror adjustment. • Check safety belts for function and damage.
Page 246 OPERATION Lights and Reflectors • Trailer side clearance lights: clean, operating and proper color. • Reflectors clean and proper color. Frame and Body • Frame and cross members not bent, cracked, damaged or missing. • Proper placarding. • Body parts not damaged or missing. Step 11: Right Rear Trailer Wheel Dual Wheels, One or Two Axles •...
Page 247 OPERATION Brakes • Condition of brake drums. With brakes released, look for a noticeable gap between lining and drum. (This check cannot be made if dust covers are in place.) Condition of brake hoses: check for any chafing. Check brake chamber mounting bolts and brackets. Check slack adjusters and chamber push rod travel.
Page 248 OPERATION Brakes • Condition of brake drums. With brakes released, look for a noticeable gap between lining and drum. (This check cannot be made if dust covers are in place.) • Condition of brake hoses: check for any chafing. • Check brake chamber mounting bolts and brackets.
Page 249 OPERATION Step 13: Left Rear Trailer Wheels Area Dual Wheels, One or Two Axles • Check condition of wheels and rims. Especially look for cracks, lockrings missing, bent or broken spacers, studs, clamps or lugs. • Check condition of tires: properly inflated, no serious cuts, bulges, tread wear or any signs of misalignment;...
Page 250 OPERATION • Check slack adjusters and chamber push rod travel. With brakes applied or released, look for conspicuously different positions of the slack adjusters. • Check spring brakes. Step 14: Left Side of Trailer Area Landing Gear or Dolly Area •...
Page 251: Hood Operation
OPERATION HOOD OPERATION WARNING Avoid tilting the hood under high or gusty wind conditions. Failure to follow this recommendation may result in the hood unexpectedly closing, which can cause personal injury. WARNING Make sure that no one is in the way of the hood when opening or closing.
Page 252 OPERATION Opening the Hood The hood is locked down by two latches, one on each side of the back end of the hood The hood release handle is at the bottom of the steering column. Pull the lever as shown in the illustration to open the hood.
Page 253 OPERATION Make sure the hood can be opened fully without hitting anything. There are two methods for opening the hood. 1. Stand in front of the hood with feet in line with the vehicle. Place feet well apart and grasp the recessed handle in the front part of the hood. Transfer the body weight by leaning away from the hood.
Page 254 OPERATION 2. Stand at the rear fender edge on the driver side of the vehicle. Lift the hood from under the fender, push the hood forward, release the hood and let it complete the opening movement unaided. W8003546 Two restraint cylinders will engage during the last part of the opening. The cylinders will slow and dampen the hood down to its resting position.
Page 255 OPERATION Closing the Hood To close the hood, stand with feet well apart, place hands along the front edge of the hood. Bend the knees and let the leg muscles do the work when lifting. Raise the hood up to the halfway point. Carefully guide the hood down with enough speed that the hood latches lock the hood in place when it comes to its normal resting position.
Page 256 OPERATION Hood Latch (Optional) VNM 200 Day Cab, Short Fairing The VNM Day cab hood is opened by unlocking and releasing both sides of the latch located underneath the left and right-hand side panels. See illustration. W8003446...
Page 257 OPERATION CHASSIS FAIRING/STEPS OPEN AND LOCKED POSITIONS WARNING Always check security of fairing and steps before use. Ensure that the fairing is completely closed and the handles are in the locked position to prevent injury from slip and fall. The chassis fairing on the VN vehicle folds up and down for battery and air tank access. CAUTION DO NOT open fairing while the cab door is open.
Page 258 OPERATION W5001359 W5001358 Unlocked Position Locked Position...
Page 259 OPERATION Closing and Locking Fairing WARNING Make sure the fairing/steps are locked into position. Failure to lock fairing/steps could result in personal injury due to slip and fall. To close and lock the fairings: Use your fingers to pull the handles to the unlocked position (1) as indicated in the illustration.
Page 260 OPERATION Securing the Fairing/Step Make sure the handle is rotated to the locked position. Pull on the fairing/step to ensure the fairing/step is locked into position. See illustration. W8003196...
Page 261 OPERATION LUGGAGE COMPARTMENT WARNING Always place heavy objects in the luggage compartment. Sudden stops or sudden turns could cause personal injury if heavy objects fall from overhead storage shelves. To gain access to the luggage compartments, there is a pull-ring connected to the lock, located at the lower rear corner of the cab door opening, on each side (not shown).
Page 262 OPERATION The door swings out from the bottom on hinges mounted on the top. To assist in opening and to hold the door open, there are two compressed gas cylinders mounted on each door. The door will swing up by itself when pulled out a short distance and then released. Manually switch the luggage lamp ON.
Page 263 There is also a keyless remote entry available. Keys can be made to fit only one vehicle or all the vehicles in a fleet of Volvo vehicles. The key fits in the door lock either way. Insert the key and turn it 1/4 turn counterclockwise to unlock or clockwise to lock the door.
Page 264 OPERATION Note: The vehicle is delivered with two identical keys. If more keys are needed, order them through your authorized Volvo Truck dealer. The door locks are mechanically or electronically operated. The lock is activated by either the key from the outside or the door lock handle from the inside. With mechanical locks, only one door can be locked and unlocked at a time.
Page 265 OPERATION With electronic locks, to lock both doors from inside the cab, push the door lock handle forward on either door. The handle will stay in place, indicating the door is locked. Either door can be unlocked without opening the door by moving the door lock handle to the middle position.
Page 266 OPERATION W8003116 To close the door from the outside, place the hand flat against the door lock area and push the door shut. CAUTION DO NOT shut the door by pushing on the door panel. Hard pushing may distort the metal in the door panel.
Page 267 OPERATION Power Door Locks (Optional) Press button 2 to lock both doors or unlock the passenger door. In the event of a power failure the electrical lock system reverts back to a mechanical functioning system. W8003087 Central Locking The central locking is operated using a remote control. There is no alarm in this unit. The central locking unit provides a means for the driver to electronically control the vehicle’s door locks, for increased personal safety and driver comfort.
Page 268 OPERATION Heated Rear View Mirrors (Optional) Press button 1 once to start electric heating for 15minutes. The indicator light in the button flashes. The heating is on for 15minutes. Hold button 1 in for longer than 1second to start electric heating. The indicator light in the button comes on.
Page 269: Safety Belts
OPERATION Power Windows (Optional) Open Window (Auto-Down) Depress the down position (2) on the button for 1second. Release the button. The window opens. The window stops when it is completely open, when the down position (2) on the button is depressed again or when the up position (1) on the button is depressed.
Page 270 OPERATION Safety belt assemblies installed in this vehicle meet FMVSS 209, "Type 1" and "Type 2" requirements. They are recommended for all persons weighing over 25 kg (50 lb.). T8009149...
Page 271 OPERATION A child restraint system should also be provided for each child weighing 25 kg (50 lb.) or less. It should meet the requirements of FMVSS 213, "Child Restraint System." Carefully read and follow all manufacturer’s instructions on installation and use. Be certain the child remains in the restraint system at all times while the vehicle is in motion.
Page 272 OPERATION Operating the Safety Belt To fasten the safety belt, pull the belt out from the retractor and insert the latch into the buckle. Verify proper lock of the latch by pulling on the latch. Adjust the slack by pulling on the top part of the belt until the lower part, or the part that crosses the lap, is adjusted to fit "snug."...
Page 273 OPERATION The buckle portion of the safety belt system is different depending on the seat option chosen. The National Standard and Comfort seat has a separate buckle that is attached to a floor anchor by a seat strap. This seat strap is not adjustable, and does not need to be adjusted. Comfort Clip Operation When provided, the comfort clip is located on the shoulder strap just below the D-ring.
Page 274 OPERATION Always adjust the clip so that there is a maximum of 25 mm (1 inch) of slack between the belt and chest (about two fingers width). If a larger slack is allowed, the effectiveness of the safety belt is decreased in the event of a collision. W8001837...
Page 275 OPERATION Sleeper Safety Restraint DANGER Always use the safety restraint when the vehicle is in motion. Failure to do so not only may cause severe injuries or death to the passenger in the event of an accident, but also poses a danger of injuries to other occupants of the vehicle.
Page 276 OPERATION W8003171 Fasten the restraint by connecting the buckle with the latch. Make sure the belts are not twisted. Test the latch connection by pulling on the belt. If they come apart, reconnect and test again. If the connection cannot be made, replace the belt before using the bunk for sleeping during driving.
Page 277 OPERATION W8002475 Release Button...
Page 278: Safety Restraint Vn 430, Vn 630, Vn 670 And Vhd 430
OPERATION Safety Restraint VN 430, VN 630, VN 670 and VHD 430 The restraint has latches in one end and buckles in the other so it can only be installed one way. Connect the restraint to the back wall and the buckles on the floor. Connect the side tethers and adjust the straps to form a "tent"...
Page 279 OPERATION W8003169 Upper Bunk...
Page 280 OPERATION W8003170 Lower Bunk...
Page 281 OPERATION Safety Restraint VN 730 Connect the restraint to the back wall first. The wall connectors are located on the back wall. Connect the lower part of the restraint to the lower buckles. Connect the side tethers and adjust the straps to form a "tent" over the bunk. Note: The restraints for top and bottom bunks are different.
Page 282 OPERATION W8028593 42-Inch Lower Bunk...
Page 283 OPERATION W8028594 Upper Bunk...
Page 284 OPERATION Safety Restraint VN 780 Connect the restraint to the back wall first. The wall connectors are located in the storage units. Connect the lower part of the restraint to the lower buckles. Connect the side tethers and adjust the straps to form a "tent" over the bunk. Note: The restraints for top and bottom bunks are different.
Page 285 OPERATION W8003782 Upper Bunk...
Page 286 OPERATION Inspection DANGER Failure to properly inspect and maintain the safety belts can cause serious personal injury or death. DANGER It is critical that any time a vehicle has been involved in an accident, the entire safety belt system must be replaced in the vehicle (which also includes the sleeper bunk restraints) if they were in use at the time of the accident.
Page 287 OPERATION Check the belts, buckles, latch plates, retractors, anchorages, and guide loops to ensure that they are working properly. Look for loose/damaged parts (without disassembling) that could keep the restraint system from working properly. If the safety belt, retractor and hardware were in use during a collision, they must be replaced. The restraint system anchorage fasteners must be replaced if necessary.
Page 288 OPERATION The D-loop web guide is an area where almost constant movement of the safety belt webbing occurs because of the relative movement between the seat and the cab. This constant movement forms an area where wear will often occur. The webbing must be closely examined to determine if there are any cuts, fraying or extreme wear in the webbing.
Page 289 OPERATION Check the buckle by inserting the latch and verifying proper operation. Determine if the latch plate is worn or deformed. Check the buckle and latch casing for cracks or breakage. W8001404...
Page 290 OPERATION The retractor web storage device is mounted on the B-pillar, just behind the door in the cab. The retractor is the heart of the safety belt system and can be damaged if abused, even unintentionally. Check the retractor web storage device operation to ensure that it is not locked and that it spools out and retracts the webbing properly.
Page 291 OPERATION W8001387...
Page 292 Volvo original replacement safety belt. See your authorized Volvo Truck dealer for replacement. Your Volvo safety belt system has been developed and tested specifically for heavy trucks. Replace it only with the exact same design that the vehicle was equipped with.
Page 293: Seats, General
Several seats can be used in the vehicles. If the seat installed in the vehicle is not explained in this section, see your authorized Volvo dealer. Before adjusting or fastening the seat belt, move the seat forward or rearward and adjust the seat height as necessary.
Page 294: National Standard Seat
OPERATION NATIONAL STANDARD SEAT Seat Adjustments W8002745 National Standard Seat Backrest Tilt: By rotating the round handle, the backrest recline angle can be adjusted within 12 degrees. Cushion Front Tilt and Length: Pulling the handle up and out adjusts the tilt and length of the seat cushion.
Page 295: National Comfort Seat
OPERATION NATIONAL COMFORT SEAT ® Some National Comfort seats are equipped with a BackCycler feature. Some National Comfort seats have a swivel mount. Seat Adjustments W8002744 National Comfort Seat 1.Seat Adjustment 5.Lumbar Support Fore and Aft Adjustment 2.Isolator Lock 6.Recliner Tilt 3.Cushion Tilt 7.Armrest Angle 4.Ride Height...
Page 296 OPERATION Bostrom Comfort Seat Some Bostrom Comfort seats have a swivel mount. W8002744 National Comfort Seat 1.Seat Adjustment Fore and Aft 5.Ride Height Adjustment 2.Isolator Lock 6.Lumbar Support Adjustment 3.Dampening Adjustment 7.Recliner Tilt 4.Cushion Tilt 8.Armrest Angle Adjustment...
Page 297: Passenger Seats
OPERATION PASSENGER SEATS National Bench Seat The bench passenger seat has the option for a two-man storage seat. The base of the seat is a storage box that is accessed by lifting the seat cushion up. W8003482 National Bench Seat...
Page 298 OPERATION National Toolbox Seat The toolbox passenger seat has an optional accessible or non-accessible toolbox in the base of the seat. If the toolbox is an option, the storage box is accessed by lifting the seat cushion up. Note: There is a release latch behind the seat. W8003146 National Toolbox Seat...
Page 299 OPERATION Bostrom Toolbox Seat W8003851 Bostrom Toolbox Seat Seat Cushion Release Lever The toolbox passenger seat has an optional accessible or non-accessible toolbox in the base of the seat. If the toolbox is an option, the storage box is accessed by lifting the seat cushion up.
Page 300 OPERATION No Passenger Seat (Optional) WARNING Using a temporary passenger seating without the benefit of proper seat mounting and safety belt can, in the event of a loss of control of the vehicle, cause serious personal injury or death. In vehicles with no passenger seat installed, DO NOT let a passenger ride on temporary seating.
Page 301: Engine Operation
OPERATION ENGINE OPERATION General Proper operation, driving techniques and maintenance are key factors in obtaining the maximum life and economy from a modern turbocharged diesel engine. This section has operational information about the components that make up the engine. When changing gears, avoid lugging to extend engine life. When the engine is operating at full throttle and maximum governed speed cannot be reached or maintained, the engine is lugging.
Page 302: Immobilizer Feature
Exhaust vapor may be visible during a cold start. If exhaust smoke is visible during engine operation, this indicates a problem with the exhaust aftertreatment system. Take the vehicle to an authorized Volvo Truck dealer immediately. IMMOBILIZER FEATURE Volvo Engines Only The Immobilizer Feature is used to prevent the engine from starting.
Page 303 OPERATION If the vehicle has not been placed in the Immobilizer Mode during the previous key-off, the driver will be able to start the vehicle as normal. After the password is entered (at shutdown) "Security Mode Active" is displayed. W3006349...
Page 304: Control Awareness Feature
OPERATION CONTROL AWARENESS FEATURE VHD Vehicles and Volvo Engines Only Volvo engine and transmission. In addition, it provides a mechanical safety to the existing Power Take-Off (PTO) functionality. • Parameters are set in VCADS. If the vehicle exceeds the maximum vehicle speed for...
Page 305: Fuel Economy Driving
OPERATION FUEL ECONOMY DRIVING General The absolute fuel consumption (counted in liters per 100 kilometers or miles per US gallon) is determined by a large number of circumstances which can be related to one of the following main areas: • Build specification and equipment •...
Page 306 A modern heavy-duty vehicle requires regular and preventive maintenance to ensure that all its components function as they should. Use the recommended preventive maintenance (PM) program that Volvo Trucks North America has developed for the vehicles. This ensures optimal energy efficiency from all components that are important to fuel consumption.
Page 307 OPERATION Brakes Dragging brakes increase fuel consumption. They should be checked regularly. It is important that the release action of the air valves is fast and that the moving parts of the wheel brakes are checked for good adjustment and operation. Axles An axle out of alignment increases rolling resistance.
Page 308 OPERATION External Environment Under unfavorable conditions, the external environment can have a negative effect on fuel consumption. This can be broken down into two main groups: weather and wind, and the nature of the roads. Rain, snow, icy conditions and headwinds have a large negative impact on fuel economy, as do hilly roads and uneven road surfaces.
Page 309 Starting the Engine Start the engine according to the instructions in the operator’s manual of the engine manufacturer (for a Volvo engine, see "STARTING THE ENGINE" “STARTING THE ENGINE” page 329). A proper start, especially during the cold season, saves fuel and reduces engine wear.
Page 310 OPERATION Air Tanks All air tanks on the vehicle should be drained daily. Empty any moisture from air tanks by pulling the drain valve wire or by opening the drain cocks and allowing the air pressure to drain completely. Make sure the drain cocks close properly after draining. During draining the tanks should be checked for condensation fluid even if an automatic drain valve is installed.
Page 311 OPERATION Trucks with automated Meritor Transmission: Drain the transmission air supply tank located on the right-hand rail daily to check for contamination, water, oil, etc. Charging Air to Another Vehicle DANGER Before working on a vehicle, set the parking brakes, place the transmission in neutral, and block the wheels.
Page 312: Cruise Control
OPERATION CRUISE CONTROL DANGER DO NOT use the cruise control in heavy traffic, with ice/snow on the road or during other unfavorable conditions. This may lead to a loss of vehicle control, causing a vehicle crash, personal injury or death. W3002499 Engaging To engage and set desired speed:...
Page 313 OPERATION Note: The cruise control cannot be engaged at speeds below approximately 30 km/h (18 mph). Disengaging The cruise control is disengaged if the brake is depressed, or if the cruise control switch is set to OFF. If the ignition key is turned back to the accessories position (I), the cruise control system will automatically be disengaged.
Page 314: Volvo Engine Brake (I-Veb)
RESUME. Volvo Engine Brake (I-VEB) The Volvo Engine Brake (I-VEB) is standard on the Volvo 16F engine and optional on the 13F engine. It has a higher braking effect than the variable geometry turbo brake. When the engine brake is in the A position and cruise control is engaged, the engine brake automatically engages if vehicle speed exceeds the set cruise control speed.
Page 315: Brake Operation
OPERATION BRAKE OPERATION Brake Safety Information DANGER DO NOT inspect or adjust parts or components in the brake system without setting the parking brake, placing the transmission in neutral and securely chocking the wheels. If the vehicle is not secured to prevent uncontrolled vehicle movement, it could roll and cause severe personal injury or death.
Page 316 OPERATION DANGER DO NOT operate the vehicle when there is a malfunction in the compressed air system. An air brake system with leaks or other malfunctions may prevent the brake system from operating properly. The vehicle should not be operated until the system is repaired and all brake circuits are working properly.
Page 317 General All Volvo vehicles are designed to meet or exceed all applicable federal brake standards and regulations. They use a dual circuit, compressed air system. It consists of two independent brake systems that use a single set of brake controls. Each circuit is supplied by its own compressed air tank.
Page 318 OPERATION DANGER Never release or drive a truck that has a brake discrepancy — no matter how minor — until it has been repaired or corrected. Failure to repair brake discrepancies can result in compromised brake efficiency and may lead to loss of control of the vehicle resulting in severe personal injury or death.
Page 319 OPERATION W3006936 W3006937 Gauge 1 and Gauge 2 Before operating the vehicle, check the air gauges which indicate air pressure. They should not register less than 420 kPa (65 psi).
Page 320 OPERATION Both circuits are piped into a dual brake valve, which simultaneously applies front and rear axle service brakes during each brake application. In the event of a failure in either one of the circuits, the other circuit becomes the emergency circuit for applying the brakes. W5001486 Clutch Fluid Reservoir Windshield Washer Fluid Fill...
Page 321 OPERATION W3005171 Master Warning Tell-Tale An important feature of the brake system is that an automatic spring brake application does not take place as a result of an air loss in only one of the two circuits. In this case, brake control remains in the foot brake valve.
Page 322 OPERATION Foot Brake Valve The foot brake valve is directly connected to the brake pedal. The valve gives a progressive output against the pedal travel. This allows better control of the pressure in the first half of the pedal travel. In the last half of the pedal travel, the pressure output increase is faster. The foot brake valve applies the service brakes, incorporating both the primary and secondary air systems.
Page 323 OPERATION The best possible stop will be made when the first brake application is as firm as the speed and road condition permit. Then, ease off as the speed is reduced. Never apply the brakes lightly at first and increase the pressure as the speed diminishes.
Page 324: Parking Brake/Trailer Supply Valves
OPERATION Parking Brake/Trailer Supply Valves Trucks/Tractors may have two air control valves on the instrument panel: • Trailer Supply (red octagonal knob) • System Park (yellow diamond knob) W5001116 The System Park valve knob (yellow) should be pushed in first, after sufficient air pressure is built up (apply foot brake to prevent vehicle from rolling).
Page 325 OPERATION On vehicles equipped with the standard two valve system, the operation of one valve together with the other permits the operator to select the desired functions described below: Red Valve (Trailer Air Yellow Valve (System Park) Function (Mode) Supply) System Park Trailer Charge Normal Running...
Page 326 OPERATION There is also an engine shut-down device in the EECU that shuts down the engine after a pre-programmed time in order to save fuel. This is activated when the yellow parking brake knob is pulled out. Therefore, some drivers park and release the parking brakes using only the red knob to keep the engine running.
Page 327 OPERATION Spring Brake for Parking DANGER Never leave the vehicle without being certain the parking brakes are set or that other precautions are taken to prevent the vehicle from rolling. Failure to do so can result in serious personal injury or death. DANGER Before working on or inspecting a vehicle, set the parking brakes, place the...
Page 328 OPERATION W5001430 The parking brake spring tension is sufficient to hold a fully loaded vehicle on maximum grades permitted on modern highways, provided the brake drums and linings are in good condition and the brakes are properly adjusted. CAUTION DO NOT use the spring parking brakes if the service brakes are hot, such as after descending a steep grade.
Page 329 OPERATION If the brakes are wet, drive the vehicle in low gear and lightly apply the brakes to heat and dry them. Allow hot brakes to cool before using the parking spring brakes. There are several ways to determine if the parking brakes have been set. By pulling out the yellow knob: •...
Page 330: Trailer Brake Hand Control
OPERATION Trailer Brake Hand Control DANGER The trailer hand brake control is not a parking brake valve and must not be used as one. This brake is not designed to hold the vehicle stationary. Failure to follow these instructions can result in the unintentional movement of the vehicle and may cause personal injury or death.
Page 331 OPERATION W5001442 The "121" Brake Standard This manual refers occasionally to "121" brakes. Although some operators believe "121" only applies to vehicles equipped with anti-lock devices, the "121" standard applies to all vehicles that are capable of on-highway operation. The "121" is a Federal requirement also covering alterations or changes to parts or systems related to the "121"...
Page 332: Anti-Lock Braking System (Abs)
OPERATION ANTI-LOCK BRAKING SYSTEM (ABS) The vehicle has a standard brake system, equipped with an electronic speed monitoring and control system, Anti-lock Braking System (ABS). ABS monitors wheel speed continuously but is not involved in controlling the wheel speed unless there is an emergency. In normal braking applications, the standard air brake system is in effect.
Page 333 If any of the ABS tell-tales come on during driving or do not go out after a short time after turning on the ignition, take the vehicle to an authorized Volvo Truck dealer to repair the ABS or brake system. The vehicle can still be driven with a problem in the ABS system.
Page 334: Volvo Enhanced Stability Technology
OPERATION VOLVO ENHANCED STABILITY TECHNOLOGY Some vehicles are equipped with Volvo Enhanced Stability Technology (VEST). VEST is an advanced stability control system designed to provide both roll stability and under- and over-steer correction in a wide variety of driving conditions. VEST continuously monitors a variety of vehicle parameters and sensors (including steering angle sensor) to determine whether the vehicle is reaching critical stability threshold.
Page 335 OPERATION W3000962 The TCS includes a switch to turn off the function. When the switch is in the OFF position, the TCS operates normally to increase traction if the drive wheels begin spinning. When the switch is pressed once, the TCS tell-tale in the instrument cluster blinks continuously, indicating that the TCS is in mud/snow mode.
Page 336: Vehicle Speed Retarding Devices
Volvo Variable Geometry Turbo Brake The variable geometry turbo brake is standard with the Volvo 11F and 13F engine. It uses software to close the variable geometry turbocharger to create retardation. Note: For both variable geometry turbocharger and engine brakes, use a "one gear" driving strategy when going downhill to keep engine speed up for effective braking (for example: uphill in 7th gear and downhill in 6th).
Page 337: Transmission Retarder, Vhd Only
OPERATION Transmission Retarder, VHD Only DANGER DO NOT use the retarder on wet or slippery roads. The retarder may cause vehicle to slide and cause an accident which could result in injury or death. CAUTION Apply the retarder only when engine is at closed throttle.
Page 338 OPERATION Note: The retarder is automatically disabled when the ABS (anti-lock brake system) is active. The Transmission Retarder is an option with Allison HD and MD transmissions. It is activated by an on/off switch in the auxiliary panel and is controlled by a stalk switch mounted in front of the wiper switch.
Page 339: Starting The Engine
Note: For cold weather starting, see “COLD WEATHER OPERATION” page 340. These starting and operating procedures should be followed for all engines. For more detailed information about design and function on a non-Volvo engine, read the operator’s manual from the engine manufacturer.
Page 340 OPERATION W0001484 DANGER Never operate the starter without first placing the transmission in neutral or depressing the clutch pedal. Failure to follow these instructions may result in the unintentional movement of the vehicle resulting in property damage, personal injury or death.
Page 341 Refer to the Driver Information Display Manual. 5. Turn the key to the start position. Release key as soon as the engine has started. For the Volvo engine, the preheater can be engaged to help starting in cold temperatures. CAUTION...
Page 342 OPERATION W3006933 6. When the engine has started, it takes a while to send lubricating oil to all bearings and shafts, and between pistons and liners. Wait for the oil pressure gauge to settle at a normal level, then bring engine speed up gradually. Increase speed as it warms up. Check all gauges during warm-up.
Page 343 OPERATION Engine Overspeed This vehicle is equipped with a diesel engine and should not be operated in an area with a concentration of hydrocarbon vapors (for example gasoline or diesel fuel fumes). Be especially cautious of low-lying or closed-in areas. The vapors may be drawn into the engine through the air intake and cause the engine to overspeed.
Page 344 OPERATION Note: Avoid excessive idling. If the vehicle is parked for more than 5 minutes, stop the engine. An engine can burn from 3 to 5.5 liters (0.75 to 1.5 gallons) of fuel per hour while idling. During long engine idling periods, the engine coolant temperature may fall below the normal operating range.
Page 345 Move the cruise control switch to the RESUME position and hold it there for four seconds. Release the switch. The engine speed will drop to the default low idle (Volvo engines), or a slight drop in idle speed will occur (Cummins).
Page 346 Parking brake is applied (Volvo engines only). These are standard choices when the vehicle is delivered. For more information about other customer adaptation choices, contact your authorized Volvo Truck dealer. Uphill Operation For best performance, allow engine speed to reach the bottom of the rated torque range before downshifting.
Page 347 OPERATION Downhill Operation CAUTION DO NOT exceed engine manufacturer’s recommended maximum engine speed. Engine damage can occur. If equipped with an engine or exhaust brake, DO NOT exceed 2300 rpm. On a downgrade, do not coast with the clutch pedal depressed or the transmission in neutral. Select a gear that does not allow the engine speed to exceed the engine manufacturer’s maximum engine speed recommendation.
Page 348 OPERATION Stopping the Engine Allow the engine to slow down and idle for 3 to 5 minutes before shutting it off. This allows the turbo to slow down and the cooling system to dissipate the engine heat. Switch the engine off by turning the ignition key to the B, or OFF, position. CAUTION Shutting off an engine immediately after high speed or full load operation can...
Page 349 OPERATION The engine shut-down system will automatically derate or stop the engine when one or more of the systems listed below reaches a critical stage: • High Coolant Temperature • Low Oil Pressure • Low Coolant Level • High Crankcase Pressure •...
Page 350: Cold Weather Operation
OPERATION COLD WEATHER OPERATION Volvo Engine Cold Start Note: These cold start instructions are for Volvo engines only. For other engine makes, see the manufacturer’s handbook. DANGER DO NOT use ether or other combustible starting aids on any Volvo engine.
Page 351 (while still observing the 30 second maximum cranking time). Ether Start DANGER DO NOT use ether or other combustible starting aids on any Volvo engine. Introduction of ether or similar starting aids could cause a fire or explosion resulting in severe property damage,...
Page 352 Additions to the vehicle, such as heated fuel filters, fuel tank heater, engine block heater, winterfront, etc., can make winter operation easier. Contact your authorized Volvo Truck dealer for the correct accessories and information about installation. If satisfactory engine temperature is not maintained, increased engine wear will result in higher maintenance cost.
Page 353 OPERATION For cold weather operation, follow these recommendations: • When starting the engine in temperatures below ?15 C (5 F), use engine lubricants of lower viscosity. See the Operator’s Manual Vehicle Maintenance for additional information. • When the temperature is below freezing, make sure the concentration of antifreeze in the coolant is sufficient to prevent freezing.
Page 354 OPERATION Engine Block Heater (Optional) An electric engine block heater can be installed for keeping the coolant hot when the vehicle is parked. The heater is mounted through the side of the engine block with the heater coils in the coolant jacket. The heater does not interfere with normal operation and can be permanently installed.
Page 355 OPERATION Oil Pan Heater (Optional) Oil pan heaters aid low temperature starting by improving oil flow to critical parts in the engine. This helps prevent engine wear. They are similar to block heaters and are wired into the same plug as the engine coolant heater. Fuel Heater Filter (Optional) If running in very cold weather, a heated fuel filter should be added.
Page 356 Winterfront Volvo Trucks North America does not recommend the use of winterfronts, shutters or any other shield in front of the grille or radiator package under normal circumstances. Today’s electronically controlled engines are designed to operate in cold temperatures without a winterfront.
Page 357: Fifth Wheel Instructions
OPERATION Please see your authorized Volvo Truck dealer for Volvo recommended winterfronts. Note: If there is engine or related damage that can be traced to an improperly used winterfront, the warranty is no longer valid for those parts. FIFTH WHEEL INSTRUCTIONS...
Page 358 OPERATION If the fifth wheel is equipped with a sliding mounting, follow the advisory labels attached to the component. Also, read the literature provided by the manufacturer. DANGER Always keep the fifth wheel plate well lubricated to prevent binding between the tractor and trailer.
Page 359 OPERATION W9000242 Open — This is the position the fifth wheel is in after the trailer is uncoupled. The jaw is open and the operating rod is now dropped down and can be freely moved around. The safety latch is rotated toward the rear of the fifth wheel. This is the position the fifth wheel must be in when being coupled to a trailer.
Page 360 OPERATION Fifth Wheel Slider (Optional) Open — This is the position the fifth wheel is in after the trailer is uncoupled. The jaw is open and the operating rod is now dropped down and can be freely moved around. The safety latch is rotated toward the rear of the fifth wheel.
Page 361 OPERATION Unlocking the Fifth Wheel Always check out the entire fifth wheel before attempting to couple to a trailer (ASF fifth wheel is shown). • If not lubricated properly, add grease to the top of the fifth wheel plate. • Make sure the mounting of the fifth wheel to the frame is tight and in good condition.
Page 362 OPERATION Using a slight upward motion, pull the operating rod out until the operating rod shoulder is outside the fifth wheel operating slot. W9000202 When the shoulder of the operating rod is outside of the operating slot, raise the operating rod handle to its maximum upward position.
Page 363 OPERATION Release the operating rod. The upper shoulder of the operating rod should now be in contact with the plate casting above the operating slot. The fifth wheel is now in the lockset position and a trailer can be coupled. W9000274 Trailer Coupling Procedures DANGER...
Page 364 OPERATION Using the following procedures, inspect the equipment before coupling to a trailer: Make sure the fifth wheel is properly lubricated and the jaw is in the open position. W9000659 WARNING If the jaw is not in the open position, use a pry bar to rotate the jaw to the open position.
Page 365 OPERATION W9000660 Make sure the plate is tilted downward to the proper position at the rear. W9000236 Make sure the mounting of the fifth wheel to the tractor frame is tight and in good condition. Make sure the plate is tilted downward to the proper position at the rear.
Page 366 OPERATION If using a sliding fifth wheel, make sure the slide locking plungers are fully engaged. W9000205 Chock the trailer wheels. Use two chocks (both on the front and rear of the wheel) on both sides of the trailer. Back up close to the trailer, centering the kingpin on the throat of the fifth wheel, and STOP. Note: For tractors with air ride suspension, make sure the suspension control switch is in the "RIDE"...
Page 367 OPERATION W3001341 Connect the air brake lines and the electrical power cord. Make sure that any slack in the lines is supported so that the brake lines do not become entangled. Set the trailer brakes by pulling out the Trailer Supply control on the dashboard. W3005321...
Page 368 OPERATION CAUTION Attempting to couple with the trailer at an improper height could result in a false or improper couple and cause damage to the tractor, fifth wheel and trailer. Check to see that the trailer is at the proper height for coupling. The leading edge of the trailer plate should initially contact the fifth wheel top plate surface about 200 mm (8 in.) behind the pivot point as the tractor backs under the trailer.
Page 369 OPERATION As an initial check, pull forward to test the completeness of the coupling. W9000237 A direct visual check is required to ensure proper coupling. Several types of improper couplings will pass the initial pull test. Sound is not reliable. Do not take for granted that you are properly coupled.
Page 370 OPERATION Make sure the trailer kingpin is in the jaw slot and that the jaw is closed behind the pin. The kingpin should not overhang the fifth wheel or be caught in the grease groove. To verify that the kingpin is actually in the fifth wheel slot and the jaw is closed, the pin must be visually inspected from the rear.
Page 371 OPERATION W9000240 Make sure the operating rod is fully retracted, the safety latch is positioned above the handle, and the latch swings freely. If the fifth wheel is equipped with a manual secondary lock, check to see that it is properly engaged.
Page 372 OPERATION W9000180 Check the kingpin to fifth wheel clearance by moving the tractor backward and forward with the trailer brakes set. If the clearance appears excessive (more than 3 mm [1/8 in.]), or if the jaw does not lock, the fifth wheel should be inspected by a qualified technician before proceeding.
Page 373 OPERATION Trailer Uncoupling Procedures For Tractors With Air Ride Suspension Set the system park brake on the tractor. Set the trailer brakes by pulling out the trailer air supply knob. W5001433 Chock the trailer wheels. Use two chocks (one on the front and one on the rear of the wheel) on both sides of the trailer.
Page 374 OPERATION Disconnect the light cord and air brake lines. Use the dummy air couplings to keep foreign material from entering the brake lines. Unlock the fifth wheel. Note: If the operating rod is too difficult to pull, back the tractor up slightly to relieve any kingpin load against the fifth wheel jaw.
Page 375 OPERATION W9000239 Select the "UNCOUPLE" position (push down the latch and press in the bottom part of the switch) on the suspension control switch to deflate the air springs. W3006386...
Page 376 OPERATION Wait about 30 seconds for the air springs to deflate. W9000238 With the suspension lowered, pull clear of the trailer and immediately select the "RIDE" position (press the top part of the switch in) on the suspension control. This restores the suspension to operating height.
Page 377 OPERATION After the trailer is uncoupled, the fifth wheel will be in the open position. The operating rod will drop and can be moved around freely. W9000203...
Page 378: Operating The Fifth Wheel Slider
OPERATION Operating the Fifth Wheel Slider CAUTION The trailer must be stopped and the trailer brakes locked, or damage to the tractor and/or trailer may result from uncontrolled sliding of the fifth wheel. Stop the tractor and trailer in a straight line on level ground. Lock the trailer brakes by pulling out the Trailer Supply knob.
Page 379 OPERATION W9000205 Slowly drive the tractor forward or backward to position the fifth wheel. After sliding the fifth wheel to the desired position, engage the slide locking plungers by moving the cab switch to the "LOCK" position (press in the top part of the switch). W3001346...
Page 380 OPERATION CAUTION DO NOT operate the vehicle if the plungers are not fully engaged and the trailer landing gear is not fully retracted. Doing so may cause damage to the tractor, trailer and landing gear. Visually check to see that the slide plungers are fully engaged. It may be necessary to leave the trailer brakes locked and to move the tractor slightly to engage the slide plungers into the rail.
Page 381 OPERATION Clutch General DANGER Before starting the engine, set the parking brakes and place the transmission in neutral. Failure to do so can result in unexpected vehicle movement and can cause serious personal injury and death. DO NOT allow the clutch to slip excessively. This would cause excessive heat to be generated and the clutch will be damaged and bring on premature failure.
Page 382: Performance Bonus Feature
The reward of higher RSL increases driver productivity and income. It also promotes increased driver and fuel efficiency. To obtain more information about the Performance Bonus Feature, contact your Volvo dealer. Note: The Performance Bonus Feature is programmable (by your dealer) using VCADS Pro or VCADS Pro Elite.
Page 383 OPERATION Rolling Buffer The "rolling buffer" is set to measure distance driven. The buffer may be set at a short or long distance. A short buffer results in a faster reward, (or loss of reward) which provides driving fuel economy training to the driver, permitting the driver easy memory of the input to the buffer during this short period of time.
Page 384: Performance Bonus Guide
OPERATION W3028721 Performance Bonus Guide Volvo Engines Only The Performance Bonus Guide is an aid that provides comprehensive feedback to the driver about the optimum engine operating range during a trip. If adhered to, this results in improved fuel efficiency. Icons in the Driver Information Display (DID) guide drivers to the most efficient engine operating range for any given engine load and speed.
Page 385 OPERATION Status Meaning Symbols Engine Operating in the Sweet Spot Mode. Fuel consumed in this mode will count 100% toward the Sweet Spot Percentage. W3006755 Engine Operating in a less efficient area of the Sweet Spot Mode. Fuel consumed in this mode will count 50% toward the Sweet Spot Percentage. W3028749 Decrease Engine Speed W3006756...
Page 386 OPERATION Symbol Meaning Performance Bonus Guide (shows Sweet Spot Percentage [Large Symbol]) W3006755 Driving Mode The Sweet Spot Status icons are displayed at the bottom left of the DID screen. The Sweet Spot symbol is displayed at the top of the screen underneath Fuel Data. The Sweet Spot percentage page is displayed in the Fuel Data menu.
Page 387 DID also displays the Sweet Spot target percentage in parenthesis. W3028762 The Performance Bonus Guide is a standard feature for all Volvo engines on vehicles equipped with the mid or high level instrument cluster. Performance Bonus does not work with the basic instrument cluster.
Page 388: Axles
OPERATION AXLES Differential Locks DANGER DO NOT drive on dry, paved surface with the differential locks engaged. The vehicle will strive to maintain a straight line. Taking a curve with the differential locks engaged may cause an accident, leading to serious personal injury or death.
Page 389 OPERATION W3001991 The differential lock should be used on icy or slippery surfaces. As soon as the slippery surface has been passed, the differential lock should be disengaged. Differential locks must not, under any circumstances, be engaged when in a wheel-spin situation.
Page 390 OPERATION Auxiliary Lift Axle VHD DANGER Before raising or lowering any of the auxiliary axles, be certain no one can be trapped by the axle movement. Failure to do so can result in a person being trapped between the wheel and the body, or between the wheel and the ground, resulting in serious personal injury or death.
Page 391 OPERATION CAUTION DO NOT rely on gauges to determine axle pressure. Weight must be verified on scales, and pressure in the air springs should then be adjusted accordingly. Regulators for adjusting the air spring pressure are located on the outside of the cab, below the rear corner of the driver side door.
Page 392: Diesel Particulate Filters (If Equipped)
Catalyzed Diesel Particulate Filters (DPF) (If Equipped) Note: The following exhaust Aftertreatment system information applies to Volvo vehicles equipped with a Volvo or Cummins engine and a catalyzed DPF. This vehicle is equipped with a 2007 emission compliant engine and an exhaust Aftertreatment system which includes a Diesel Particulate Filter (DPF).
Page 393 OPERATION DANGER Exhaust gases and components can be at extremely high temperatures during regeneration. When parking the vehicle, keep away from people, any flammable materials, vapors, or structures. Serious personal injury may result. DANGER The temperature of the exhaust system components during the regeneration process can exceed 350 C (662 F).
Page 394 OPERATION CAUTION Use of diesel fuel other than ULSD and engine oils other than VDS-4 or EO-O Premium Plus, will adversely affect performance, efficiency and durability of the DPF system and the engine, to the point where the engine may not run at all.
Page 395 OPERATION Aftertreatment icons are displayed on the instrument cluster. There are two Aftertreatment icons: • DPF Regeneration required • High Exhaust System Temperature (HEST) The Aftertreatment icons are located in the lower left corner of the instrument cluster. W3007526...
Page 396 OPERATION The Aftertreatment system is self-monitoring. When the diesel particulate filter is becoming full and regeneration is needed, the DPF Regeneration Required icon on the instrument cluster illuminates and the message "REGEN In Process, Enter to Delay" is displayed. Maintain uninterrupted highway speed for an automatic regeneration. To delay the regeneration process, if necessary, press Enter on the stalk switch.
Page 397 OPERATION If the regeneration process is delayed, the message "REGEN Cancelled" is displayed for a short time. The DPF Regeneration Required icon will remain illuminated and the message "Parked REGEN Required" is displayed. To return to the main menu, press ESC on the stalk switch.
Page 398 Regenerations that are stopped and never restarted at a later time, however, will require that the vehicle be taken to an authorized Volvo Truck dealer to have the regeneration manually started with special service tools.
Page 399 OPERATION The Aftertreatment menu in the Drive Information Display (DID) has three submenus: request parked DPF Regeneration, check Aftertreatment status and cancel DPF regeneration. W3007436...
Page 400 Note: It is important to enable regeneration as soon as possible to avoid engine problems. Long term engine operation with regeneration disabled will result in a loss of engine performance including horsepower, torque, speed and temperature derates. Also, the DPF filter will become overloaded with soot and require service at an authorized Volvo dealer.
Page 401 OPERATION The regeneration process can be stopped at any time by turning the ignition key to OFF, or, scrolling to the Aftertreatment menu in the Drive Information Display (DID) and selecting "Cancel REGEN", or by pressing Enter on the stalk switch. W3007436 Note: If regeneration occurs during vehicle operation, idle speed may increase when the vehicle is stopped at a traffic light to maintain proper regeneration conditions.
Page 402 If the DPF Regeneration Required icon is flashing and the STOP light illuminates, a serious engine problem has occurred. The diesel particulate filter may be over its maximum capacity and the engine may shut down. The vehicle must be taken to an authorized Volvo Truck dealer immediately for service.
Page 403 OPERATION If a request for manual regeneration fails, "REGEN Failed Check Menu Status" is displayed. Scroll to the Aftertreatment menu in the Drive Information Display (DID) and select "ATS Status" to determine why the regeneration failed. W3007452 WARNING For chassis equipped with a heated-dump body, be aware the temperature around the area where the exhaust enters the body as well as the product contained in the...
Page 404 The system will time-out if the duty cycle is inadequate to support an automatic regeneration or if there is a problem that is preventing regeneration. Attempt to perform a parked regeneration or take the vehicle to a Volvo Truck dealer for a service regeneration. T0015429...
Page 405 Temporary lockout prevents performing a regeneration when a regeneration is not needed. Permanent lockout prevents performing a regeneration when a condition exists that requires vehicle service. Take the vehicle to a Volvo Truck dealer. A minimum engine temperature of 35 C (95 F) is required for regeneration.
Page 406 OPERATION To perform a parked regeneration, the accelerator pedal must not be depressed, the transmission must be in the neutral position and the vehicle speed must not be above zero. T0015433 A minimum exhaust temperature of 250 C (482 F) is required for regeneration. The minimum vehicle speed for an automatic regeneration is 40 km/h (25 mph).
Page 407 OPERATION Refer to the Emission System Instructions sun visor label for additional DPF information. For additional information about the Aftertreatment menu, refer to the Driver Information Display manual. W2006276...
Page 408 OPERATION Extended Idling and Aftertreatment System Conditioning (Periodic Heat Mode) Extended idling performed on this vehicle equipped with an exhaust aftertreatment system should be carried out at a low engine idle speed. There is no benefit to using a raised engine idle speed for extended idling.
Page 409: Maintenance And Lubrication
Note: Make sure that all fluid levels are at their proper levels. If the fluids are not at their proper levels, add as necessary. Refer to the Operator’s Manual Vehicle Maintenance for information on what types of fluids are recommended for your Volvo vehicle. WARNING Keep yourself clear of all moving or hot engine parts.
Page 410: Towing Procedure
MAINTENANCE AND LUBRICATION TOWING PROCEDURE General WARNING If a vehicle with air suspension is lifted by the rear frame member, there is a risk that the air springs will separate from the spring plates. When towing has been completed, DO NOT under any circumstances use your hands to reposition the air springs.
Page 411 MAINTENANCE AND LUBRICATION Remove the driveshaft from the rear axle before moving the vehicle, unless it only needs to be moved a small distance for safety reasons. When the transmission is driven from the rear wheels without the engine running, there is no lubrication in the transmission. Axle shafts must be removed if the vehicle is to be towed at speeds over 40 km/h (25 mph) or for a long distance.
Page 412 MAINTENANCE AND LUBRICATION Towing Instructions DANGER DO NOT use the tow eyes for raising the front of the vehicle; the tow eyes can break. DO NOT crawl under a vehicle suspended by tow eyes. Failure to follow these instructions can result in serious personal injury or death.
Page 413 MAINTENANCE AND LUBRICATION CAUTION If the vehicle becomes disabled, it is very important to tow it properly. Failure to do so can cause damage to the frame and body parts. Follow the instructions below to avoid damage. In the event that the vehicle cannot be reached to place the wrecker lift bar under the front axle, use the optional tow eyes.
Page 414 MAINTENANCE AND LUBRICATION The tow eyes are held in place when mounted on the front of the vehicle by tractor pins. These pins are stored in the tow eye mounting holes when not being used. If the vehicle is equipped with the optional rock guard installed, insert the lock pin into the tow hook from the opposite side during installation.
Page 415 MAINTENANCE AND LUBRICATION If the vehicle is equipped with the optional rock/stone guard installed, the driver will have to insert the lock pin into the tow hook from the opposite side during installation. W9000751 When the vehicle is located properly, lift the front and locate the lift bar under the front axle and secure.
Page 416 Note: If your vehicle is equipped with a pintle hook system installed by Volvo Trucks North America, please note that the entire pintle hook system — including the frame and...
Page 417 MAINTENANCE AND LUBRICATION W7001269 Pintle Hook Advisory Label Acceptable loads per hook: • Straight pull: Less than or equal to 18 143 kg/hook (40,000 lb). • Vertical pull: Less than or equal to 5 170 kg/hook (11,400 lb). • 45 cone (combination loads): Less than or equal to 7239 kg (15,960 lb).
Page 418: Caging Spring Brake Chambers
MAINTENANCE AND LUBRICATION Caging Spring Brake Chambers DANGER Always start by chocking the wheels to prevent the vehicle from rolling. Failure to do so can result in unexpected vehicle movement and serious personal injury or death can occur. DANGER DO NOT attempt in any way to disassemble or tamper with the spring brake chamber.
Page 419 MAINTENANCE AND LUBRICATION ® Towing Procedure — AIRTEK W5001430 Suspension ® HENDRICKSON recommends that a vehicle equipped with a STEERTEK axle be towed using the following methods for ON HIGHWAY or ON ROADWAY applications. Methods listed are in order of preference. Wheel lift method, the ideal towing procedure Axle fork method Towing vehicle from the rear method...
Page 420 MAINTENANCE AND LUBRICATION ® Please contact HENDRICKSON Tech. Services with any questions regarding proper towing procedures for vehicles equipped with a STEERTEK axle. Wheel Lift Method This method provides the greatest ease for towing the vehicle. Lifting at the tires helps reduce the risk of possible damage to the axle, suspension, and engine components during towing operations.
Page 421 MAINTENANCE AND LUBRICATION CAUTION DO NOT tow the vehicle from the axle. Towing the vehicle by the axle will cause scarring and resultant damage to the axle and void warranty. When lifting a vehicle with an under lift boom, care must be taken not to damage the engine’s oil pan.
Page 422 MAINTENANCE AND LUBRICATION Towing Vehicle From Rear Method W7001301 This method is preferred when the proper equipment is not available to perform the wheel lift method or the axle fork method, and is necessary for wreckers not equipped with an under lift system. Spring Eye and Hanger Lift Method This method is permitted for under lift equipped units.
Page 423 MAINTENANCE AND LUBRICATION Off Roadway Towing Method WARNING When a truck is disabled and equipped with a STEERTEK axle, care must be taken to ensure there is no damage to the suspension when towing the vehicle. The use of a tow strap is necessary to tow a disabled truck into a repair facility.
Page 424 MAINTENANCE AND LUBRICATION THE FOLLOWING METHODS IN THESE ILLUSTRATIONS ARE NOT RECOMMENDED FOR ON HIGHWAY TOWING W7001303 Nylon straps are acceptable for only Off roadway towing.
Page 425 MAINTENANCE AND LUBRICATION W7001304 Chains are not acceptable for Off roadway towing.
Page 426: Engine Oil Level Check
DO NOT overfill! To add oil to the engine, remove cap from right-side oil fill and fill through the hole. See the Operator’s Manual Vehicle Maintenance for correct types of oil used in Volvo engines. W0002105...
Page 427 MAINTENANCE AND LUBRICATION Clutch Fluid Check Check the fluid level in the clutch fluid reservoir. The fluid level should be between the level marks on the reservoir. If fluid needs to be added, use brake fluid, DOT 4. W4002567 Clutch Fluid Reservoir Windshield Washer Fluid Fill Brake Valve...
Page 428: Power Steering, General
MAINTENANCE AND LUBRICATION POWER STEERING, GENERAL The VN power steering consists of an integrated gear. The VHD vehicle has both the integrated gear and the hydraulic power cylinder. There is also a power steering pump with fluid container. The pump, driven by the engine, provides hydraulic pressure to the power steering.
Page 429 MAINTENANCE AND LUBRICATION Windshield Washer Reservoir Check level in the windshield washer reservoir. If washer fluid needs to be added, use a commercially reputable washer fluid that has good cleaning capability and does not freeze in cold weather. Windshield Washer Capacity Model Reserve Total Capacity...
Page 430 MAINTENANCE AND LUBRICATION VN: An indicator will appear in the Driver Information Display (DID) screen when there is approximately 6.35 liters (1.5 gallons) remaining in the reservoir. VHD: An indicator will appear in the DID screen when there is approximately 3.875 liters (0.9 gallons) remaining in the reservoir.
Page 431 MAINTENANCE AND LUBRICATION CAUTION Diesel-powered engines for heavy-duty trucks built on or after January 1, 2007 are designed to operate only with Ultra Low Sulfur Diesel (ULSD) fuel. Improper fuel use will reduce the efficiency and durability of engines, permanently damage advanced emissions control systems, reduce fuel economy and possibly prevent the vehicles from running at all.
Page 432: Cooling System
MAINTENANCE AND LUBRICATION COOLING SYSTEM Coolant Level Check WARNING DO NOT remove the cap to the surge tank while the engine and radiator are still hot and under pressure. Scalding fluid and/or steam may be blown out under pressure if the cap is taken off too soon.
Page 433: Cab Air Filters
MAINTENANCE AND LUBRICATION CAB AIR FILTERS Air going into the cab passes a filter located on the right, front side of the cab. Remove the filter and check it every 19,200 km (12,000 miles). W8003189 The filter should not be cleaned and reused. Replace with a new filter as necessary. Change the filter more often if driving in dusty conditions.
Page 434: Headlights
MAINTENANCE AND LUBRICATION HEADLIGHTS Changing Headlight Bulb Note: To prevent short service life, DO NOT touch the glass surface of the replacement bulb. VNM Instructions The headlight bulb can be accessed from the rear of the headlight assembly. Raise the hood and remove the cover.
Page 435 MAINTENANCE AND LUBRICATION Install the bulb and line up with the location tab by turning it and then push it in until fully seated. Install the lock ring. Push the terminal back on. Check that the rubber seal is clean and then install cover and snap the clamps over it.
Page 436 Note: In some cases, the cover seal may stick to the housing, which makes removal difficult. Use special tool 85104355 to assist in removal. Contact your authorized Volvo dealer for the tool. With the cover removed, grasp the bulb assembly and turn counterclockwise to remove.
Page 437: Roof Extender
MAINTENANCE AND LUBRICATION ROOF EXTENDER The roof extender increases fuel economy. The extender is adjustable to five positions which are shown in the illustration and in the graphs. The vehicle is delivered with the extender or deflector lowered or down, which is the transport position, see A in illustration.
Page 438 MAINTENANCE AND LUBRICATION Note: For 630 and 670 vehicle models, the frame height must be measured. See F in illustration. If F measures 266 mm (10-1/2 inches), subtract 17 mm (5/8-inch) from the value determined for H. W8003466 VN Roof Extender Measurements W8003472 VN 630/670 Roof Extender Adjustment Chart...
Page 439 MAINTENANCE AND LUBRICATION W8003473 VN 630/670 Roof Extender Adjustment Chart...
Page 440: Front Bumper/License Plate Mounting
MAINTENANCE AND LUBRICATION FRONT BUMPER/LICENSE PLATE MOUNTING CAUTION DO NOT cover the opening in the front bumper with a license plate. Covering this hole will restrict airflow to the lower portion of the radiator. This can cause the engine to overheat, which can damage the engine.
Page 441 MAINTENANCE AND LUBRICATION Multiple License Plate Mounting Install multiple license plates as shown. W8003370...
Page 442 MAINTENANCE AND LUBRICATION VORAD License Plate Mounting Install multiple license plates as shown. W8003371 Fig. 3: VN Install license plates below this edge.
Page 443: Modifications To Vehicle
W7001277 Drilling is permitted in the frame web in accordance with a specified hole spacing pattern. Consult an authorized Volvo Truck dealer to obtain approved hole spacing dimensions or refer to the Frame Rail and Cross Member Service Manual.
Page 444 MAINTENANCE AND LUBRICATION Frame rail and cross member nuts and bolts should be checked periodically and tightened to the specified torque if necessary. Frame Alterations Under no circumstances can the frame be cut and an extension piece added to increase the wheelbase.
Page 445: Wheels
General Due to the size, equipment needed and the procedures used to change wheels, this should be done through the Volvo Truck dealer. By having an expert technician perform this procedure, personal injury and property damage may be avoided. Note: When replacing the wheel equipment or tires, use the same size wheels or tires as originally manufactured.
Page 446 MAINTENANCE AND LUBRICATION W7001270 Inflating Tires DANGER Tires and wheels must be serviced only by a qualified technician. DO NOT attempt to perform this work yourself. Inflated tires on wheels contain compressed air and if suddenly released, do so with an explosive force.
Page 447 MAINTENANCE AND LUBRICATION W2002684 For specific information and warranty on rims and tires, contact the tire manufacturer’s distributor. Check tires for abnormal wear. Also, check the tread depth. Wheel Bearing Adjustment DANGER Failure to keep wheel bearings properly adjusted may result in accelerated tire wear, poor handling and, in extreme cases, wheel separation from the hub or from the spindle.
Page 448 For reliable operation and adequate service life, the wheel bearings must be properly adjusted and checked during the service period. Loose wheel bearings could cause premature tire wear and possibly affect vehicle handling. See your authorized Volvo Truck dealer for proper servicing.
Page 449: Battery
MAINTENANCE AND LUBRICATION BATTERY Battery Box Access for Jump Start DANGER When inspecting or cleaning batteries, never smoke or expose batteries (or the areas around them) to spark or flames. The battery area may contain an explosive gas mixture that can ignite, causing an explosion, leading to serious personal injury or death.
Page 450 MAINTENANCE AND LUBRICATION W3006385 DANGER When installing the battery cover, make sure it is resting properly on the box before fastening the latches. Faulty installation may cause the cover to shift when the steps are used, which may lead to a fall, causing serious personal injury or death.
Page 451 MAINTENANCE AND LUBRICATION The battery cover may also be a base for the cab steps. To remove the cover, unhook the two rubber latches and lift the cover up and out. This applies to the vehicle models without fairings, and the VHD vehicle. W3005334...
Page 452 MAINTENANCE AND LUBRICATION The VHD vehicle has two styles of battery boxes available. One is covered with a plastic cover, the other cover is made of chromed diamond plated steel. W3005504 There may be up to four batteries installed. Always make sure the batteries are fastened properly in the box.
Page 453 MAINTENANCE AND LUBRICATION Battery Jump Starting and Charging DANGER DO NOT attempt to jump-start a vehicle equipped with Delco Maintenance Free batteries if the test indicator is light yellow. Replace the battery instead. Jump-starting may cause battery to explode causing skin burns from acid or serious personal injury or death.
Page 454 MAINTENANCE AND LUBRICATION W3005322 Connect the jumper cables in the following sequence: • Good battery positive, • Dead battery positive, • Dead battery negative, • Disconnect the cables in the reverse order. Avoid creating sparks by making all connections quickly and firmly. DO NOT permit vehicles to touch each other when jump starting.
Page 455 DO NOT work on the electrical system without the proper tools and training. Repair work to the electrical system must always be done by trained professionals. Your Volvo Truck dealer has the right tools and trained technicians.
Page 456 MAINTENANCE AND LUBRICATION Battery, Low State of Charge If the batteries are discharged to the point where they do not have enough stored energy to start the engine, they should be recharged using a low charge current, not to exceed 14.5 to 15.0 volts.
Page 457 MAINTENANCE AND LUBRICATION CAUTION If there are other ground cables connected to the battery (such as engine ECU, transmission ECU, etc.), disconnect those wires in the sequence shown, then remove the main battery ground cable. Electronic modules may be damaged when their ground(s) are connected/disconnected with the main battery ground disconnected.
Page 458 MAINTENANCE AND LUBRICATION The vehicle is equipped with systems that have their own electronics, including vehicle ECU (VECU), ABS, air bag (SRS), gauge cluster and some transmissions. Disconnect each ECU at its electrical connectors. W8003198 Disconnect the power harness (engine electronic control unit [EECU]) and vehicle interface harness at the battery.
Page 459 MAINTENANCE AND LUBRICATION Reposition or shield any parts that would be damaged by high temperatures during welding. W8003200 Complete the battery cable removal by removing the positive cable last. • Attach the welder ground cable as close to the weld area as possible (6 inches or less from the place being welded).
Page 460: Battery Voltage Protection System
MAINTENANCE AND LUBRICATION Battery Voltage Protection System The vehicle is equipped with a battery protection system. The vehicle detects when the batteries are excessively discharged and will flash the indication light and sound an audible alarm. Should the battery voltage remain low for an additional 30 seconds the indication light and alarm rate increases (fast flash).
Page 461 MAINTENANCE AND LUBRICATION W3030711 Battery Protection Data Flow from Note: Pressing the fan speed button over rides for approximately 10 minutes, enabling all loads. When the batteries are charged, either through the vehicle alternator or a connected battery charger, the monitor will automatically restore power to the disconnected circuits. Unless the batteries are held at an elevated voltage for several hours, they will only develop a "surface"...
Page 462 MAINTENANCE AND LUBRICATION W3030520 In situations where there is a short or overcurrent (over 100 Amps), the battery voltage protection system will initiate a different audible and visual alarm. The alarms are activated at a series of three 30 second intervals. If the short or overcurrent situation is not resolved by the final alarm series, the LVD shuts down in order to protect the vehicle lectrical system.
Page 463: Electrical
MAINTENANCE AND LUBRICATION ELECTRICAL General Safety Guidelines WARNING Failure to repair a malfunction in the electrical system can result in serious damage due to vehicle fire. Always let an experienced electrical technician perform repairs. Always determine the source of the fault; do not just treat the symptoms. WARNING Always wear eye protection when working around batteries to prevent the...
Page 464 MAINTENANCE AND LUBRICATION CAUTION Attempting to work on electronic components without proper equipment can damage internal parts with static electricity. CAUTION Today’s vehicles contain a high number of electronic devices. It is very important to exercise caution when working on a modern electrical system, charging batteries or jump starting the engine.
Page 465 Repair work to the electrical system must be done by trained professionals. Your authorized Volvo Truck dealer has the right tools and trained technicians. Charging System An alternator with an integrated regulator is used to supply power to the vehicle electrical system.
Page 466 MAINTENANCE AND LUBRICATION Electrical Center WARNING Failure to repair a malfunction in the electrical system may result in a vehicle fire and personal injury. WARNING Always replace fuses and circuit breakers with the same current/amperage rating. Using larger fuse or circuit breaker ratings may result in electrical circuit overheating and possibly fire.
Page 467 MAINTENANCE AND LUBRICATION The cover panels are fastened with screws. Most relays and fuses are accessible from under the top cover. Since the function of some fuses or relays may change for the vehicle application, refer to the list of functions that is attached beneath each panel. W3007220...
Page 468 MAINTENANCE AND LUBRICATION W3007221 VHD Fuse and Relay Center Additional relays are located in the left-hand luggage compartment, attached to the sleeper harness. Note: These relays have limited optional sleeper functions.
Page 469 MAINTENANCE AND LUBRICATION Additional fuses are located in the Sleeper Control Panel. W3007222 Sleeper Control Panel Fuses Fuses are standard. Reset breakers are available as an option for some circuits. If a fuse continues to blow or disconnect, the circuit has a malfunction and must be repaired. If a breaker trips, the ignition or main switch must be switched off before the breaker resets.
Page 470 MAINTENANCE AND LUBRICATION CB Power Studs CB Studs are available either in the overhead storage compartment, or on the dash. W3005282 The red stud is the positive terminal and the black stud is the ground terminal. For a proper hook-up, use fork-type connectors on the wires or use "banana" plugs. CAUTION If stripped wire ends are used, make sure there are no wire strands that can bridge...
Page 471 MAINTENANCE AND LUBRICATION Before connecting any electrical accessory, make sure it is made for 12 V operation. This circuit is fused at 20 A maximum, or optional circuits are fused at higher amps (30 A). DO NOT overload this circuit. CAUTION DO NOT connect a device with a current rating in excess of the amount specified...
