Page 3 Foreword This manual contains information concerning the operation and function of the Volvo Link System. The information in this manual applies to vehicles built January 2010 and later. Please keep this manual in the vehicle at all times. Note: Illustrations in this manual are used for reference only and may differ slightly from the actual vehicle.
Page 4: Table Of Contents
............................1 ADVISORY LABEL DEFINITIONS (IN HANDBOOK)........1 INFORMATION FOR THE OWNER...............2 EMISSIONS CONTROL COMPLIANCE..............5 Exhaust and Noise Emissions ..................5 B5 Approval For Volvo US 10 Certified Products.............6 ENGINES OTHER THAN VOLVO: ................8 VEHICLE DATA .....................13 Identification and Labels..................13 SERVICE LITERATURE ..................19 SERVICE ASSISTANCE ..................20...
Page 5: Table Of Contents
PARKING HEATER (OPTIONAL, SLEEPER MODELS ONLY) ......149 ANTENNAS ......................151 TELEVISION ......................153 TV Antenna......................154 COMMUNICATION EQUIPMENT ..............155 CB Radio........................155 STORAGE COMPARTMENTS................156 SLEEPER BUNKS ....................169 VN 780, VNL 730, VN 670 OFFICE ..............184 SLEEPER COMPARTMENT SINK ..............186 OPERATION........................192 PRE-TRIP INSPECTION AND DAILY MAINTENANCE........192 Pre-Trip Assistance ....................192...
Page 6: Table Of Contents
Pre-Trip Inspection Quick List ................199 New Vehicle Break-In....................211 HOOD OPERATION.....................213 SAFETY BELTS....................230 Safety Restraint VN 430, VN 630, VN 670 ............238 SEATS, GENERAL ....................251 NATIONAL STANDARD SEAT ................252 NATIONAL COMFORT SEAT................253 PASSENGER SEATS ....................255 ENGINE OPERATION ..................259 IMMOBILIZER FEATURE ..................260 CONTROL AWARENESS FEATURE ..............262...
Page 7: Table Of Contents
Aftertreatment DEF Tank Level - Driver Warning & Inducement......373 Aftertreatment DEF Quality - Driver Warning & Inducement ......374 Misfilling Diesel or Aftertreatment DEF Tanks.............375 SCR Tampering - Driver Warning & Inducement ..........376 Warranty and Maintenance ..................377 Exhaust Aftertreatment System Maintenance............377 Emissions Maintenance ..................377 Engine Maintenance Intervals................378 Engine Gaseous Emission Control Systems ............379...
Page 8: Safety Information
Safety Information IMPORTANT: Before driving this DANGER vehicle, be certain that you have read and that you fully understand each and Danger indicates an unsafe practice that every step of the driving and handling could result in serious personal injury information in this manual.
Page 10: Introduction
INTRODUCTION 1 ADVISORY LABEL DEFINITIONS (IN HANDBOOK) Cautionary signal words (Danger-Warning-Caution) may appear in various locations throughout this manual. Information accented by one of these signal words must be observed to minimize the risk of personal injury to service personnel, or the possibility of improper service methods which may damage the vehicle or cause it to be unsafe.
Page 11: Information For The Owner
If you are not the original owner of this vehicle, please notify us about the change in ownership at the address below or through an authorized Volvo Truck dealer. This is the only way we will be able to contact you if necessary.
Page 12 Note: Illustrations in this manual are used for reference only and may differ slightly from the actual vehicle; however, key components addressed in the manual are represented as accurately as possible. This manual covers Volvo VN series vehicles manufactured by Volvo Trucks North America with any of the following designations: •...
Page 13 4 INTRODUCTION W0036011...
Page 14: Emissions Control Compliance
INTRODUCTION 5 EMISSIONS CONTROL COMPLIANCE Exhaust and Noise Emissions General The Federal Clean Air Act, Section 203 (a) (3), states the following concerning the removal of air pollution control devices or modification of a certified engine to a non-certified configuration: CAA, Section (a) (3) (A) prohibits any person to remove or render inoperative any (emission control) device or element of design installed on or in a motor vehicle or motor vehicle engine in compliance with regulations under this part prior to its sale...
Page 15: B5 Approval For Volvo Us 10 Certified Products
As a result, Volvo does not warrant the engine will conform to applicable Federal or California emissions limits when operated on, or having operated on, biodiesel or other alternative fuels that are not substantially similar to specified test fuels used for certification.
Page 16 For additional information about fuel, refer to the Operator’s Manual Vehicle Maintenance. VN: An indicator will appear in the DID screen when there is approximately 3.875 liters (0.9 gallons) remaining in the reservoir. Note: This indicator is optional. It can be deleted.
Page 17: Engines Other Than Volvo
Volvo Trucks North America was designed, built and equipped to conform, at the time it left the control of Volvo Trucks North America, with all applicable U.S. EPA Noise Control Regulations.
Page 18 INTRODUCTION 9 Tampering with Noise Control System Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person, other than for purposes of maintenance, repair, or replacement, of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use;...
Page 19: Cooling System
10 INTRODUCTION • Removal of transmission noise shields. Noise Shielding and Insulation Devices Maintenance Ensure sound shielding and insulating devices are intact. Inspect components for damage. Primary system components requiring noise related inspection include the hood, engine compartment insulating materials (including hood insulation, bulkhead insulation, doghouse insulation, etc.) splash shields, cab skirts, fender shields, and body panels.
Page 20 INTRODUCTION 11 WARNING Hot engine! Avoid all movable parts or hot engine parts, exhaust gases, and/or fluids. A hot engine, exhaust, and/or fluids can cause burns. Maintenance Make sure the exhaust system is intact. Inspect for damage, misalignment and/or leakage. Primary system components requiring noise related inspection include exhaust manifold, turbocharger, and all exhaust system (rigid and flexible) piping.
Page 21 12 INTRODUCTION Engine Control, EGR and Fuel Systems Acts that constitute tampering with Engine Control, EGR and Fuel Systems: Removing rendering inoperative, or modifying the engine control system such as the ECU, EGR system components, or fuel system components, in order to allow the engine to operate outside of the manufacturer’s specifications is not allowed and violates both warranty and legislation.
Page 22: Vehicle Data
INTRODUCTION 13 VEHICLE DATA Identification and Labels It is extremely important that the correct vehicle model and serial number are given whenever replacement parts or service literature are ordered. Using these numbers, as well as giving the major component model and serial numbers, will prevent delay and errors in obtaining the correct material.
Page 23 Note: To deter tampering with the original build information, the information on the label will be destroyed if the label is removed. If for any reason a label is damaged, contact your authorized Volvo Truck dealer for a replacement. Vehicle Order The Vehicle Order is a complete and detailed record of all data pertaining to the assembly of the vehicle.
Page 24 The Engine family is affixed to all Volvo diesel engines. This “AVPTH12.8S0” can be used to identify label, which is located on the cylinder head...
Page 25 In compliance with Federal and California engine was certified. emission requirements, an engine information label is affixed to all Volvo W2040454 Engine Identification Label — 50 State EPA Approved Engine with Califonia “Clean Idle” label as shown above. Should this engine...
Page 26 INTRODUCTION 17 Clean Idle Engines The California Air Resources Board (ARB) requires that any engines having tamper-resistant software which limits the time at which the engine can idle at speeds above low idle (550 – 700 rpm). At speeds above low idle, and without a PTO engaged, idle time will be limited to five minutes, after which the engine will revert back to low idle.
Page 27 18 INTRODUCTION Component Labels The Volvo engine serial number is located on the front left side of the cylinder block. The serial number can also be found on the certification label on the valve cover. The axle model and serial number is located on the front left side of the forward drive axle and the front right side of the rear drive axle.
Page 28: Service Literature
SERVICE LITERATURE To order a single Service Manual or a Service Manual Set for your vehicle, contact your authorized Volvo Truck dealer. In order to handle the request correctly, you must give the model, year and VIN (last six digits of VIN only).
Page 29: Service Assistance
There is also a direct number to Volvo Action Service (VAS), staffed 24 hours a day, if you are in need of assistance. The number to the Customer Support Center is: 1 (800) 528–6586 [or (800) 52–VOLVO].
Page 30: Reporting Safety Defects
Mexico Volvo Trucks de Mexico, S.A. de C.V. should be informed immediately if you believe the vehicle has a defect that could cause a vehicle accident, injury or death. Contact Volvo Trucks de Mexico by calling 011-52-55-50-81-68-50 or by writing to: Volvo Trucks de Mexico, S.A.
Page 31: Event Data Recording Devices
22 INTRODUCTION EVENT DATA RECORDING DEVICES Your Volvo vehicle is equipped with a device generally referred to as an "event data recorder" or "EDR." Please note that while the term "event data recorder" is typically used throughout the motor vehicle industry, not every EDR is the same; i.e., they do not all record the same data elements.
Page 32: Safety Information
The safe operation of this vehicle is determined by the you, the driver. Because of your special preferences, needs and circumstances, you may choose to add extra mirrors and/or other visibility enhancement devices. If so, contact an authorized Volvo Truck dealer to obtain parts which best fit your personal needs and preferences.
Page 33: Operating In Bobtail Mode
24 SAFETY INFORMATION Operating in Bobtail Mode CAUTION When operating bobtail, be certain that glad hands, trailer air hoses, electrical cable and connectors are properly stowed and secure. Do not allow them to rub or chafe on other components. Depending on customer specification, some tractors may be equipped with a bobtail air brake proportioning valve which automatically redistributes the braking force between front and rear axles when not hooked up to a semitrailer (bobtail operation).
Page 34 SAFETY INFORMATION 25 DANGER DO NOT exceed the load rating of the tires or the vehicle weight ratings. Overloading may result in tire failure causing loss of vehicle control, leading to an accident resulting in severe personal injury or death. This vehicle has been designed and assembled for a maximum gross vehicle weight rating (GVWR) and a maximum front and rear axle weights rating (FAWR and RAWR).
Page 35: Vorad® Collision Warning System
26 SAFETY INFORMATION VORAD® COLLISION WARNING SYSTEM The Eaton® VORAD® computerized Collision Warning System constantly monitors vehicles ahead with a front end-mounted radar and in a blind spot area with an optional side-mounted radar. The Collision Warning System warns the driver of potentially dangerous situations by activating visual and audible alerts.
Page 36: Advisory Labels
The labels shown are applicable to the VN model chassis at the time of publication and are representative of what can be typically found. (Your vehicle may not contain all of the labels illustrated in this handbook.) These labels are for your benefit.
Page 37: Cab Entry And Exit
28 SAFETY INFORMATION CAB ENTRY AND EXIT General DANGER WARNING DO NOT stand on the steps or any other Wearing shoes with soles that are dirty part of the vehicle while it is in motion. or wet increases the chance of injury The steps and the back of cab access from slipping and falling.
Page 38 SAFETY INFORMATION 29 W8003120...
Page 39 30 SAFETY INFORMATION W8003127 VN without Fairings...
Page 40: General Entry Guidelines
SAFETY INFORMATION 31 General Entry Guidelines WARNING To avoid personal injury due to a slip and/or fall, observe the following guidelines. BE SURE TO FOLLOW ALL OF THESE INSTRUCTIONS BEFORE ENTERING OR EXITING THE CAB OR THE AREA BEHIND THE CAB. 1 Always have three limbs (one foot and two hands or two feet and one hand) in contact with the vehicle at all times when entering or exiting the cab or the area behind the cab.
Page 41 32 SAFETY INFORMATION 14. Make sure your safety belt is disconnected before exiting the cab. 15. Make sure the safety belt is fully retracted and out of the way prior to entering or exiting the cab. 16. DO NOT put your foot on any surface that does not have slip resistant, self- cleaning material.
Page 42: Driver Side Entry/Exit
SAFETY INFORMATION 33 Driver Side Entry/Exit WARNING On vehicles without side fairings or cab panels, always make sure that the battery box cover is securely fastened before stepping up. Failure to fasten the cover may lead to a fall and personal injury.
Page 43 34 SAFETY INFORMATION Passenger Side Entry/Exit Open the door. Place any hand-carried items on the cab floor. Grasp the left grab handle with your left hand and the right grab handle with your right hand. Put the left foot fully on the bottom step and pull yourself up to the opening. W8003117 Slide hands up on the handles, if necessary.
Page 44 SAFETY INFORMATION 35 Behind the Cab Access WARNING Be careful when entering the back-of-cab area with dirty or wet soles. Wearing shoes with soles that are dirty or wet increases the chance of slipping or falling. When trailer air and electrical connections can not be coupled from the ground, Federal Regulations require commercial carriers to provide back-of-cab access steps, grab handles and plates.
Page 45 36 SAFETY INFORMATION Grasp the grab handle to the left with both hands. Put the left foot onto the bottom step and pull yourself up. Put the right foot on the top step and step onto the deck plate with the left foot. W8003122 WARNING Always perform trailer hook-ups while...
Page 46 SAFETY INFORMATION 37 Stand on the ground when connecting the air and electrical connections to the trailer. W3005321...
Page 47: Entering Sleeper From Seat
38 SAFETY INFORMATION ENTERING SLEEPER FROM SEAT Standard Gear Lever When moving from the driver seat to the CAUTION sleeper section, follow this procedure: Be careful when standing to your feet in the seat area, headroom is limiting. • Make sure the parking brakes are set. •...
Page 48 SAFETY INFORMATION 39 W4001391...
Page 49: Safety Equipment
40 SAFETY INFORMATION SAFETY EQUIPMENT Safety triangles and fire extinguishers are available as optional equipment. The fire extinguisher should be located by the base of the driver seat, between the seat and the door. W1000176 Note: Always store the warning triangles in the box after use.
Page 50: Warning Triangles, Day Cab
SAFETY INFORMATION 41 Warning Triangles, Day Cab The warning triangles are stored in a box that is strapped behind the passenger seat. W1000177...
Page 51: Sleeper Cab
42 SAFETY INFORMATION Sleeper Cab The warning triangles are stored in a box, which is inside the exterior luggage compartment. W8003517...
Page 52: Safety Belt System
SAFETY INFORMATION 43 SAFETY BELT SYSTEM The safety belt system is the main restraint application in the vehicle. All vehicles are equipped with this system. For additional information on the safety belt system refer to “SAFETY BELTS”, page 230. The safety belt system monitors the safety belt latch and vehicle speed. When the vehicle is started the safety belt telltale displays in the cluster.
Page 53: Srs Airbag
The Volvo SRS Airbag provides increased protection in frontal collisions, where the vehicle collides with a fixed or heavy object with enough force to activate the sensors which then activate the airbag.
Page 54 SAFETY INFORMATION 45 The inflatable airbag is folded into the center of the steering wheel. It inflates in the event of a serious collision above a certain level, where the angle of impact, crash severity, speed and nature of the object involved in the collision all play a part in whether or not the airbag is activated.
Page 55 In the event of a problem in the SRS system, an icon is shown in the graphic display in the instrument cluster. T3008842 CAUTION The vehicle should be taken to an authorized Volvo Truck dealer immediately if the SRS icon comes on or remains on while the vehicle is being driven.
Page 56 The label attached to the left-hand sun visor shows the year and month when an authorized Volvo Truck dealer should be contacted for a specific inspection and for a possible replacement of the airbag. This is done to guarantee the function of the airbag after the indicated date.
Page 57 48 SAFETY INFORMATION Steering shafts and steering wheel should not be removed, adjusted or replaced without following the proper work procedure. Failure to do so can damage the SRS system, which can result in malfunction of the SRS. A warning label is located on the upper steering shaft.
Page 58 SRS system. Any interference with the system may cause it to malfunction and result in serious injury or death. Work on the system may only be carried out by an authorized Volvo Truck dealer. To allow the SRS system to work as designed: •...
Page 59 Note: The SRS system is only activated once in a collision. If the airbag has deployed, the following is recommended: * Have the vehicle towed to an authorized Volvo Truck dealer. Even if the vehicle can be driven after a collision, it is not recommended to drive the truck with the airbag deployed.
Page 60 Heart of the Volvo Safety System The three-point anchored safety belt is the heart of the Volvo safety system. The belt should be worn at all times. The SRS system is intended as a supplement to the...
Page 61: Instruments And Controls
52 INSTRUMENTS AND CONTROLS CAB INTERIOR W8003838 1 Instrument Cluster 4 Brake Pedal 2 Cab Climate Control Panel 5 Clutch Pedal (if equipped) 3 Accelerator Pedal 6 Steering Column Tilt Control Pedal...
Page 62: Instrument Panel
INSTRUMENTS AND CONTROLS 53 INSTRUMENT PANEL Tell-Tales A tell-tale is a display that indicates the actuation of a device, a correct or defective condition, or a failure to function. The operator should become familiar with these symbols in order to recognize and react (if necessary) to the indicated condition.
Page 63: Panel Arrangement
54 INSTRUMENTS AND CONTROLS Panel Arrangement Your view from the driver seat should look something like the illustrations shown. The layout is designed to provide the operator with a good view of the gauges and controls (which are placed so they are within easy reach). The instrument panel, as shown in the following drawing, is broken down into several main sections.
Page 64: Instrument Panel Gauge Layout
INSTRUMENTS AND CONTROLS 55 INSTRUMENT PANEL GAUGE LAYOUT W3007473 Panel Arrangement...
Page 65: Panel A
56 INSTRUMENTS AND CONTROLS Panel A W3007469 1 Light Control Panel 2 Instrument Cluster 3 Trailer Air Supply...
Page 66: Panel B
INSTRUMENTS AND CONTROLS 57 4 Tractor Parking Brake Panel B W3007470...
Page 67 58 INSTRUMENTS AND CONTROLS 5. Inter-Wheel Differential Lock 15. VN: Engine Brake Mode Select (ISX) 6. Inter-Axle Differential Lock or I-Shift Hill Start Assist 7. VN: Idle Management Indicator 16. VN: 5th Wheel Touch Lock (Unlock) Lamp (ISX ICON) or Optional Switch 17.
Page 68: Panel C
INSTRUMENTS AND CONTROLS 59 Panel C W3007471 30. VN: Optional Switch or Passenger Window Lift 31. Water in Fuel (Purge Switch) 32. Optional Switch or AUX/USB Port 33. VN: Sleeper Fan Speed 34. VN: Optional Switch or Beacon Lamps...
Page 69: Panel D
60 INSTRUMENTS AND CONTROLS Panel D W3007472 35. Back of Cab Light 36. Optional Switch 37. Optional Switch or Power Take-Off (PTO) 38. VN: Overhead Bunk Lamp or Passenger Side Mirror IN/OUT 39. VN: Side Mirror Heat or Power Take-Off (PTO),...
Page 70: Panel E
Depending on the options selected, all gauges and tell-tales may not be used in all vehicles. Note: The dash layout is the same for all Volvo vehicles. However, the switches and certain switch positions are different depending on vehicle options.
Page 71 62 INSTRUMENTS AND CONTROLS 1. Light Control Panel — For more information, please refer to “LIGHT CONTROL PANEL”, page 107 2. Instrument Cluster There are two instrument cluster levels available: High and Mid level. W3034025 High Level Cluster 1. Tachometer 9.
Page 72 INSTRUMENTS AND CONTROLS 63 W3034026 Mid Level Cluster 1. Tachometer 8. Malfunction Indicator Lamp (MIL) 2. Upper Tell-Tales 9. Driver Information Display (DID) 3. Speedometer 10. Fuel Level 4. Front Brake Air Pressure 11. Intake Manifold Pressure 5. Rear Brake Air Pressure 12.
Page 73: Tachometer
64 INSTRUMENTS AND CONTROLS Tachometer The tachometer has two colored fields: green and red. Use the green field for normal driving (1000 to 1600 rpm). Use higher engine speeds for maximum engine brake performance. Never allow the engine to go into the red field (greater than 2200 rpm). To achieve maximum fuel economy, use the Performance Bonus Guide feature.
Page 74: Oil Pressure Gauge
INSTRUMENTS AND CONTROLS 65 If the pressure in a brake circuit air tank drops below approximately 420 kPa (65 psi), the red LED light in the lower left corner of the gauge will come on and the STOP tell-tale warning indicator comes on. In addition, the buzzer comes on if the vehicle starts to move at speed higher than 1.6 km/h (1 mph).
Page 75 66 INSTRUMENTS AND CONTROLS W3005171 Stop Tell-Tale W3003613 Oil Pressure Symbol Note: The engine will shut down within 30 seconds from when the red STOP tell-tale comes on. Pull off the road as soon as possible without creating a safety hazard.
Page 76: Coolant Temperature Gauge
Coolant Temperature Gauge The coolant temperature gauge indicates engine coolant temperature. The normal operating temperature for Volvo engines is 80 to 105°C (170 to 215°F). Under normal driving conditions, the temperature must be below the red sector. The temperature range for the coolant will vary depending on the type of engine, load, grade, ambient air temperature and operating conditions.
Page 77: Intake Manifold Pressure Gauge (High Level Cluster Only)
68 INSTRUMENTS AND CONTROLS Intake Manifold Pressure Gauge (High Level Cluster Only) The intake manifold pressure gauge indicates intake manifold pressure to the engine. The pressure generated by the intake manifold pressure should be the same at a given engine temperature, speed and load. Intake manifold pressure will vary for different engines and vehicle models.
Page 78: Exhaust Pyrometer Gauge (High Level Cluster Only)
INSTRUMENTS AND CONTROLS 69 Exhaust Pyrometer Gauge (High Level Cluster Only) The exhaust pyrometer gauge indicates the exhaust temperature, which helps the operator get the best efficiency from the engine. Variations in engine load can cause the exhaust temperature to vary. For example, high exhaust gas temperature is the result of prolonged engine lugging or over-fueling.
Page 79 70 INSTRUMENTS AND CONTROLS T4015831 Interwheel Differential Lock When the lock is engaged, a telltale lights up in the instrument cluster. T3014470 Inter-Wheel Tell-Tale A differential lock should only be used on a slippery surface, NOT when driving on good road conditions. If a differential lock telltale is activated in the instrument cluster, do not make turns until the telltale has gone out.
Page 80 INSTRUMENTS AND CONTROLS 71 6. Inter-Axle Differential Lock The inter-axle differential lock eliminates slipping between axles to improve traction. The switch has a safety latch to prevent accidental engagement. W3028391 When the lock is engaged, a tell-tale lights up in the instrument cluster. W3006119 Inter-Axle Tell-Tale A differential lock should only be used on a slippery surface, NOT when driving on...
Page 81 72 INSTRUMENTS AND CONTROLS 7. Idle Management Indicator Lamp (CUMMINS ISX ICON) For more information on this lamp, please refer to your vendor engine manual supplied with this vehicle. Electronically Controlled Suspension (ECS) (ON/OFF) For more information on this lamp, please refer to your vendor engine manual supplied with this vehicle.
Page 82 INSTRUMENTS AND CONTROLS 73...
Page 83 74 INSTRUMENTS AND CONTROLS Lift Axle The vehicle may be equipped with auxiliary lift axles. The lift mechanism operates with air pressure. Press the top part of the switch to raise the axle and press the lower part of the switch to lower the axle. For information about lift axles, refer to “AXLES”, page 342.
Page 84 INSTRUMENTS AND CONTROLS 75 Optional Switch 9. Auxiliary Switches Generic switches are available for auxiliary functions that are installed by the customer. These switches can be purchased from your authorized Volvo Truck dealer. W3005502 Auxiliary Switch Auxiliary Switches Generic switches are available for auxiliary functions that are installed by the customer.
Page 85 76 INSTRUMENTS AND CONTROLS W3005507 Tag Axle Auxiliary Switches Generic switches are available for auxiliary functions that are installed by the customer. These switches can be purchased from your authorized Volvo Truck dealer. W3005502 Auxiliary Switch...
Page 86 W3006082 Engine/Transmission Temperature Gauge Front/Rear Axle Temperature Gauge 14.Engine Brake For more information about the engine brake, see “Volvo Engine Brake (I-VEB)”, page 272. I-Shift Eco-Roll For more information on this feature, please refer to the I-Shift Transmission Manual supplied with your vehicle.
Page 87 78 INSTRUMENTS AND CONTROLS 15. Engine Brake Mode Select (ISX) For more information about the engine brake, see “Volvo Engine Brake (I-VEB)”, page 272. W3002303 I-Shift Hill Start Assist For more information on this feature, please refer to the I-Shift Transmission Manual supplied with your vehicle.
Page 88 INSTRUMENTS AND CONTROLS 79 16. Fifth Wheel Touch Lock. release the locking mechanism. Once DANGER activated, the switch will not relock the fifth wheel kingpin locking mechanism. Activation of the kingpin lock release • switch ONLY unlocks the kingpin Release parking brake and drive tractor latch mechanism.
Page 89 80 INSTRUMENTS AND CONTROLS 17. Marker Interrupt Switch This switch interrupts power to the marker lights when held down. When released, it springs back to the ON position and returns power to the marker lights. W3001352 Marker Interrupt Switch...
Page 90 INSTRUMENTS AND CONTROLS 81 18. Secondary Gauge Cluster The secondary gauge is an optional feature, which is available only with the Mid and High level instrument clusters. The instrument cluster receives temperature information from the datalink and then passes the information to the secondary gauge for viewing.
Page 91 This may be useful for decreasing the chances of getting bogged down when driving in heavy snow, slush or muddy conditions. Refer to Volvo Exhaust Brake for more information.
Page 92 INSTRUMENTS AND CONTROLS 83 21. Fifth Wheel Slide Switch DANGER The release must never be operated while the vehicle is operating on the road. Fifth wheel position adjustment must only be done when stationary. Damage to the fifth wheel, trailer kingpin and slider may occur if not operated properly and may lead to an accident, causing serious personal...
Page 93 84 INSTRUMENTS AND CONTROLS Engine Air Control Switch The engine fresh air control switch controls air flow to the engine air cleaner. In the normal OFF position, air is pulled through the side hood vent, and into the air cleaner. In the ON position, air is pulled from within the engine compartment into the air cleaner.
Page 94 “Trailer Brake Hand Control”, page 288. 31. Water-In-Fuel (Purge Switch) (Optional) The water-in-fuel drain switch is a non-locking switch used to drain the fuel water separator on Volvo engines. W3005378 Water-In-Fuel Drain Switch A symbol displayed in the instrument panel indicates when it is recommended to drain the water separator.
Page 95 86 INSTRUMENTS AND CONTROLS Draining Procedure Note: If the engine is started before draining is complete, the process is interrupted. 1 Stop the vehicle. 2 Apply the parking brake. 3 Turn off the engine. 4 Place a container under the water separator. 5 Turn the ignition key counterclockwise to the "Radio, Accessories"...
Page 96 INSTRUMENTS AND CONTROLS 87 33. Sleeper Fan Speed Switch The sleeper fan switch located in the dash, controls the sleeper fan speed. The switch in the sleeper control module performs the same function as the dash switch. Press the top part of the switch to increase the fan speed, press the lower part to decrease fan speed.
Page 97 88 INSTRUMENTS AND CONTROLS W3005382 Sleeper Fan Speed Switch 34. Beacon Lamps Switch W3005428 Sleeper Fan Speed Switch...
Page 98 INSTRUMENTS AND CONTROLS 89 Optional Switch 35. Back of Cab Light Switch (Optional) To activate the back of cab light, press the bottom part of the switch. The light will stay on until the switch is turned to the OFF position. Back of cab lights are available as a flush-mounted light in the middle of the cab rear wall or as a high-mounted light on the side of the cab.
Page 99 90 INSTRUMENTS AND CONTROLS 38. Sleeper Overhead Bunk Lamp This switch operates the overhead lighting in the VN sleeper cabs. It is situated on the left-hand side of the dash to allow access to the switch without entering the sleeper section of the cab.
Page 100: Dash Switches
INSTRUMENTS AND CONTROLS 91 41. Microphone The microphone is located above the driver in the headliner. It is available on the Mid-Level radio with Blue Tooth/Hands free option. This is what is used to talk into when the phone is connected to the truck. For more information on the microphone, please refer to the Radio Manual that is supplied with the vehicle.
Page 101 92 INSTRUMENTS AND CONTROLS W3005510 Engine-Mounted PTO, VN The engine should be running at low idle and the vehicle should be stopped or running at very low speed before engaging power take-off. Engage the PTO by depressing the locking tab and at the same time, depressing the main part of the switch. The PTO is...
Page 102 3 If NOT, then • Volvo engines: Press the RESUME button to achieve the preset PTO engine speed. Alternatively, the accelerator pedal can be used to achieve the desired engine speed, and press SET+ or SET- to hold that speed •...
Page 103 Volvo Variable Geometry Turbo Brake VN The variable geometry turbo brake is standard equipment on the Volvo 11F and 13F engines. Software is used to close the variable geometry turbocharger, creating...
Page 104 The I-VEB is standard equipment on the Volvo 16F engine and optional on the 13F and 11F engines. The I-VEB has a six position control located on the steering column, just forward of the wiper stalk.
Page 105 96 INSTRUMENTS AND CONTROLS Cummins ISX Intebrake Standard: Two dash switches control the 3-level engine brake; the left dash switch controls ON/OFF, the right dash switch controls LOW/MED/HIGH. W3005433...
Page 106 INSTRUMENTS AND CONTROLS 97 Optional: A 6-level retarder stalk switch mounted to the right of the steering column. An ON/OFF switch at the end of the stalk lever enables/disables the engine brake. W3005373...
Page 107: Climate Control Systems
98 INSTRUMENTS AND CONTROLS CLIMATE CONTROL SYSTEMS There are two different air conditioning systems. Depending on your vehicle, you will have one of these two air conditioning units installed: 1 Electronic Climate Control (EEC) 2 Manual Climate Control (MCC) Note: For both climate control systems (ECC and MCC), after a pre-determined number of "vehicle starts"...
Page 108 INSTRUMENTS AND CONTROLS 99 Recirculation Press recirculation to circulate the air in the cab. Only a small amount of air is taken directly from outside. The light in the button comes on when the button is pressed for air recirculation. Temperature Control Settings ECC Maximum Cold Setting The temperature knob should be set to the far left.
Page 109 100 INSTRUMENTS AND CONTROLS Mist and Ice Removal DANGER DO NOT attempt to drive with the windshield covered by mist, or fog or frost. The visibility is reduced, which could lead to an accident causing severe personal injury or death. 1 Turn knob to defrost.
Page 110 INSTRUMENTS AND CONTROLS 101 ECC Air Distribution W8003067 1 Temperature Sensor CAUTION The temperature sensor shown in the illustration, detects the temperature in the cab. DO NOT cover the sensor, and DO NOT place warm objects, like coffee makers or refrigerators, close to the sensor.
Page 111: Air Conditioning Manual Climate Control (Mcc)
102 INSTRUMENTS AND CONTROLS AIR CONDITIONING MANUAL CLIMATE CONTROL (MCC) One difference in the Manual Climate Control unit is the AC ON button. W8003066 1 AC ON button turns the air conditioning ON. 2 Temperature Control Knob 3 Fan Speed Knob 4 Recirculation Button 5 Air Distribution Knob Note: The LED light is green when the AC button is depressed.
Page 112 INSTRUMENTS AND CONTROLS 103 Recirculation Press recirculation to circulate the air in the cab. Only a small amount of air is taken directly from outside. The light in the button comes on when the button is pressed for air recirculation. Temperature Control Settings MCC Move the knob to the blue bar for cool air to circulate in the cab, and to the red bar for warm to hot air to circulate in the cab.
Page 113 104 INSTRUMENTS AND CONTROLS MCC Air Distribution W8003110 Always allow the dashboard vents (see arrows in illustration) to remain open. Irrespective of how the air distribution is set, a small amount of air will always come from the dashboard vents to ensure the temperature in the cab is correct. Note: Floor Mode: Unheated air is leaked DANGER to the panel vent to balance the heat rising...
Page 114 INSTRUMENTS AND CONTROLS 105 If at any time there is any question whether fumes are entering the cab, determine the cause of the fumes and have it corrected as soon as possible. If the vehicle must be driven under these conditions, drive only with all windows open. Protect against carbon monoxide entry into the cab.
Page 115: Sleeper Climate Unit
106 INSTRUMENTS AND CONTROLS SLEEPER CLIMATE UNIT The sleeper cabs have an A/C and heater unit that is located in the passenger side luggage compartment. The sleeper unit operates from the same heater and air conditioning supply as the main unit. The heater can be operated independently from the main unit as long as the engine is running.
Page 116: Light Control Panel
INSTRUMENTS AND CONTROLS 107 LIGHT CONTROL PANEL Exterior lighting is controlled through the light control panel. The rotary knob controls the parking lights, headlights, and the optional fog and driving lights. The panel also has a dimmer control switch and hazard switch. W3005377 1 Off 2 Parking Lights...
Page 117 108 INSTRUMENTS AND CONTROLS Fog and Driving Lights Fog and driving lights are wired so they are turned on only when the headlight control is on. Fog lights are used with the low beam headlights. Driving lights are used with the high beam headlights.
Page 118 INSTRUMENTS AND CONTROLS 109 W3005274 VNL Fog and Driving Lights...
Page 119: Sleeper Control Panel (Sleeper Models Only)
110 INSTRUMENTS AND CONTROLS SLEEPER CONTROL PANEL (SLEEPER MODELS ONLY) The sleeper control module is located behind the driver’s seat. It provides precise temperature control to the sleeper unit. There are separate temperature and fan control systems for the sleeper and the cab area. The driver can control the fan speed in the sleeper using a control switch on the dash.
Page 120 INSTRUMENTS AND CONTROLS 111 W3030107 1 Panel in VN 730 ,780 and 2 Panel in VN 430, 630, 670 Note: High Sleeper or Basic Sleeper Control Panel are NOT cab model dependent This dual control usage provides optimum comfort to the driver and passenger (if any) in both compartments.
Page 121: Sleeper Control Panel, High
112 INSTRUMENTS AND CONTROLS Sleeper Controls Sleeper Control Panel, High W3030106 1 Display Screen: Displays selected information. 2 On/Off button 3 Radio Forward Scan/Search/Next Track 4 Radio Power 5 Menu/Snooze Button: This button allows you to adjust settings in the display screen and activate the clock’s snooze option.
Page 122 INSTRUMENTS AND CONTROLS 113 9 Fuses 10 Panic button 11 LED: Only used for low voltage conditions. 12 Overhead Lamp Switch: This can be controlled from the sleeper control module or from the dash rocker switch. 13 Mode Switch: Changes mode of radio 14 Radio Reverse Scan/Search/Next Track 15 Set button 16 Increment/Decrement Knob: Use this knob to adjust the Volume level.
Page 123: Sleeper Control Panel, Basic
114 INSTRUMENTS AND CONTROLS Sleeper Control Panel, Basic W3030078 1 Overhead Lamp Switch: This can be controlled from the sleeper control module or from the dash rocker switch. 2 Speaker: Sounds when the alarm or timer goes off, or when entering battery protection mode.
Page 124 INSTRUMENTS AND CONTROLS 115 Set Clock To set the clock for the Sleeper Control Panel, perform the following: 1 Press the SET button. 2 To set the clock to either ’12’ or ’24’ hour increments, use the “+” or “-” knob. 3 Press the SET button.
Page 125 116 INSTRUMENTS AND CONTROLS Dimmer To adjust the backlighting brightness level, perform the following: 1 Press the MENU button. 2 Press the SET button. 3 Use the “+” or “-” knob to adjust the brightness level. 4 Press the SET button to confirm settings. Once the backlighting brightness is set to the desired level, the display goes back to the clock.
Page 126 INSTRUMENTS AND CONTROLS 117 Setting Alarm Time To set the alarm time, perform the following: 1 Press the MENU button twice. 2 Press SET button. 3 Use the “+” or “-” knob to adjust the hour value. 4 Press SET to accept the set hour. 5 Use the “+”...
Page 127 118 INSTRUMENTS AND CONTROLS Setting the Sleeper Control Panel Heat Control Value to Auto Auto Set a time in the future to automatically turn ON. Will remain ON until manually turned OFF. To set the Sleeper Control Panel heater to Auto, perform the following: 1 Press the MENU button three times.
Page 128 INSTRUMENTS AND CONTROLS 119 Setting the Sleeper Control Panel Heat Control Value to Cycle Cycle Set a cycle time to continuously cycle between ON/OFF To set the Sleeper Control Panel heater to Cycle, perform the following: 1 Press the MENU button three times. The Heat icon blinks.
Page 129: Setting Sleeper Control Panel Timer
120 INSTRUMENTS AND CONTROLS Setting Sleeper Control Panel Timer To set the Sleeper Control Panel Timer, perform the following: 1 Press the MENU button four times. The TIMER icon blinks. 2 Press the SET button. 3 To set the Timer minutes, use the “+” or “-” knob. 4 Press the SET button.
Page 130 INSTRUMENTS AND CONTROLS 121 Turning the Lamp Timer ON/OFF Lamp Timer Turns interior lamps off after a set time. To turn the Lamp Timer On/Off for the Sleeper Control Panel, perform the following: 1 Press the MENU button six times. The Lamp Icon flashes.
Page 131: Miscellaneous Cab Equipment
122 INSTRUMENTS AND CONTROLS MISCELLANEOUS CAB EQUIPMENT Cup Holders and Trash Compartment There is a trash bin holder at the lower part of the dash. To open, press the top part of the lid in and the lid will fold out. To close, press the lid in until the latch closes. There are also two dash-mounted cup holders convenient to the driver and passenger.
Page 132 INSTRUMENTS AND CONTROLS 123 Sleeper cup holder: Located on the left lower tower cabinet, for the bottom bunk. There is another cup holder located on the left upper tower cabinet for the upper bunk. W8003181...
Page 133 3 Sleeper Window Cover 4 Sky Light Cover Covers for the VN 670 are to be stored in a rolled-up position in the opening behind the cabinet. The covers for the VN 780 side windows are stored behind the backrest cushions. All covers are put on with snap buttons that are on the cover and window rim, with the exception of the sky light cover.
Page 134: Steering Column
The ignition switch is located on the right side of the steering column just under the steering wheel. Standard equipment is a normal ignition switch. Note: The vehicle is delivered with 2 identical keys. If more keys are needed, order them through your authorized Volvo Truck dealer. The ignition positions are: •...
Page 135 126 INSTRUMENTS AND CONTROLS Windshield Wiper/Washer Note: Make sure the ignition is in the Off position to avoid draining the battery. The wiper/washer functions are operated by the same lever. The wipers have normal and fast speeds which are activated by moving the lever down one or two positions. To let the wipers engage for a few passes, lightly depress the lever until the wipers start and hold it there.
Page 136: Adjustable Steering Column
INSTRUMENTS AND CONTROLS 127 ADJUSTABLE STEERING COLUMN DANGER DO NOT try to make adjustments to the steering wheel while the vehicle is moving. Never operate the vehicle with the steering wheel adjusted to its uppermost position (exiting cab position). Make all adjustments before starting the vehicle, to prevent loss of vehicle control, which can cause personal injury or death.
Page 137: Steering Wheel Controls
128 INSTRUMENTS AND CONTROLS STEERING WHEEL CONTROLS • Left-Hand Controls Marker Interrupt (Bottom) • Headlamp Interrupt (Top) When either switch is pressed, the corresponding lights toggle from their current state. If OFF they change to ON and if ON they change to OFF. When pressed for more than 3 seconds, the lights revert automatically to the initial state.
Page 138: Miscellaneous Switches
INSTRUMENTS AND CONTROLS 129 MISCELLANEOUS SWITCHES Horn Switches Electric and air horns are standard equipment. They are both operated from the steering wheel or center pad. The airbag can be pressed down anywhere around the edge to engage the air horn. W6001503 1 Air Horn 2 Electric Horn (city horn)
Page 139: Interior Lights
130 INSTRUMENTS AND CONTROLS INTERIOR LIGHTS The cab is equipped with separate and combined interior and reading lights in various locations in the cab. The front seat overhead lights can be turned on at any time using the switch in the fixture. This is a three-way switch, pressing the lamp turns the light ON, OFF or the light comes on with the door being opened.
Page 140 INSTRUMENTS AND CONTROLS 131 Interior Lights Chart Number Description Overhead Dome Lamp Overhead Dome/Spot Lamp connected to door Door Courtesy Lamp Dome Lamp — Sleeper Reading Lamp under bunk storage Reading Lamp Overhead Lamp — Short Overhead Lamp — Long Overhead Dome/Spot Lamp Note: To prevent short service lift, DO NOT touch the glass surface of the replacement bulb.
Page 141 132 INSTRUMENTS AND CONTROLS The red courtesy light comes on when the door is opened. The lens is red to alert oncoming traffic from the rear that the door is open. It is also used during night driving to light up the floor area and steps without distracting the driver with a glaring light. CAUTION DO NOT use sleeves of any kind over bulbs in the interior lamps.
Page 142 INSTRUMENTS AND CONTROLS 133 The door latch has an internal switch that operates all door-activated lights. W8003522...
Page 143: Fresh Air Vent
134 INSTRUMENTS AND CONTROLS Fresh Air Vent A. Closed B. Open C. Vertical Air Flow D. Lateral Air Flow T0008094 When heating the cab, all vents should be closed. However, the vents on the outer parts of the dash can be used for defrosting the cab door windows. When operating the air conditioning, all air vents should be completely open and the air flow directed upward.
Page 144: Cab Ventilation, Sleeper
INSTRUMENTS AND CONTROLS 135 CAB VENTILATION, SLEEPER In sleeper versions (except the VN 780 and VN 730) there is a fresh air vent located on each cab side wall. It opens to two positions so the air flow can be regulated.
Page 145 1 VN 780 and VN 670 Vent Window 2 VN 780 Hinged Side Window The VN 730 is equipped with two hinged side windows in the sleeper area. DO NOT force the window crank mechanism in the fully open position. The mechanism can be damaged if you try to open the window beyond the stop position.
Page 146 INSTRUMENTS AND CONTROLS 137 12 Volt Power Outlets CAUTION DO NOT connect a device with a current rating in excess of 10 amps or the amount labeled. There are a number of 12 V outlets that can be accessed in the cab. There is a power outlet on the sleeper control panel.
Page 147 There is an optional power outlet in the driver and passenger side cabinets. Accessories for this cabinet will have ON/OFF switches of their own. The cabinet 12 V outlets are made for 12 V accessory-type plugs. W3005508 VN 780, VN 730...
Page 148 INSTRUMENTS AND CONTROLS 139 W3005500 VN 780, VN 730...
Page 149: Inverter Switch 12 V Dc To 120 V Ac
140 INSTRUMENTS AND CONTROLS Inverter Switch 12 V DC to 120 V AC DANGER When parked on wet ground, avoid using an external power source to connect the cab power plug. Water is a conductor of electricity. In wet conditions, electrical shock can occur which can result in personal injury or death.
Page 150 INSTRUMENTS AND CONTROLS 141 W3005980 This is a typical setup with a factory-installed inverter. 1 External Power Plug 2 Load Center 3 Inverter (if equipped)
Page 151 The VN 730, 780, 670 and 630 are available with an optional 120 V AC service, used for longer parking while still living in the vehicle. The 120 V AC service is supplied from outside sources.
Page 152 INSTRUMENTS AND CONTROLS 143 W3005284 Power goes through a circuit breaker box located on the front wall in the driver side luggage compartment. On the right is an ON/OFF switch and on the left is the ground fault circuit interrupter. The controls may also be reached from inside the cab through the hatch under the mattress or cushion.
Page 153 144 INSTRUMENTS AND CONTROLS W3005967...
Page 154 INSTRUMENTS AND CONTROLS 145 From the breaker box in the VN 780 and 730, power goes to the three outlets as a standard feature. In the VN 670 and 630 models, the outlet on the driver side lower bunk box is standard, and the tower cabinet middle compartments (1) each have an optional outlet.
Page 155 146 INSTRUMENTS AND CONTROLS W3005343 120 Volt System Wiring, VN 670, VN 630...
Page 156 INSTRUMENTS AND CONTROLS 147 W3005342 120 Volt System Components, VN 670, VN 630 1 120 Volt Outlet 3 Circuit Breaker Box 2 External 120 Volt Receptacle...
Page 157 Some of these may deform the lighter socket’s tangs and cause it not to work properly. If an auxiliary socket is needed, the cigar lighter assembly may be replaced with the approved Volvo 12 V power socket.
Page 158: Parking Heater (Optional, Sleeper Models Only)
INSTRUMENTS AND CONTROLS 149 PARKING HEATER (OPTIONAL, SLEEPER MODELS ONLY) DANGER WARNING DO NOT fuel the vehicle or handle The parking heater is a very hot object. flammable liquids in the vicinity of DO NOT touch the heater when it an operating parking heater.
Page 159 150 INSTRUMENTS AND CONTROLS Fuel Parking Heater Note: The parking heater is not available if the vehicle is equipped with a sink. A fuel heated parking heater is available as an option. It is located in the left-hand luggage compartment. The heater provides automatically regulated heat that is distributed through its own vents into the sleeper section of the cab.
Page 160: Antennas
INSTRUMENTS AND CONTROLS 151 ANTENNAS General 3 Radio AM/FM 4 TV Antenna 1 Multiband 2 Multiplexer (Rami) Multiband Antenna There are antennas mounted on the top of the mirror brackets for wideband reception. They receive or send signals for radio, CB and telephone. Each antenna carries multiple wire windings that work together with mirror bracket devices to cover the needs of many uses.
Page 161 Communication signals that travel to and from the antennas go through the antenna multiplexer. It is standard in the VN 670 and VN 780, and optional on other models. Coaxial cables for the cellular phone, CB radio and radio are included in the...
Page 162: Television
This could cause personal injury. The VN 780, VN 730, VN 670 and VN 630 are already equipped for TV with a pre-installed antenna. The TV should be installed in the passenger side cabinet where there is a standard 12 V connection or an optional 120 V connection.
Page 163: Tv Antenna
TV. When the headset jack is plugged in, the speaker is cut out. Note: The TV prep kit is optional. TV Antenna CAUTION DO NOT pierce or drill through the headliner. The TV antenna may be damaged. The TV antenna for the VN 780, VN 730 and VN 830 is standard equipment.
Page 164: Communication Equipment
INSTRUMENTS AND CONTROLS 155 COMMUNICATION EQUIPMENT CB Radio There is an optional platform provided for a CB radio on top of the dash. The unit is held in place with a strap which can accommodate a variety of sizes. W3006382 The CB radio can also be mounted in the overhead storage.
Page 165: Storage Compartments
156 INSTRUMENTS AND CONTROLS Telephone There is room on the dash for a mobile telephone. This can be hooked up to the multiplex box. If the vehicle is delivered with a multiplex box, the connecting end of the telephone coaxial cable should be located at the lower dash cover. Note: The panel must be removed to access the cable.
Page 166 INSTRUMENTS AND CONTROLS 157 To prevent the television and microwave oven from moving when the vehicle is driven, the strap in the storage area should be tight around the unit. Position the strap across the front corners of the unit. Periodically, check that the strap is tight and retighten as necessary.
Page 167 158 INSTRUMENTS AND CONTROLS Front Overhead Storage There are two configurations of overhead storage compartments mounted over the windshield: five openings with nets, or CB radio, switch panel, and three openings with nets. The storage compartments have a maximum storage weight limit of approximately 1.1 kg (2.5 lb.) per opening or a total of 5.6 kg (12.5 lb.) evenly distributed.
Page 168 INSTRUMENTS AND CONTROLS 159 W8003821 CB Radio, Switch Panel and Three Openings with Nets...
Page 169 160 INSTRUMENTS AND CONTROLS There are two configurations of forward overhead shelves at the front of the sleeper: without cabinets or with cabinets. The storage compartments have a maximum storage weight limit of approximately 3.6 kg (8 lb.) per section. W8003794 Forward Overhead Shelf without Cabinets...
Page 170 INSTRUMENTS AND CONTROLS 161 W8003793 Forward Overhead Shelf with Cabinets...
Page 171 162 INSTRUMENTS AND CONTROLS VN 780 Storage W8003805 1. 3 kg (6.6 lb.) 9. 4 kg (8.8 lb.) 2. 3 kg (6.6 lb.) 10. 15 kg (33.1 lb.) with TV, 6 kg (13 3. 4 kg (8.8 lb.) lb.) without TV 4.
Page 172 INSTRUMENTS AND CONTROLS 163 VN 780 Bunk Storage W8003157 1 Storage Bins 2 Storage Compartment 3 Storage Compartment 4 Exterior Side Storage Compartment...
Page 173 164 INSTRUMENTS AND CONTROLS VNL 730 Storage W0002358 1. 6 kg (13 lb.) without refrigerator, 5. 3 kg (6.6 lb.) 45 kg (99 lb.) equally distributed with 6. 3 kg (6.6 lb.) 78 L refrigerator 7. 13.6 kg (30 lb.) 2.
Page 174 INSTRUMENTS AND CONTROLS 165 W8028486 Load Limits...
Page 175 166 INSTRUMENTS AND CONTROLS 1. 5 kg (9.9 4. 3 kg (6.6 lb.) lb.) with 44 L 5. 13.6 kg (30 lb.) refrigerator 6. 10 kg (22 lb.) 2. 4 kg (8.8 lb.) on hanger rod if shelf, 5 kg (9.9 lb.) if refrigerator 3.
Page 176 INSTRUMENTS AND CONTROLS 167 VNL 730 Bunk Storage W8028488 Load Limits 1. Storage Compartment 2. Storage Compartment 3.Exterior Side Storage Compartment...
Page 177 168 INSTRUMENTS AND CONTROLS VN 670, 630, 430 W8028489 Load Limits 1. Lower Bunk Floor Panel 2. Release Handle 3. Restraint Cylinders 4. Outside Storage Compartments...
Page 178: Sleeper Bunks
The VN 670 and VN 630 use the safety bunk harness latch to hold up the bunk. The VN 780 has latches on both sides of the wall that hold the bunk in position. To release the latches, pull the latch strap in the middle of the bunk underside.
Page 179 170 INSTRUMENTS AND CONTROLS and hold the bunk properly. For more information on bunk safety restraints, see “Safety Restraint VN 430, VN 630, VN 670 ”, page 238. W8028490 1 Cushions: These can be moved and placed to the side.
Page 180 INSTRUMENTS AND CONTROLS 171 VN 780 Sleeper Upper Bunk WARNING DANGER Support the bunk with one hand while releasing the latches. Failure to support Always have three limbs (one foot and the bunk may lead to the bunk falling two hands or two feet and one hand) without control, causing personal injury.
Page 181 172 INSTRUMENTS AND CONTROLS W8028491 1 Upper Bunk 2 Upper Bunk in Lowered Position 3 Release/Pull Strap 4 Upper Bunk in Raised Position...
Page 182 INSTRUMENTS AND CONTROLS 173 VNL 730 Sleeper Bunk DANGER Always have three limbs (one foot and two hands or two feet and one hand) in contact with the floor, bunk or step at all times when entering or exiting the upper bunk. Failure to follow this procedure can lead to a fall and cause severe personal injury or death.
Page 183 The VNL 730 can be equipped with a single 53-inch lower bunk, or a 42-inch lower bunk and an upper bunk. For information on bunk safety restraints, see “Safety Restraint VN 430, VN 630, VN 670 ”, page 238. W8028524...
Page 184 INSTRUMENTS AND CONTROLS 175 The 42-inch bunk cushions cover the luggage compartment. They can be moved for access to luggage from inside the cab. W8028524 1 Cushions: These can be moved for access to the luggage compartment. 2 Cushions: These can be moved and placed to the side.
Page 185 176 INSTRUMENTS AND CONTROLS The upper bunk is hinged and can be raised out of the way. The bunk is supported by a strut on each side in the raised and lowered positions. Use the handle in the middle of the bunk to raise and lower it. W8028525 1 Upper Bunk in Raised Position 2 Upper Bunk in Lowered Position...
Page 186 INSTRUMENTS AND CONTROLS 177 VN 670, 630 42-Inch Sleeper Bunk W8028526 VN 670, 630 Lower Bunk WARNING Support the bunk with one hand while releasing the latch. Failure to support the bunk may lead to the bunk falling without control, causing personal injury.
Page 187 178 INSTRUMENTS AND CONTROLS W8028527 VN 670, 630 Lower and Upper Bunks...
Page 188 INSTRUMENTS AND CONTROLS 179 VN 670 Optional Fold Down Step In the VN 670 sleeper there is an option on the passenger side which offers a fold down step. See illustration. W8028528 1 Fold Down Step 2 Cabinet Grab Handle...
Page 189 180 INSTRUMENTS AND CONTROLS VN 670 W8028529 Moveable Cushions in Lower Bunk...
Page 190 INSTRUMENTS AND CONTROLS 181 VN 430 Sleeper Bunk W8028530 1 Bunk 2 Bunk Restraints 3 Lower Bunk Restraint Attachment Buckles 4 Tenting Buckles...
Page 191 182 INSTRUMENTS AND CONTROLS Upper Bunk Access VN 780 WARNING DANGER Support the ladder with one hand while releasing the lock straps. Failure to Always have three limbs (one foot and support the ladder may lead to the two hands or two feet and one hand)
Page 192 INSTRUMENTS AND CONTROLS 183 W8028531 1.Ladder in 4.Ladder (Stored) Down Position 5.Cabinet Grab 2.Retainer Handle 3.Grab Handle 6.Ladder Security (on Optional Positioning Fixed Bunk, Grab Handle is Not Available)
Page 193: Vn 780, Vnl 730, Vn 670 Office
Lower the table to its resting position. Place the seat cushions toward the walls and then position the backrest cushions as illustrated. Press down on the cushions in the middle to form a mattress. See "VN 780 Bunk Storage" in this manual.
Page 194 INSTRUMENTS AND CONTROLS 185 W8003158...
Page 195: Sleeper Compartment Sink
186 INSTRUMENTS AND CONTROLS SLEEPER COMPARTMENT SINK A built-in sink is available as optional equipment in some sleeper models. It is located on the left side, in the cabinet behind the driver. The sink is mounted in the drawer space. To pull out, grasp the drawer lip and release the latch.
Page 196 INSTRUMENTS AND CONTROLS 187 To operate the water pump, there is a combined valve and switch in the knob (see arrow in illustration) on the base. Turn the knob slightly toward you to start the pump; see arrow in illustration. Turn the knob further to increase water flow. When the knob is turned fully back to rest position, the pump will stop.
Page 197 188 INSTRUMENTS AND CONTROLS It is not recommended to keep unused water in the tank for over one month. Clean and refill as necessary. W8002168 CAUTION USE POTABLE DRINKING WATER ONLY. Verify with the supplier of any water prior to filling the fresh water tank that it is potable to avoid contamination of the tank.
Page 198 INSTRUMENTS AND CONTROLS 189 CAUTION Fresh water and waste water tanks must be drained if the vehicle is not being used and the outside temperature is below freezing. Also drain the hose from the pump to the faucet. Failure to drain the system may result in component damage due to water forming ice.
Page 199 190 INSTRUMENTS AND CONTROLS When the tank is full, reinstall the fill hose on the elbow fitting. Do not tighten more than finger tight. Make sure that the valve handle is fully open (1) to allow venting. If the valve is left in any of the closed positions (2), the pumped out water may generate an under-pressure in the tank, interfering with the pump operation.
Page 200 INSTRUMENTS AND CONTROLS 191 Waste Water Tank When the water is drained from the sink, it is collected in a waste water tank behind the fresh water tank. Waste water tank volume is 19 liters (5 gallons). The tank is fastened to the floor with a strap that can be easily opened for tank removal.
Page 201: Operation
If any component or system does not pass this inspection, it must be corrected before operating the vehicle. Whenever equipment requires adjustment, replacement, repair or lubrication, refer to the Service Manuals or contact an authorized Volvo Truck dealer for the correct procedures, specifications and intervals.
Page 202 OPERATION 193 Switch/Circuit Status Check The Switch/Circuit Status check tests the functionality of the switches and their corresponding circuits. To start the check the driver must turn the individual switches on/off. As the switches turn on/off, the cluster updates the DID to show switch option being tested and it’s status.
Page 203 194 OPERATION Exterior Light Inspection Check The Exterior Light Inspection check repeatedly turns all exterior lights on/off for the vehicle. This allows the operator to start the test, exit the vehicle and do a visual check that all exterior lighting is functioning properly. The following exterior lights are cycled through the check: •...
Page 204 OPERATION 195 2. The Test Started screen displays. You can stop the test by pressing ’ESC’ on the stalk or by starting the ignition. W3035557 Once the test is started all exterior lights flash on and off so that you can perform a visual check.
Page 205 196 OPERATION Air Leakage Check The Air Leakage check allows the driver to accurately measure the amount of air pressure drop in the front and rear brake air systems. After selecting this test from the DID, you are prompted to apply the service brake for 60 seconds. After applying and holding the service brake for 60 seconds, the DID will display the amount of pressure drop in the brake system.
Page 206 OPERATION 197 2. When the system is ready to be checked, the following screen displays. Press Enter to begin the test. W3035566 Press and hold the brake pedal for 60 seconds. If the brake pedal is not pressed and held for 60 seconds the following warning screen displays. W3035571 3.
Page 207 198 OPERATION W3035574...
Page 208: Pre-Trip Inspection Quick List
OPERATION 199 Take your time going through the pre-trip inspection. Remember that a careful pre-trip inspection saves time by eliminating unscheduled stops for correcting a faulty item. The following information has been provided by the American Trucking Association as developed by the D.O.T. Office of Motor Carriers (BMCS). Pre-Trip Inspection Quick List W0001230 Pre-Trip Inspection Quick List...
Page 209 200 OPERATION • Raise cab so belts can be checked Step 1: Left Side of the Cab Left Front Wheel • Check condition of wheel rim. Especially look for cracks, missing lockrings, bent or broken studs, missing clamps or lug nuts. •...
Page 210 OPERATION 201 Engine Compartment, Right Side • Check condition of coolant and heater hoses. • Check condition of fan drive belts. • Check engine and surrounding areas for coolant, oil and fuel leaks. • Check fuel separator sight glass and drain if necessary. Check for leaks. •...
Page 211 202 OPERATION • Check condition of tire: properly inflated, no serious cuts, bulges, tread wear or any signs of misalignment; valve stem not touching wheel, rim or brake drum; valve cap in place. • Check wheel bearing and hub: no obvious leaking on outside or inside wheel.
Page 212 OPERATION 203 • Check drive shaft. • Exhaust system: secure, not leaking, not touching wires, fuel or air tubing. • Frame and cross members: no bends, cracks or breaks. DPF/SCR check hoses and fittings for leaks. • Air tubing and electrical wiring: secured against snagging and chafing. Step 5: Right Rear Vehicle Area Dual Wheels, One or Two Axles •...
Page 213 204 OPERATION • Check that air tubing and electrical lines are properly secured to the frame with no damage or chafing. Lights and Reflectors • Tail lights, brake lights and turn signal lights: operating, clean and proper color. Step 7: Coupling System Area Fifth Wheel •...
Page 214 OPERATION 205 Suspension • Check condition of springs (leaf or air), spring hangers, shackles and U-bolts, no cracks, breaks or shifting. Brakes • Condition of brake drums. With brakes released, look for a noticeable gap between lining and drum. (This check cannot be made if dust covers are in place.) •...
Page 215 206 OPERATION In the Cab • Check steps and grab handles for looseness or breakage. Also, clean them if there is any substance that makes them slippery, which makes cab entry/exit hazardous. • Start the engine. If equipped, check that exhaust rain cap opens when accelerating engine.
Page 216 OPERATION 207 Sliding Fifth Wheel • Check that fifth wheel is not so far forward that the tractor frame will strike the landing gear during turns. Note: Refer to the trailer manufacturer’s manual for specific information on the trailer checks. Step 9: Trailer Front Area Air and Electrical Connections •...
Page 217 208 OPERATION • Body parts not damaged or missing. Step 11: Right Rear Trailer Wheel Dual Wheels, One or Two Axles • Check condition of wheels and rims. Especially look for cracks, missing lockrings, bent or broken spacers, studs, missing clamps or lug nuts. •...
Page 218 OPERATION 209 • Rear clearance, identification and tail lights clean, operating and proper color. • Reflectors clean and proper color. Cargo Securement • Cargo properly blocked, braced, tied, chained, etc. • Tailboard up and properly secured. End gates free from damage, properly secured in stake pockets.
Page 219 210 OPERATION • Condition of brake drums. With brakes released, look for a noticeable gap between lining and drum. (This check can not be made if dust covers are in place.) • Condition of brake hoses: check for any chafing. •...
Page 220: New Vehicle Break-In
DO NOT OVERFILL. Note: Oil and filter change intervals in this manual pertain to components built by Volvo Truck. For information concerning oil and oil filter change intervals for vendor components, refer to the specific vendor component service literature.
Page 221 • On chassis equipped with AIRTEK™ front axle air suspensions, retorque the U-bolts. • Check the U-bolt torque on the Volvo air suspension at the end of the first 1600 km (1000 miles). After the First 5000 Kilometers (3000 Miles) or Before 6400 Kilometers (4000 Miles) or Before 3 to 4 Months •...
Page 222: Hood Operation
OPERATION 213 HOOD OPERATION WARNING WARNING Avoid tilting the hood under high or Make sure that no one is in the way of gusty wind conditions. Failure to follow the hood when opening or closing. The this recommendation may result in the hood could injure a person under the hood unexpectedly closing, which can hood.
Page 223 214 OPERATION Make sure the hood can be opened fully without hitting anything. There are two methods for opening the hood. 1. Stand in front of the hood with feet in line with the vehicle. Place feet well apart and grasp the recessed handle in the front part of the hood. Transfer the body weight by leaning away from the hood.
Page 224 OPERATION 215 2. Stand at the rear fender edge on the driver side of the vehicle. Lift the hood from under the fender, push the hood forward, release the hood and let it complete the opening movement unaided. W8003546 Two restraint cylinders will engage during the last part of the opening. The cylinders will slow and dampen the hood down to its resting position.
Page 225 216 OPERATION Closing the Hood To close the hood, stand with feet well apart, place hands along the front edge of the hood. Bend the knees and let the leg muscles do the work when lifting. Raise the hood up to the halfway point. Carefully guide the hood down with enough speed that the hood latches lock the hood in place when it comes to its normal resting position.
Page 226 OPERATION 217 Hood Latch (Optional) VNM 200 Day Cab, Short Fairing The VNM Day cab hood is opened by unlocking and releasing both sides of the latch located underneath the left and right-hand side panels. See illustration. W8003446...
Page 227 The chassis fairing on the VN vehicle folds up and down for battery and air tank access. CAUTION DO NOT open fairing while the cab door is open.
Page 228 OPERATION 219 W5001359 W5001358 1 Unlocked Position 2 Locked Position...
Page 229 220 OPERATION Closing and Locking Fairing WARNING Make sure the fairing/steps are locked into position. Failure to lock fairing/steps could result in personal injury due to slip and fall. To close and lock the fairings: Use your fingers to pull the handles to the unlocked position (1) as indicated in the illustration.
Page 230 OPERATION 221 Securing the Fairing/Step Make sure the handle is rotated to the locked position. Pull on the fairing/step to ensure the fairing/step is locked into position. See illustration. W8003196...
Page 231 222 OPERATION LUGGAGE COMPARTMENT WARNING Always place heavy objects in the luggage compartment. Sudden stops or sudden turns could cause personal injury if heavy objects fall from overhead storage shelves. To gain access to the luggage compartments, there is a pull-ring connected to the lock, located at the lower rear corner of the cab door opening, on each side (not shown).
Page 232 OPERATION 223 The door swings out from the bottom on hinges mounted on the top. To assist in opening and to hold the door open, there are two compressed gas cylinders mounted on each door. The door will swing up by itself when pulled out a short distance and then released.
Page 233 There is also a keyless remote entry available. Keys can be made to fit only one vehicle or all the vehicles in a fleet of Volvo vehicles. The key fits in the door lock either way. Insert the key and turn it 1/4 turn counterclockwise to unlock or clockwise to lock the door.
Page 234 OPERATION 225 Note: The vehicle is delivered with two identical keys. If more keys are needed, order them through your authorized Volvo Truck dealer. The door locks are mechanically or electronically operated. The lock is activated by either the key from the outside or the door lock handle from the inside. With mechanical locks, only one door can be locked and unlocked at a time.
Page 235 226 OPERATION With electronic locks, to lock both doors from inside the cab, push the door lock handle forward on either door. The handle will stay in place, indicating the door is locked. Either door can be unlocked without opening the door by moving the door lock handle to the middle position.
Page 236 OPERATION 227 W8003116 To close the door from the outside, place the hand flat against the door lock area and push the door shut. CAUTION DO NOT shut the door by pushing on the door panel. Hard pushing may distort the metal in the door panel. W8003114...
Page 237 228 OPERATION Power Door Locks (Optional) Press button 2 to lock both doors or unlock the passenger door. In the event of a power failure the electrical lock system reverts back to a mechanical functioning system. W8003087 Central Locking The central locking is operated using a remote control. There is no alarm in this unit. The central locking unit provides a means for the driver to electronically control the vehicle’s door locks, for increased personal safety and driver comfort.
Page 238 OPERATION 229 Heated Rear View Mirrors (Optional) Press button 1 once to start electric heating for 15minutes. The indicator light in the button flashes. The heating is on for 15minutes. Hold button 1 in for longer than 1second to start electric heating. The indicator light in the button comes on.
Page 239: Safety Belts
230 OPERATION Power Windows (Optional) Open Window (Auto-Down) 1 Depress the down position (2) on the button for 1second. 2 Release the button. 3 The window opens. The window stops when it is completely open, when the down position (2) on the button is depressed again or when the up position (1) on the button is depressed.
Page 240 OPERATION 231 Safety belt assemblies installed in this vehicle meet FMVSS 209, "Type 1" and "Type 2" requirements. They are recommended for all persons weighing over 25 kg (50 lb.). T8009149...
Page 241 232 OPERATION A child restraint system should also be provided for each child weighing 25 kg (50 lb.) or less. It should meet the requirements of FMVSS 213, "Child Restraint System." Carefully read and follow all manufacturer’s instructions on installation and use. Be certain the child remains in the restraint system at all times while the vehicle is in motion.
Page 242 OPERATION 233 Operating the Safety Belt To fasten the safety belt, pull the belt out from the retractor and insert the latch into the buckle. Verify proper lock of the latch by pulling on the latch. Adjust the slack by pulling on the top part of the belt until the lower part, or the part that crosses the lap, is adjusted to fit "snug."...
Page 243 234 OPERATION The buckle portion of the safety belt system is different depending on the seat option chosen. The National Standard and Comfort seat has a separate buckle that is attached to a floor anchor by a seat strap. This seat strap is not adjustable, and does not need to be adjusted.
Page 244 OPERATION 235 Always adjust the clip so that there is a maximum of 25 mm (1 inch) of slack between the belt and chest (about two fingers width). If a larger slack is allowed, the effectiveness of the safety belt is decreased in the event of a collision. W8001837...
Page 245 236 OPERATION Sleeper Safety Restraint DANGER Anytime the vehicle is in motion, a DANGER passenger using the sleeper bunk should be strapped in using the safety restraint. Always use the safety restraint when The top bunk should always be used the vehicle is in motion.
Page 246 OPERATION 237 Fasten the restraint by connecting the buckle with the latch. Make sure the belts are not twisted. Test the latch connection by pulling on the belt. If they come apart, reconnect and test again. If the connection cannot be made, replace the belt before using the bunk for sleeping during driving.
Page 247: Safety Restraint Vn 430, Vn 630, Vn 670
Connect the restraint to the back wall and the buckles on the floor. Connect the side tethers and adjust the straps to form a "tent" over the bunk (VN 670 upper bunk does not have the "tenting" feature).
Page 248 OPERATION 239 W8003169 Upper Bunk W8003170 Lower Bunk...
Page 249 240 OPERATION Safety Restraint VN 730 Connect the restraint to the back wall first. The wall connectors are located on the back wall. Connect the lower part of the restraint to the lower buckles. Connect the side tethers and adjust the straps to form a "tent" over the bunk.
Page 250 OPERATION 241 W8028593 42-Inch Lower Bunk...
Page 251 242 OPERATION W8028594 Upper Bunk...
Page 252 OPERATION 243 Safety Restraint VN 780 Connect the restraint to the back wall first. The wall connectors are located in the storage units. Connect the lower part of the restraint to the lower buckles. Connect the side tethers and adjust the straps to form a "tent" over the bunk.
Page 253 244 OPERATION Inspection DANGER A damaged safety belt, whether visibly DANGER damaged or not, could result in serious personal injury or death in the event of Failure to properly inspect and maintain an accident. The safety belt systems the safety belts can cause serious should be replaced at least every five personal injury or death.
Page 254 OPERATION 245 Check the belts, buckles, latch plates, retractors, anchorages, and guide loops to ensure that they are working properly. Look for loose/damaged parts (without disassembling) that could keep the restraint system from working properly. If the safety belt, retractor and hardware were in use during a collision, they must be replaced.
Page 255 246 OPERATION The D-loop web guide is an area where almost constant movement of the safety belt webbing occurs because of the relative movement between the seat and the cab. This constant movement forms an area where wear will often occur. The webbing must be closely examined to determine if there are any cuts, fraying or extreme wear in the webbing.
Page 256 OPERATION 247 Check the buckle by inserting the latch and verifying proper operation. Determine if the latch plate is worn or deformed. Check the buckle and latch casing for cracks or breakage. W8001404...
Page 257 248 OPERATION The retractor web storage device is mounted on the B-pillar, just behind the door in the cab. The retractor is the heart of the safety belt system and can be damaged if abused, even unintentionally. Check the retractor web storage device operation to ensure that it is not locked and that it spools out and retracts the webbing properly.
Page 258 OPERATION 249 W8001387...
Page 259 Once replacement of the safety belt has been determined necessary, be certain that it is replaced only with a Volvo original replacement safety belt. See your authorized Volvo Truck dealer for replacement. Your Volvo safety belt system has been developed and tested specifically for heavy trucks.
Page 260: Seats, General
Several seats can be used in the vehicles. If the seat installed in the vehicle is not explained in this section, see your authorized Volvo dealer. Before adjusting or fastening the seat belt, move the seat forward or rearward and adjust the seat height as necessary.
Page 261: National Standard Seat
252 OPERATION NATIONAL STANDARD SEAT Seat Adjustments W8002745 National Standard Seat 1 Backrest Tilt: By rotating the round handle, the backrest recline angle can be adjusted within 12 degrees. 2 Cushion Front Tilt and Length: Pulling the handle up and out adjusts the tilt and length of the seat cushion.
Page 262: National Comfort Seat
OPERATION 253 NATIONAL COMFORT SEAT Some National Comfort seats are equipped with a BackCycler® feature. Some National Comfort seats have a swivel mount. Seat Adjustments W8002744 National Comfort Seat 1.Seat Adjustment 5.Lumbar Support Fore and Aft Adjustment 2.Isolator Lock 6.Recliner Tilt 7.Armrest Angle 3.Cushion Tilt 4.Ride Height...
Page 263 254 OPERATION Bostrom Comfort Seat Some Bostrom Comfort seats have a swivel mount. W8002744 National Comfort Seat 1.Seat Adjustment Fore and Aft 5.Ride Height Adjustment 2.Isolator Lock 6.Lumbar Support Adjustment 3.Dampening Adjustment 7.Recliner Tilt 4.Cushion Tilt 8.Armrest Angle Adjustment...
Page 264: Passenger Seats
OPERATION 255 PASSENGER SEATS National Bench Seat The bench passenger seat has the option for a two-man storage seat. The base of the seat is a storage box that is accessed by lifting the seat cushion up. W8003482 National Bench Seat...
Page 265 256 OPERATION National Toolbox Seat The toolbox passenger seat has an optional accessible or non-accessible toolbox in the base of the seat. If the toolbox is an option, the storage box is accessed by lifting the seat cushion up. Note: There is a release latch behind the seat. W8003146 National Toolbox Seat...
Page 266 OPERATION 257 Bostrom Toolbox Seat W8003851 Bostrom Toolbox Seat 1 Seat Cushion Release Lever The toolbox passenger seat has an optional accessible or non-accessible toolbox in the base of the seat. If the toolbox is an option, the storage box is accessed by lifting the seat cushion up.
Page 267 258 OPERATION No Passenger Seat (Optional) WARNING Using a temporary passenger seating without the benefit of proper seat mounting and safety belt can, in the event of a loss of control of the vehicle, cause serious personal injury or death. In vehicles with no passenger seat installed, DO NOT let a passenger ride on temporary seating.
Page 268: Engine Operation
OPERATION 259 ENGINE OPERATION General Proper operation, driving techniques and maintenance are key factors in obtaining the maximum life and economy from a modern turbocharged diesel engine. This section has operational information about the components that make up the engine. When changing gears, avoid lugging to extend engine life.
Page 269: Immobilizer Feature
Exhaust vapor may be visible during a cold start. If exhaust smoke is visible during engine operation, this indicates a problem with the exhaust aftertreatment system. Take the vehicle to an authorized Volvo Truck dealer immediately. IMMOBILIZER FEATURE Volvo Engines Only The Immobilizer Feature is used to prevent the engine from starting.
Page 270 OPERATION 261 If the vehicle has not been placed in the Immobilizer Mode during the previous key-off, the driver will be able to start the vehicle as normal. After the password is entered (at shutdown) "Security Mode Active" is displayed. W3006349...
Page 271: Control Awareness Feature
262 OPERATION CONTROL AWARENESS FEATURE Volvo Engines Only Volvo engine and transmission. In addition, it provides a mechanical safety to the existing Power Take-Off (PTO) functionality. • Parameters are set in VCADS. If the vehicle exceeds the maximum vehicle speed...
Page 272: Fuel Economy Driving
OPERATION 263 FUEL ECONOMY DRIVING General The absolute fuel consumption (counted in liters per 100 kilometers or miles per US gallon) is determined by a large number of circumstances which can be related to one of the following main areas: •...
Page 273 A modern heavy-duty vehicle requires regular and preventive maintenance to ensure that all its components function as they should. Use the recommended preventive maintenance (PM) program that Volvo Trucks North America has developed for the vehicles. This ensures optimal energy efficiency from all components that are...
Page 274 OPERATION 265 Brakes Dragging brakes increase fuel consumption. They should be checked regularly. It is important that the release action of the air valves is fast and that the moving parts of the wheel brakes are checked for good adjustment and operation. Axles An axle out of alignment increases rolling resistance.
Page 275 266 OPERATION External Environment Under unfavorable conditions, the external environment can have a negative effect on fuel consumption. This can be broken down into two main groups: weather and wind, and the nature of the roads. Rain, snow, icy conditions and headwinds have a large negative impact on fuel economy, as do hilly roads and uneven road surfaces.
Page 276 Starting the Engine Start the engine according to the instructions in the operator’s manual of the engine manufacturer (for a Volvo engine, see "STARTING THE ENGINE" “STARTING THE ENGINE”, page 298). A proper start, especially during the cold season, saves fuel and reduces engine wear.
Page 277 268 OPERATION Air Tanks All air tanks on the vehicle should be drained daily. Empty any moisture from air tanks by pulling the drain valve wire or by opening the drain cocks and allowing the air pressure to drain completely. Make sure the drain cocks close properly after draining.
Page 278 OPERATION 269 Trucks with automated Meritor Transmission: Drain the transmission air supply tank located on the right-hand rail daily to check for contamination, water, oil, etc. Charging Air to Another Vehicle DANGER Before working on a vehicle, set the parking brakes, place the transmission in neutral, and block the wheels.
Page 279: Cruise Control
270 OPERATION CRUISE CONTROL DANGER DO NOT use the cruise control in heavy traffic, with ice/snow on the road or during other unfavorable conditions. This may lead to a loss of vehicle control, causing a vehicle crash, personal injury or death. Engaging W3002499 To engage and set desired speed:...
Page 280 OPERATION 271 Note: The cruise control cannot be engaged at speeds below approximately 30 km/h (18 mph). Disengaging The cruise control is disengaged if the brake is depressed, or if the cruise control switch is set to OFF. If the ignition key is turned back to the accessories position (I), the cruise control system will automatically be disengaged.
Page 281: Volvo Engine Brake (I-Veb)
RESUME. Volvo Engine Brake (I-VEB) The Volvo Engine Brake (I-VEB) is standard on the Volvo 16F engine and optional on the 13F engine. It has a higher braking effect than the variable geometry turbo brake. When the engine brake is in the A position and cruise control is engaged, the engine brake automatically engages if vehicle speed exceeds the set cruise control speed.
Page 282: Brake Operation
OPERATION 273 BRAKE OPERATION Brake Safety Information DANGER DO NOT ride the brakes going down DANGER steep hills. The brakes could overheat and lose their effectiveness. Always DO NOT inspect or adjust parts or choose a low gear before going down components in the brake system without the grade and reduce speed to help setting the parking brake, placing the...
Page 283 274 OPERATION DANGER DANGER DO NOT operate the vehicle when there The brake system is a critical vehicle is a malfunction in the compressed air safety system. For your safety and system. An air brake system with leaks for those around you, follow the or other malfunctions may prevent the recommended preventive maintenance brake system from operating properly.
Page 284 General All Volvo vehicles are designed to meet or exceed all applicable federal brake standards and regulations. They use a dual circuit, compressed air system. It consists of two independent brake systems that use a single set of brake controls. Each circuit is supplied by its own compressed air tank.
Page 285 276 OPERATION DANGER Never release or drive a truck that has a brake discrepancy — no matter how minor — until it has been repaired or corrected. Failure to repair brake discrepancies can result in compromised brake efficiency and may lead to loss of control of the vehicle resulting in severe personal injury or death.
Page 286 OPERATION 277 W3006936 W3006937 Gauge 1 and Gauge 2 Before operating the vehicle, check the air gauges which indicate air pressure. They should not register less than 420 kPa (65 psi).
Page 287 278 OPERATION Both circuits are piped into a dual brake valve, which simultaneously applies front and rear axle service brakes during each brake application. In the event of a failure in either one of the circuits, the other circuit becomes the emergency circuit for applying the brakes.
Page 288 OPERATION 279 W3005171 Master Warning Tell-Tale An important feature of the brake system is that an automatic spring brake application does not take place as a result of an air loss in only one of the two circuits. In this case, brake control remains in the foot brake valve.
Page 289 280 OPERATION Foot Brake Valve The foot brake valve is directly connected to the brake pedal. The valve gives a progressive output against the pedal travel. This allows better control of the pressure in the first half of the pedal travel. In the last half of the pedal travel, the pressure output increase is faster.
Page 290 OPERATION 281 1 The best possible stop will be made when the first brake application is as firm as the speed and road condition permit. Then, ease off as the speed is reduced. Never apply the brakes lightly at first and increase the pressure as the speed diminishes. 2 DO NOT fan the brake pedal.
Page 291: Parking Brake/Trailer Supply Valves
282 OPERATION Parking Brake/Trailer Supply Valves Trucks/Tractors may have two air control valves on the instrument panel: • Trailer Supply (red octagonal knob) • System Park (yellow diamond knob) W5001116 The System Park valve knob (yellow) should be pushed in first, after sufficient air pressure is built up (apply foot brake to prevent vehicle from rolling).
Page 292 Bobtail Parking Brake Release VN models have engines equipped with engine electronic control units (EECU). These have two features that may impact the brake system. One is the anti-stall device in the EECU which senses torque demand and automatically controls the engine to compensate and maintain speed.
Page 293 284 OPERATION There is also an engine shut-down device in the EECU that shuts down the engine after a pre-programmed time in order to save fuel. This is activated when the yellow parking brake knob is pulled out. Therefore, some drivers park and release the parking brakes using only the red knob to keep the engine running.
Page 294 OPERATION 285 Spring Brake for Parking DANGER Before working on or inspecting a DANGER vehicle, set the parking brakes, place the transmission in neutral and block Never leave the vehicle without being the wheels. Failure to do so can result in certain the parking brakes are set or that unexpected vehicle movement and can other precautions are taken to prevent...
Page 295 286 OPERATION W5001430 The parking brake spring tension is sufficient to hold a fully loaded vehicle on maximum grades permitted on modern highways, provided the brake drums and linings are in good condition and the brakes are properly adjusted. CAUTION DO NOT use the spring parking brakes if the service brakes are hot, such as after descending a steep grade.
Page 296 OPERATION 287 There are several ways to determine if the parking brakes have been set. By pulling out the yellow knob: • An audible rush of air will be heard when the parking brake knob is pulled. The air exhausts from the park brake valve itself and from the spring brake chambers on the rear axle(s).
Page 297: Trailer Brake Hand Control
288 OPERATION Trailer Brake Hand Control DANGER DANGER The trailer hand brake control is not a DO NOT use the trailer brake hand parking brake valve and must not be control as a parking brake. The brakes used as one. This brake is not designed could release and the vehicle could roll, to hold the vehicle stationary.
Page 298 OPERATION 289 W5001442 The "121" Brake Standard This manual refers occasionally to "121" brakes. Although some operators believe "121" only applies to vehicles equipped with anti-lock devices, the "121" standard applies to all vehicles that are capable of on-highway operation. The "121"...
Page 299: Anti-Lock Braking System (Abs)
290 OPERATION ANTI-LOCK BRAKING SYSTEM (ABS) The vehicle has a standard brake system, equipped with an electronic speed monitoring and control system, Anti-lock Braking System (ABS). ABS monitors wheel speed continuously but is not involved in controlling the wheel speed unless there is an emergency.
Page 300 If any of the ABS tell-tales come on during driving or do not go out after a short time after turning on the ignition, take the vehicle to an authorized Volvo Truck dealer to repair the ABS or brake system. The vehicle can still be driven with a problem in the ABS system.
Page 301: Volvo Enhanced Stability Technology
VOLVO ENHANCED STABILITY TECHNOLOGY Some vehicles are equipped with Volvo Enhanced Stability Technology (VEST). VEST is an advanced stability control system designed to provide both roll stability and under- and over-steer correction in a wide variety of driving conditions. VEST continuously monitors a variety of vehicle parameters and sensors (including steering angle sensor) to determine whether the vehicle is reaching critical stability threshold.
Page 302 OPERATION 293 W3000962 The TCS includes a switch to turn off the function. When the switch is in the OFF position, the TCS operates normally to increase traction if the drive wheels begin spinning. When the switch is pressed once, the TCS tell-tale in the instrument cluster blinks continuously, indicating that the TCS is in mud/snow mode.
Page 303: Tire Pressure System (If Equipped)
294 OPERATION Tire Pressure System (If Equipped) The tire pressure/temperature sensor is attached to each wheel with a stainless steel tire strap and is located in line with the wheels valve stem. This self powered sensor is responsible for transmitting the tire cavity pressure and temperature to the system via a radio frequency sign that is received by the system antenna.
Page 304: Air Pressure Monitoring And Alert
OPERATION 295 Air Pressure Monitoring and Alert The air pressure of each programmed tire can monitored by the operator via the DID. The system monitors tire air pressure in all cab tires independently and alerts the operator of low tire pressures in two stages; 1.
Page 305: Tire Temperature Monitoring And Alert
296 OPERATION Tire Temperature Monitoring and Alert The cavity air temperature of each programmed tire can monitored by the operator via the DID. The system monitors cavity air temperature in all cab tires independently and alerts the operator when any of these tire cavity temperature reaches 77°C (170°F). The operator is alerted by a red flashing telltale light/buzzer that is displayed in the instrument cluster.
Page 306: Vehicle Speed Retarding Devices
Volvo Variable Geometry Turbo Brake The variable geometry turbo brake is standard with the Volvo 11F and 13F engine. It uses software to close the variable geometry turbocharger to create retardation. Note: For both variable geometry turbocharger and engine brakes, use a "one gear"...
Page 307: Starting The Engine
Note: For cold weather starting, see “COLD WEATHER OPERATION”, page 306. These starting and operating procedures should be followed for all engines. For more detailed information about design and function on a non-Volvo engine, read the operator’s manual from the engine manufacturer.
Page 308 Information Display Manual. 5. Turn the key to the start position. Release key as soon as the engine has started. For the Volvo engine, the preheater can be engaged to help starting in cold temperatures. CAUTION If at start-up, or thereafter, the oil...
Page 309 300 OPERATION W3006933 6. When the engine has started, it takes a while to send lubricating oil to all bearings and shafts, and between pistons and liners. Wait for the oil pressure gauge to settle at a normal level, then bring engine speed up gradually. Increase speed as it warms up.
Page 310 OPERATION 301 Engine Overspeed This vehicle is equipped with a diesel engine and should not be operated in an area with a concentration of hydrocarbon vapors (for example gasoline or diesel fuel fumes). Be especially cautious of low-lying or closed-in areas. The vapors may be drawn into the engine through the air intake and cause the engine to overspeed.
Page 311 Release the switch. The engine speed will drop to the default low idle (Volvo engines), or a slight drop in idle speed will occur (Cummins). 4 The idle speed is adjusted up with the SET+ switch. Each time the SET+ switch is pressed momentarily, idle speed will increase approximately 10 rpm (the speed cannot be increased above the maximum allowed by the engine manufacturer).
Page 312 The idle shutdown timer can be programmed to shut the engine down after a specific engine idling time. This programming cannot be changed by the operator, but can be done using special tools. Contact your authorized Volvo Truck dealer for details. The permitted idle time can be set to the following time intervals: Volvo –...
Page 313 304 OPERATION Downhill Operation CAUTION DO NOT exceed engine manufacturer’s recommended maximum engine speed. Engine damage can occur. If equipped with an engine or exhaust brake, DO NOT exceed 2300 rpm. On a downgrade, do not coast with the clutch pedal depressed or the transmission in neutral.
Page 314 OPERATION 305 Stopping the Engine Allow the engine to slow down and idle for 3 to 5 minutes before shutting it off. This allows the turbo to slow down and the cooling system to dissipate the engine heat. Switch the engine off by turning the ignition key to the B, or OFF, position. DANGER CAUTION Failure to take the necessary precautions...
Page 315: Cold Weather Operation
306 OPERATION COLD WEATHER OPERATION Volvo Engine Cold Start Note: These cold start instructions are for Volvo engines only. For other engine makes, see the manufacturer’s handbook. DANGER DO NOT use ether or other combustible starting aids on any Volvo engine.
Page 316 (while still observing the 30 second maximum cranking time). Ether Start DANGER DO NOT use ether or other combustible starting aids on any Volvo engine. Introduction of ether or similar starting aids could cause a fire or explosion resulting in severe property damage, serious personal injury or death.
Page 317 Additions to the vehicle, such as heated fuel filters, fuel tank heater, engine block heater, winterfront, etc., can make winter operation easier. Contact your authorized Volvo Truck dealer for the correct accessories and information about installation.
Page 318 OPERATION 309 For cold weather operation, follow these recommendations: • When starting the engine in temperatures below 15°C (5°F), use engine lubricants of lower viscosity. See the Operator’s Manual Vehicle Maintenance for additional information. • When the temperature is below freezing, make sure the concentration of antifreeze in the coolant is sufficient to prevent freezing.
Page 319 310 OPERATION Engine Block Heater (Optional) An electric engine block heater can be installed for keeping the coolant hot when the vehicle is parked. The heater is mounted through the side of the engine block with the heater coils in the coolant jacket. The heater does not interfere with normal operation and can be permanently installed.
Page 320 OPERATION 311 Oil Pan Heater (Optional) Oil pan heaters aid low temperature starting by improving oil flow to critical parts in the engine. This helps prevent engine wear. They are similar to block heaters and are wired into the same plug as the engine coolant heater. Fuel Heater Filter (Optional) If running in very cold weather, a heated fuel filter should be added.
Page 321 These heaters are thermostatically controlled and will automatically raise the fuel temperature to an optimum level. Winterfront Volvo Trucks North America does not recommend the use of winterfronts, shutters or any other shield in front of the grille or radiator package under normal circumstances.
Page 322: Fifth Wheel Instructions
OPERATION 313 FIFTH WHEEL INSTRUCTIONS Fifth Wheel General Information DANGER Always have all fifth wheel maintenance and repairs done by a qualified technician. An incorrect repair can cause the trailer to separate from the tractor causing an accident with serious personal injury or death.
Page 323 314 OPERATION If the fifth wheel is equipped with a sliding mounting, follow the advisory labels attached to the component. Also, read the literature provided by the manufacturer. DANGER Always keep the fifth wheel plate well lubricated to prevent binding between the tractor and trailer.
Page 324 OPERATION 315 W9000242 Open — This is the position the fifth wheel is in after the trailer is uncoupled. The jaw is open and the operating rod is now dropped down and can be freely moved around. The safety latch is rotated toward the rear of the fifth wheel. This is the position the fifth wheel must be in when being coupled to a trailer.
Page 325 316 OPERATION Fifth Wheel Slider (Optional) Open — This is the position the fifth wheel is in after the trailer is uncoupled. The jaw is open and the operating rod is now dropped down and can be freely moved around. The safety latch is rotated toward the rear of the fifth wheel.
Page 326 OPERATION 317 Unlocking the Fifth Wheel Always check out the entire fifth wheel before attempting to couple to a trailer (ASF fifth wheel is shown). • If not lubricated properly, add grease to the top of the fifth wheel plate. •...
Page 327 318 OPERATION Using a slight upward motion, pull the operating rod out until the operating rod shoulder is outside the fifth wheel operating slot. W9000202 When the shoulder of the operating rod is outside of the operating slot, raise the operating rod handle to its maximum upward position.
Page 328 OPERATION 319 Release the operating rod. The upper shoulder of the operating rod should now be in contact with the plate casting above the operating slot. The fifth wheel is now in the lockset position and a trailer can be coupled. W9000274 Trailer Coupling Procedures DANGER...
Page 329 320 OPERATION Using the following procedures, inspect the equipment before coupling to a trailer: Make sure the fifth wheel is properly lubricated and the jaw is in the open position. W9000659 WARNING If the jaw is not in the open position, use a pry bar to rotate the jaw to the open position.
Page 330 OPERATION 321 Make sure the plate is tilted downward to the proper position at the rear. W9000236 Make sure the mounting of the fifth wheel to the tractor frame is tight and in good condition. Make sure the plate is tilted downward to the proper position at the rear. If using a sliding fifth wheel, make sure the slide locking plungers are fully engaged.
Page 331 322 OPERATION Chock the trailer wheels. Use two chocks (both on the front and rear of the wheel) on both sides of the trailer. Back up close to the trailer, centering the kingpin on the throat of the fifth wheel, and STOP.
Page 332 OPERATION 323 CAUTION Attempting to couple with the trailer at an improper height could result in a false or improper couple and cause damage to the tractor, fifth wheel and trailer. Check to see that the trailer is at the proper height for coupling. The leading edge of the trailer plate should initially contact the fifth wheel top plate surface about 200 mm (8 in.) behind the pivot point as the tractor backs under the trailer.
Page 333 324 OPERATION As an initial check, pull forward to test the completeness of the coupling. W9000237 A direct visual check is required to ensure proper coupling. Several types of improper couplings will pass the initial pull test. Sound is not reliable. Do not take for granted that you are properly coupled.
Page 334 OPERATION 325 Make sure the trailer kingpin is in the jaw slot and that the jaw is closed behind the pin. The kingpin should not overhang the fifth wheel or be caught in the grease groove. To verify that the kingpin is actually in the fifth wheel slot and the jaw is closed, the pin must be visually inspected from the rear.
Page 335 326 OPERATION W9000240 Make sure the operating rod is fully retracted, the safety latch is positioned above the handle, and the latch swings freely. If the fifth wheel is equipped with a manual secondary lock, check to see that it is properly engaged.
Page 336 OPERATION 327 Trailer Uncoupling Procedures For Tractors With Air Ride Suspension Set the system park brake on the tractor. Set the trailer brakes by pulling out the trailer air supply knob. W5001433 Chock the trailer wheels. Use two chocks (one on the front and one on the rear of the wheel) on both sides of the trailer.
Page 337 328 OPERATION Disconnect the light cord and air brake lines. Use the dummy air couplings to keep foreign material from entering the brake lines. Unlock the fifth wheel. Note: If the operating rod is too difficult to pull, back the tractor up slightly to relieve any kingpin load against the fifth wheel jaw.
Page 338 OPERATION 329 W9000239 Select the "UNCOUPLE" position (push down the latch and press in the bottom part of the switch) on the suspension control switch to deflate the air springs. W3006386...
Page 339 330 OPERATION Wait about 30 seconds for the air springs to deflate. W9000238 With the suspension lowered, pull clear of the trailer and immediately select the "RIDE" position (press the top part of the switch in) on the suspension control. This restores the suspension to operating height.
Page 340 OPERATION 331 After the trailer is uncoupled, the fifth wheel will be in the open position. The operating rod will drop and can be moved around freely. W9000203...
Page 341: Operating The Fifth Wheel Slider
332 OPERATION Operating the Fifth Wheel Slider CAUTION The trailer must be stopped and the trailer brakes locked, or damage to the tractor and/or trailer may result from uncontrolled sliding of the fifth wheel. Stop the tractor and trailer in a straight line on level ground. Lock the trailer brakes by pulling out the Trailer Supply knob.
Page 342 OPERATION 333 W9000205 Slowly drive the tractor forward or backward to position the fifth wheel. After sliding the fifth wheel to the desired position, engage the slide locking plungers by moving the cab switch to the "LOCK" position (press in the top part of the switch). W3001346...
Page 343 334 OPERATION CAUTION DO NOT operate the vehicle if the plungers are not fully engaged and the trailer landing gear is not fully retracted. Doing so may cause damage to the tractor, trailer and landing gear. Visually check to see that the slide plungers are fully engaged. It may be necessary to leave the trailer brakes locked and to move the tractor slightly to engage the slide plungers into the rail.
Page 344 OPERATION 335 Clutch DANGER General Before starting the engine, set the parking brakes and place the transmission in neutral. Failure to do so can result in unexpected vehicle movement and can cause serious personal injury and death. DO NOT allow the clutch to slip excessively. This would cause excessive heat to be generated and the clutch will be damaged and bring on premature failure.
Page 345: Performance Bonus Feature
The reward of higher RSL increases driver productivity and income. It also promotes increased driver and fuel efficiency. To obtain more information about the Performance Bonus Feature, contact your Volvo dealer. Note: The Performance Bonus Feature is programmable (by your dealer) using VCADS Pro or VCADS Pro Elite.
Page 346 OPERATION 337 Rolling Buffer The "rolling buffer" is set to measure distance driven. The buffer may be set at a short or long distance. A short buffer results in a faster reward, (or loss of reward) which provides driving fuel economy training to the driver, permitting the driver easy memory of the input to the buffer during this short period of time.
Page 347: Performance Bonus Guide
338 OPERATION W3028721 Performance Bonus Guide Volvo Engines Only The Performance Bonus Guide is an aid that provides comprehensive feedback to the driver about the optimum engine operating range during a trip. If adhered to, this results in improved fuel efficiency. Icons in the Driver Information Display (DID) guide drivers to the most efficient engine operating range for any given engine load and speed.
Page 348 OPERATION 339 Status Symbols Meaning Engine Operating in the Sweet Spot Mode. Fuel consumed in this mode will count 100% toward the Sweet Spot Percentage. W3006755 Engine Operating in a less efficient area of the Sweet Spot Mode. Fuel consumed in this mode will count 50% toward the Sweet Spot Percentage.
Page 349 340 OPERATION Symbol Meaning Performance Bonus Guide (shows Sweet Spot Percentage [Large Symbol]) W3006755 Driving Mode The Sweet Spot Status icons are displayed at the bottom left of the DID screen. The Sweet Spot symbol is displayed at the top of the screen underneath Fuel Data. The Sweet Spot percentage page is displayed in the Fuel Data menu.
Page 350 DID also displays the Sweet Spot target percentage in parenthesis. W3028762 The Performance Bonus Guide is a standard feature for all Volvo engines on vehicles equipped with the mid or high level instrument cluster. Performance Bonus does not work with the basic instrument cluster.
Page 351: Axles
342 OPERATION AXLES Differential Locks CAUTION DANGER Never operate the vehicle with the differentials locked any longer than is DO NOT drive on dry, paved surface necessary, as this places a great strain on with the differential locks engaged. the axles and may cause rapid tire wear. The vehicle will strive to maintain a straight line.
Page 352 OPERATION 343 W3001991 The differential lock should be used on icy or slippery surfaces. As soon as the slippery surface has been passed, the differential lock should be disengaged. Differential locks must not, under any circumstances, be engaged when in a wheel-spin situation.
Page 353 344 OPERATION CAUTION DO NOT rely on gauges to determine axle pressure. Weight must be verified on scales, and pressure in the air springs should then be adjusted accordingly. Regulators for adjusting the air spring pressure are located on the outside of the cab, below the rear corner of the driver side door.
Page 354: Volvo, Us10 Emissions Solution
Volvo, US10 Emissions Solution 345 Exhaust Aftertreatment System W2029933 1. Selective Catalytic Reduction (SCR) Catalyst 2. Aftertreatment DEF Dosing Unit 3. Aftertreatment Diesel Particulate Filter (DPF) 4.Aftertreatment DEF Tank...
Page 355 346 Volvo, US10 Emissions Solution Safety Information Volvo utilizes the use of a Diesel Particulate Filter (DPF) and Selective Catalytic Reduction (SCR) to meet EPA2010 emissions. The system is designed to require very little driver interface to maintain correct operation. The technology utilizes a passive regeneration;...
Page 356: Exhaust Aftertreatment System Components And Operation
Volvo, US10 Emissions Solution 347 Exhaust Aftertreatment System Components and Operation Selective Catalytic Reduction (SCR) Selective Catalytic Reduction (SCR) is an emissions-reduction technology with the ability to deliver near-zero emissions of nitrogen oxides (NOx), a smog-causing pollutant and greenhouse gas. SCR’s performance has been proved in millions of miles of real-world truck operations in other countries, as well as in long-term field tests in the U.S.
Page 357 348 Volvo, US10 Emissions Solution W2031651 1. Diesel Engine 2. Aftertreatment DEF Tank 3. Aftertreatment DEF Pump 4. Aftertreatment DEF Dosing Unit 5. Aftertreatment Diesel Particulate Filter (DPF) 6. Selective Catalytic Reduction (SCR) Catalyst 7. Aftertreatment DEF Tank Gauge...
Page 358 7 The system notifies the driver when it is time to refill tank with DEF. The Volvo SCR system is simple and effective, with few components. It consists of a Aftertreatment DEF tank positioned near the standard diesel tank, plus a Aftertreatment DEF pump, Aftertreatment DEF Dosing unit and SCR catalyst.
Page 359 350 Volvo, US10 Emissions Solution W2055492 Horizontal SCR, full sive W2055493 Horizontal SCR, compact sive CAUTION Do not put diesel fuel in the Aftertreatment DEF tank. Diesel fuel, if sprayed into the hot exhaust along with the DEF, could ignite...
Page 360: Diesel Exhaust Fluid (Def)
Volvo, US10 Emissions Solution 351 W3036787 Diesel Exhaust Fluid (DEF) Diesel Exhaust Fluid (DEF) is a reactant that’s key to the SCR process. It’s a nontoxic, aqueous solution of urea and ultra-pure water. Urea is a compound of nitrogen that turns to ammonia when heated.
Page 361 352 Volvo, US10 Emissions Solution Diesel Exhaust Fluid (DEF) Handling When handling DEF solution, it is important that electrical connectors to be connected or well encapsulated, otherwise there is a risk that the DEF will cause oxidation that cannot be removed. Water or compressed air do not help, since DEF quickly oxidizes certain metal.
Page 362 Volvo, US10 Emissions Solution 353 Diesel Exhaust Fluid (DEF) Availability DEF will be available in 2.5-gallon containers, 55-gallon drums, 275 gallon IBC and in bulk storage for fleet locations, truck stops and dealerships. All major truck stops, dealers and distributors will carry DEF.
Page 363: Aftertreatment Diesel Particulate Filter (Dpf)
354 Volvo, US10 Emissions Solution Aftertreatment Diesel Particulate Filter (DPF) W2030326 CAUTION Use of diesel fuel other than ULSD and engine oils other than EO-O Premium Plus (or VDS-4), will adversely affect performance, efficiency and durability of the Aftertreatment DPF system and the engine, to the point where the engine may not run at all.
Page 364 Exhaust vapor (water condensation) may be visible during a cold start. If black exhaust smoke is visible during engine operation, this indicates a problem with the exhaust Aftertreatment system. Take the vehicle to an authorized Volvo Truck dealer immediately. Vehicles equipped with a 2010 emission compliant engine have an exhaust Aftertreatment system which includes a Selective Catalytic Reduction (SCR) system and a Catalyzed Aftertreatment Diesel Particulate Filter (DPF).
Page 365: Aftertreatment Control Module (Acm)
356 Volvo, US10 Emissions Solution Aftertreatment Control Module (ACM) W2029917 The ACM controls the following components in the exhaust Aftertreatment system: • Aftertreatment DEF Dosing Unit • Aftertreatment DEF Tank Heater Valve • Aftertreatment DEF Line Heaters • Aftertreatment DEF Pump •...
Page 366: Exhaust Aftertreatment System Operation
Volvo, US10 Emissions Solution 357 Exhaust Aftertreatment System Operation The stalk switch control lever is used to interact with the Driver Information Display (DID) in the center of the instrument cluster. The lever is located on the right-hand side of the steering wheel.
Page 367 358 Volvo, US10 Emissions Solution Aftertreatment Menu 1 The Aftertreatment system menu is in the DID. Press the Esc button to display the main menus in the DID. 2 Use the up and down buttons on the stalk switch to scroll to the Aftertreatment menu.
Page 368: Aftertreatment Dpf Regeneration
Regeneration that are stopped and never restarted at a later time, however, will require that the vehicle be taken to an authorized Volvo Truck dealer to have the Aftertreatment parked Regeneration manually started with special service tools.
Page 369 360 Volvo, US10 Emissions Solution There are two types of Aftertreatment DPF Regeneration: Passive regeneration and Parked regeneration. Passive Regeneration occurs when the exhaust gas within the aftertreatment system is hot enough to burn soot without injecting additional fuel into the DPF system.
Page 370 Volvo, US10 Emissions Solution 361 The Aftertreatment DPF Regeneration system is self-monitoring. When the Aftertreatment Diesel Particulate Filter is becoming full and Aftertreatment DPF regeneration is needed, the Aftertreatment DPF Regeneration Needed icon on the instrument cluster illuminates and the message ."Parked REGEN Needed" is displayed.
Page 371 362 Volvo, US10 Emissions Solution If the vehicle has not had a parked REGEN completed after the “Parked REGEN Needed” screen displays the vehicle must be stopped. Perform the parked REGEN now. The vehicle will also be in Engine Derate.
Page 372 Volvo, US10 Emissions Solution 363 If a parked REGEN is not done when the” Soot Level High” displays the “Soot Level Critically High” screen displays. W3055333 Soot Level Critically High When the ATS Service DID and the Stop Light illuminates screen displays stop the vehicle immediately and perform a Parked Regen.
Page 373 Required screen displayed may result in a loss of engine performance, reduced horsepower, torque and speed, and temperature derate. Also, the Aftertreatment DPF may become overloaded with soot and require service at a authorized VOLVO dealer. Aftertreatment DPF Regeneration Required cannot be initiated if it is not required.
Page 374 Volvo, US10 Emissions Solution 365 If the conditions are not met and a parked REGEN is attempted the “Parked REGEN Conditions Not Met Check Menu Status” screen displays. W3055181 Parked REGEN Conditions Not Met Scroll to the Aftertreament menu in the Driver information Display (DID) and select “ATS Status”...
Page 375 The Aftertreatment Diesel Particulate Filter may be over its maximum capacity and the engine may shut down. The vehicle must be taken immediately to an authorized Volvo Truck dealer for service. W3005171...
Page 376: Exhaust Aftertreatment System (Ats) Status
Volvo, US10 Emissions Solution 367 Refer to the Exhaust Aftertreatment System Information sun visor label for additional Aftertreatment DPF information. W8056652 Exhaust Aftertreatment System (ATS) Status The ATS status submenus provide information about the conditions required for performing a parked DPF Regeneration.
Page 377 368 Volvo, US10 Emissions Solution To perform a parked Regeneration, the accelerator pedal (AP) must not be depressed, the transmission must be in the neutral position and the vehicle speed must not be zero. W3054889 To perform a parked Regeneration, the park brake must be engaged and there can be no active Diagnostic Trouble Codes (DTC) codes.
Page 378 Temporary lockout prevents performing a parked DPF Regeneration when it is not needed. Permanent lockout prevents performing a parked Regeneration when a condition exists that requires vehicle service. Take the vehicle to a Volvo Truck dealer. A minimum engine temperature (ECT) of 35°C (95°F) is required for parked DPF Regeneration.
Page 379: Driver Warnings And On Board Diagnostics (Obd)
Maintenance section of this manual. emissions related components and alert Instrument Cluster The Aftertreatment icons are located in the applies to Volvo vehicles equipped with a lower left corner of the instrument cluster. Volvo or Cummins engine. Note: The following exhaust...
Page 380 Volvo, US10 Emissions Solution 371 Instrument Cluster Icons Aftertreatment icons are displayed on the instrument cluster. There are three Aftertreatment icons: • Parked Aftertreatment DPF Regeneration Required • High Exhaust System Temperature (HEST) • Aftertreatment DEF Tank Low Level Indicator The Aftertreatment DPF Regeneration Required icon flashes when the Diesel Particulate Filter is full or overfull and regeneration is needed..
Page 381: Malfunction Indicator Lamp (Mil)
372 Volvo, US10 Emissions Solution The Aftertreatment DEF Tank Low Level Indicator icon illuminates when the fluid level is low. It also Flashes when the level becomes critically low. W2029416 Aftertreatment DEF Tank Low Level Indicator (DEF) Malfunction Indicator Lamp (MIL)
Page 382 Volvo, US10 Emissions Solution 373 Aftertreatment DEF Tank Level - Driver Warning & Inducement Aftertreatment DEF tanks are sized to have no less than two times the diesel fuel tank mileage or hour range The vehicle instrument cluster has a Aftertreatment DEF Tank Level Gauge...
Page 383: Aftertreatment Def Quality - Driver Warning & Inducement
374 Volvo, US10 Emissions Solution Aftertreatment DEF Quality - Driver Warning & Inducement Triggers Aftertreatment Amber Warning Inducement DEF Tank Low Lamp Level Indicator None None None Good DEF Quality None None Poor DEF Quality DTC Initial Detected W2029417 Poor DEF Quality...
Page 384: Misfilling Diesel Or Aftertreatment Def Tanks
Volvo, US10 Emissions Solution 375 Misfilling Diesel or Aftertreatment DEF Tanks Although diesel fuel and Aftertreatment DEF caps are clearly labeled and filler necks and nozzles are different accidents can happen. Contamination of fluids by- misfilling of diesel or DEF in the wrong tank may result in vehicle malfunction.
Page 385: Scr Tampering - Driver Warning & Inducement
376 Volvo, US10 Emissions Solution SCR Tampering - Driver Warning & Inducement 1. Disconnected Aftertreatment DEF tank 4. Disconnected Aftertreatment DEF level sensor pump 2. Blocked Aftertreatment DEF line or 5. Disconnected SCR wiring harness dosing unit 3. Disconnected Aftertreatment DEF 6.
Page 386: Warranty And Maintenance
Volvo, US10 Emissions Solution 377 Warranty and Maintenance Exhaust Aftertreatment System Maintenance The vehicle must be taken to an authorized Volvo Truck dealer to remove the ash from the Aftertreatment Diesel Particulate Filter and clean the Aftertreatment Doser. Emissions Maintenance 1.
Page 387: Engine Maintenance Intervals
378 Volvo, US10 Emissions Solution Engine Maintenance Intervals Component Operation Interval Every oil change. Under certain conditions (for example, irregular Fuel Filter Change fuel quality), the fuel/water separator filters may require more frequent replacement. Control lamp indication or 24 Air Cleaner...
Page 388: Engine Gaseous Emission Control Systems
The repair or replacement of defective parts will be made without charge for the cost of parts and, if repairs are made at an authorized Volvo Trucks North America dealership, there will be no charge for labor. Volvo Trucks North America’s obligation under this warranty is limited to the repair or replacement, at Volvo Trucks North America’s option, of any part(s) of the Emission Control Systems of such...
Page 389: Emissions Control System Warranty
380 Volvo, US10 Emissions Solution Emissions Control System Warranty The following engine components are covered by the supplemental emissions control system warranty policy as required by the Federal code of emission regulations. • 1 Turbocharger Assembly Discharge Recirculation Valve •...
Page 390: Engine Gaseous Emissions Control System Warranty
Note: In response to customer requests, Volvo Trucks North America, may build vehicles with engines supplied by other manufacturers. In these cases, each engine manufacturer through its service organization, is responsible for emission control systems warranty on all parts of the engine assembly, as furnished.
Page 391: Emission Control System Warranty — California
Body Builders documentation . Emission Control System Warranty — California The California Air Resources Board and Volvo Trucks North America. are pleased to explain the California emission control system warranty on your new motor vehicle engine. In California, new motor vehicle engines must be designed, built and equipped to meet the State’s stringent anti-smog standards.
Page 392 State of California) Volvo Trucks North America. warrants the Emission Control Systems on each new Volvo diesel engine in a new Volvo truck to comply with all State of California emissions regulations applicable at the time of manufacture of the...
Page 393 384 Volvo, US10 Emissions Solution Qualifications and Limitations: Not covered by the Emissions Control Systems Warranty: • Malfunctions caused by misuse, improper adjustments, modification, alteration, tampering, disconnection, improper or inadequate maintenance and use of improper diesel fuel or DEF. •...
Page 394 Volvo, US10 Emissions Solution 385 Emissions Control System Warranty The following engine components are covered by the supplemental emissions control system warranty policy as required by the California code of regulations. • 1 Turbocharger Assembly Fuel lines to Aftertreatment Doser •...
Page 395 386 Volvo, US10 Emissions Solution • 17 Sensors: Aftertreatment DEF Dosing Valve • • Crankshaft Position (CKP) Aftertreatment DEF Tank • • Camshaft Position (CMP) Aftertreatment DEF Tank • Heater/Sender Engine Coolant Temperature (ECT) • • Aftertreatment DEF Tank Heater Intake Manifold Air Temperature •...
Page 396: Oil Change Intervals
For additional information about oil change intervals, see your Volvo Truck dealer. Also, refer to Bulletin 175-60, Oil and Filters, Volvo Components. For a complete list of approved oils, see your Volvo Truck dealer. Also, refer to Bulletin 175-61, Approved Oils, Volvo Components.
Page 397: Maintenance And Lubrication
Note: Make sure that all fluid levels are at their proper levels. If the fluids are not at their proper levels, add as necessary. Refer to the Operator’s Manual Vehicle Maintenance for information on what types of fluids are recommended for your Volvo vehicle.
Page 398: Towing Procedure
MAINTENANCE AND LUBRICATION 389 TOWING PROCEDURE General WARNING WARNING Vehicles with air fairings are tall. Make sure that the total height of the vehicle, when it is raised up behind the wrecker, If a vehicle with air suspension is lifted does not exceed the maximum allowed by the rear frame member, there is a height for local underpasses.
Page 399 390 MAINTENANCE AND LUBRICATION T0006670 The vehicle may now be towed. It is recommended that a wrecker with a lift bar is used since the service brakes will not function. The system must be filled with air to release the parking brake or follow the mechanical spring brake caging procedures on “Caging Spring Brake Chambers”, page 396.
Page 400 MAINTENANCE AND LUBRICATION 391 Towing Instructions DANGER DO NOT use the tow eyes for raising the front of the vehicle; the tow eyes can break. DO NOT crawl under a vehicle suspended by tow eyes. Failure to follow these instructions can result in serious personal injury or death.
Page 401 392 MAINTENANCE AND LUBRICATION CAUTION If the vehicle becomes disabled, it is very important to tow it properly. Failure to do so can cause damage to the frame and body parts. Follow the instructions below to avoid damage. In the event that the vehicle cannot be reached to place the wrecker lift bar under the front axle, use the optional tow eyes.
Page 402 MAINTENANCE AND LUBRICATION 393 The tow eyes are held in place when mounted on the front of the vehicle by tractor pins. These pins are stored in the tow eye mounting holes when not being used. If the vehicle is equipped with the optional rock guard installed, insert the lock pin into the tow hook from the opposite side during installation.
Page 403 394 MAINTENANCE AND LUBRICATION If the vehicle is equipped with the optional rock/stone guard installed, the driver will have to insert the lock pin into the tow hook from the opposite side during installation. W9000751 When the vehicle is located properly, lift the front and locate the lift bar under the front axle and secure.
Page 404 Note: If your vehicle is equipped with a pintle hook system installed by Volvo Trucks North America, please note that the entire pintle hook system — including the frame and attachment to the frame —...
Page 405: Caging Spring Brake Chambers
396 MAINTENANCE AND LUBRICATION Caging Spring Brake Chambers DANGER DANGER Always start by chocking the wheels DO NOT attempt in any way to to prevent the vehicle from rolling. disassemble or tamper with the spring Failure to do so can result in unexpected brake chamber.
Page 406 MAINTENANCE AND LUBRICATION 397 W5001430...
Page 407 398 MAINTENANCE AND LUBRICATION Towing Procedure — AIRTEK® Suspension ®HENDRICKSON recommends that a vehicle equipped with a STEERTEK axle be towed using the following methods for ON HIGHWAY or ON ROADWAY applications. Methods listed are in order of preference. 1 Wheel lift method, the ideal towing procedure 2 Axle fork method 3 Towing vehicle from the rear method 4 Spring eye and hanger lift method...
Page 408 MAINTENANCE AND LUBRICATION 399 CAUTION DO NOT tow the vehicle from the axle. Towing the vehicle by the axle will cause scarring and resultant damage to the axle and void warranty. When lifting a vehicle with an under lift boom, care must be taken not to damage the engine’s oil pan.
Page 409 400 MAINTENANCE AND LUBRICATION W7001301 Towing Vehicle From Rear Method This method is preferred when the proper equipment is not available to perform the wheel lift method or the axle fork method, and is necessary for wreckers not equipped with an under lift system. Spring Eye and Hanger Lift Method This method is permitted for under lift equipped units.
Page 410 MAINTENANCE AND LUBRICATION 401 Off Roadway Towing Method WARNING When a truck is disabled and equipped with a STEERTEK axle, care must be taken to ensure there is no damage to the suspension when towing the vehicle. The use of a tow strap is necessary to tow a disabled truck into a repair facility.
Page 411 402 MAINTENANCE AND LUBRICATION W7001304 Chains are not acceptable for Off roadway towing.
Page 412: Engine Oil Level Check
DO NOT overfill! To add oil to the engine, remove cap from right-side oil fill and fill through the hole. See the Operator’s Manual Vehicle Maintenance for correct types of oil used in Volvo engines. W0056532 1 Oil Fill...
Page 413 404 MAINTENANCE AND LUBRICATION Clutch Fluid Check Check the fluid level in the clutch fluid reservoir. The fluid level should be between the level marks on the reservoir. If fluid needs to be added, use brake fluid, DOT 4. W4056530 1 Clutch Fluid Reservoir...
Page 414 MAINTENANCE AND LUBRICATION 405 Engine Maintenance Intervals Intervals Components Operation Water Seperator Filter Every oil change. Under certain Change conditions (for example, irregular fuel quality), the fuel/water seperator filters may require more frequent replacement. Coolant (Standard) Change 500,000 km (300,000 miles) or 24 months, whichever comes first Coolant (ELC) Change...
Page 415: Power Steering, General
406 MAINTENANCE AND LUBRICATION POWER STEERING, GENERAL The VN power steering consists of an integrated gear. There is also a power steering pump with fluid container. The pump, driven by the engine, provides hydraulic pressure to the power steering. If the engine is not working, the steering is only manual.
Page 416 MAINTENANCE AND LUBRICATION 407 Windshield Washer Reservoir Check level in the windshield washer reservoir. If washer fluid needs to be added, use a commercially reputable washer fluid that has good cleaning capability and does not freeze in cold weather. Windshield Washer Capacity Model Reserve Total Capacity...
Page 417: Cooling System
408 MAINTENANCE AND LUBRICATION COOLING SYSTEM Coolant Level Check CAUTION WARNING Add only premixed coolant made up of 50% clean water and 50% antifreeze. See the Operator’s Manual DO NOT remove the cap to the surge Vehicle Maintenance for more detailed tank while the engine and radiator are information.
Page 418 MAINTENANCE AND LUBRICATION 409 Air going into the cab passes a filter located on the right, front side of the cab. Remove the filter and check it every 19,200 km (12,000 miles). W8003189 The filter should not be cleaned and reused. Replace with a new filter as necessary. Change the filter more often if driving in dusty conditions.
Page 419: Headlights
410 MAINTENANCE AND LUBRICATION HEADLIGHTS Changing Headlight Bulb Note: To prevent short service life, DO NOT touch the glass surface of the replacement bulb. VNM Instructions The headlight bulb can be accessed from the rear of the headlight assembly. Raise the hood and remove the cover.
Page 420 Note: In some cases, the cover seal may stick to the housing, which makes removal difficult. Use special tool 85104355 to assist in removal. Contact your authorized Volvo dealer for the tool. With the cover removed, grasp the bulb assembly and turn counterclockwise to remove.
Page 421: Roof Extender
412 MAINTENANCE AND LUBRICATION ROOF EXTENDER The roof extender increases fuel economy. The extender is adjustable to five positions which are shown in the illustration and in the graphs. The vehicle is delivered with the extender or deflector lowered or down, which is the transport position, see A in illustration.
Page 422 Note: For 630 and 670 vehicle models, the frame height must be measured. See F in illustration. If F measures 266 mm (10-1/2 inches), subtract 17 mm (5/8-inch) from the value determined for H. W8003466 VN Roof Extender Measurements W8003472 VN 630/670 Roof Extender Adjustment Chart...
Page 423 414 MAINTENANCE AND LUBRICATION W8003473 VN 630/670 Roof Extender Adjustment Chart...
Page 424: Front Bumper/License Plate Mounting
MAINTENANCE AND LUBRICATION 415 FRONT BUMPER/LICENSE PLATE MOUNTING CAUTION DO NOT cover the opening in the front bumper with a license plate. Covering this hole will restrict airflow to the lower portion of the radiator. This can cause the engine to overheat, which can damage the engine.
Page 425 416 MAINTENANCE AND LUBRICATION Multiple License Plate Mounting Install multiple license plates as shown. W8003370...
Page 426 MAINTENANCE AND LUBRICATION 417 VORAD License Plate Mounting Install multiple license plates as shown. W8003371 Fig. Fig. 3 VN 1 Install license plates below this edge.
Page 427: Modifications To Vehicle
W7001277 Drilling is permitted in the frame web in accordance with a specified hole spacing pattern. Consult an authorized Volvo Truck dealer to obtain approved hole spacing dimensions or refer to the Frame Rail and Cross Member Service Manual.
Page 428 MAINTENANCE AND LUBRICATION 419 Frame rail and cross member nuts and bolts should be checked periodically and tightened to the specified torque if necessary. Frame Alterations Under no circumstances can the frame be cut and an extension piece added to increase the wheelbase.
Page 429: Wheels
General Due to the size, equipment needed and the procedures used to change wheels, this should be done through the Volvo Truck dealer. By having an expert technician perform this procedure, personal injury and property damage may be avoided. Note: When replacing the wheel equipment or tires, use the same size wheels or tires as originally manufactured.
Page 430 MAINTENANCE AND LUBRICATION 421 W7001270 Inflating Tires DANGER CAUTION Tires and wheels must be serviced Never bleed the air from hot tires. only by a qualified technician. DO Increased tire pressure measured in NOT attempt to perform this work a hot tire is normal. Lower than yourself.
Page 431 422 MAINTENANCE AND LUBRICATION W2002684 For specific information and warranty on rims and tires, contact the tire manufacturer’s distributor. Check tires for abnormal wear. Also, check the tread depth. Wheel Bearing Adjustment DANGER Failure to keep wheel bearings properly adjusted may result in accelerated tire wear, poor handling and, in extreme cases, wheel separation from the hub or from the spindle.
Page 432 For reliable operation and adequate service life, the wheel bearings must be properly adjusted and checked during the service period. Loose wheel bearings could cause premature tire wear and possibly affect vehicle handling. See your authorized Volvo Truck dealer for proper servicing.
Page 433: Battery
424 MAINTENANCE AND LUBRICATION BATTERY Battery Box Access for Jump Start WARNING DANGER Always wear eye protection when working around batteries to prevent When inspecting or cleaning batteries, the risk of injury due to contact with never smoke or expose batteries (or sulfuric acid or an explosion.
Page 434 MAINTENANCE AND LUBRICATION 425 The battery cover may also be a base for the cab steps. To remove the cover, unhook the two rubber latches and lift the cover up and out. This applies to the vehicle models without fairings. W3005334 There may be up to four batteries installed.
Page 435 426 MAINTENANCE AND LUBRICATION Battery Jump Starting and Charging WARNING DANGER Always wear eye protection when working around batteries to prevent DO NOT attempt to jump-start a vehicle the risk of injury due to contact with equipped with Delco Maintenance Free sulfuric acid or an explosion.
Page 436 MAINTENANCE AND LUBRICATION 427 W3005322 Connect the jumper cables in the following sequence: • Good battery positive, • Dead battery positive, • Dead battery negative, • Disconnect the cables in the reverse order. Avoid creating sparks by making all connections quickly and firmly. DO NOT permit vehicles to touch each other when jump starting.
Page 437 DO NOT work on the electrical system without the proper tools and training. Repair work to the electrical system must always be done by trained professionals. Your Volvo Truck dealer has the right tools and trained technicians.
Page 438 MAINTENANCE AND LUBRICATION 429 Battery, Low State of Charge If the batteries are discharged to the point where they do not have enough stored energy to start the engine, they should be recharged using a low charge current, not to exceed 14.5 to 15.0 volts.
Page 439 430 MAINTENANCE AND LUBRICATION CAUTION CAUTION If there are other ground cables DO NOT weld on the engine or engine connected to the battery (such as components. Welding on the engine engine ECU, transmission ECU, etc.), or components mounted on the engine disconnect those wires in the sequence can cause serious damage to the engine shown, then remove the main battery...
Page 440 MAINTENANCE AND LUBRICATION 431 The vehicle is equipped with systems that have their own electronics, including vehicle ECU (VECU), ABS, air bag (SRS), gauge cluster and some transmissions. Disconnect each ECU at its electrical connectors. W8003198 Disconnect the power harness (engine electronic control unit [EECU]) and vehicle interface harness at the battery.
Page 441 432 MAINTENANCE AND LUBRICATION Reposition or shield any parts that would be damaged by high temperatures during welding. W8003200 Complete the battery cable removal by removing the positive cable last. • Attach the welder ground cable as close to the weld area as possible (6 inches or less from the place being welded).
Page 442: Battery Voltage Protection System
MAINTENANCE AND LUBRICATION 433 Battery Voltage Protection System The vehicle is equipped with a battery protection system. The vehicle detects when the batteries are excessively discharged and will flash the indication light and sound an audible alarm. Should the battery voltage remain low for an additional 30 seconds the indication light and alarm rate increases (fast flash).
Page 443 434 MAINTENANCE AND LUBRICATION W3030711 Battery Protection Data Flow from LVD Note: Pressing the fan speed button over rides for approximately 10 minutes, enabling all loads. When the batteries are charged, either through the vehicle alternator or a connected battery charger, the monitor will automatically restore power to the disconnected circuits.
Page 444 MAINTENANCE AND LUBRICATION 435 W3030520 In situations where there is a short or overcurrent (over 100 Amps), the battery voltage protection system will initiate a different audible and visual alarm. The alarms are activated at a series of three 30 second intervals. If the short or overcurrent situation is not resolved by the final alarm series, the LVD shuts down in order to protect the vehicle lectrical system.
Page 445: Electrical
436 MAINTENANCE AND LUBRICATION ELECTRICAL General Safety Guidelines WARNING WARNING Before replacing a damaged fuse, turn off all functions for that circuit. Damage to the circuit can happen. Always Failure to repair a malfunction in the replace fuses and circuit breakers with electrical system can result in serious the same current/amperage rating.
Page 446 MAINTENANCE AND LUBRICATION 437 CAUTION CAUTION Attempting to work on electronic Welding on the vehicle can damage the components without proper equipment electrical system or components due can damage internal parts with static to the high voltage and current spikes electricity.
Page 447 DO NOT weld on the engine or engine be done by trained professionals. Your components. Welding on the engine authorized Volvo Truck dealer has the or components mounted on the engine right tools and trained technicians. can cause serious damage to the engine ECU.
Page 448 MAINTENANCE AND LUBRICATION 439 Electrical Center WARNING WARNING Failure to repair a malfunction in the Always replace fuses and electrical system may result in a vehicle circuit breakers with the same fire and personal injury. current/amperage rating. Using larger fuse or circuit breaker ratings may result in electrical circuit overheating and possibly fire.
Page 449 440 MAINTENANCE AND LUBRICATION The cover panels are fastened with screws. Most relays and fuses are accessible from under the top cover. Since the function of some fuses or relays may change for the vehicle application, refer to the list of functions that is attached beneath each panel. W3007220 Additional relays are located in the left-hand luggage compartment, attached to the sleeper harness.
Page 450 MAINTENANCE AND LUBRICATION 441 Additional fuses are located in the Sleeper Control Panel. W3007222 Sleeper Control Panel Fuses Fuses are standard. Reset breakers are available as an option for some circuits. If a fuse continues to blow or disconnect, the circuit has a malfunction and must be repaired.
Page 451 442 MAINTENANCE AND LUBRICATION CB Power Studs CB Studs are available either in the overhead storage compartment, or on the dash. W3005282 The red stud is the positive terminal and the black stud is the ground terminal. For a proper hook-up, use fork-type connectors on the wires or use "banana" plugs. CAUTION If stripped wire ends are used, make sure there are no wire strands that can...
Page 452 MAINTENANCE AND LUBRICATION 443 Before connecting any electrical accessory, make sure it is made for 12 V operation. This circuit is fused at 20 A maximum, or optional circuits are fused at higher amps (30 A). DO NOT overload this circuit. CAUTION DO NOT connect a device with a current rating in excess of the amount...
Page 453: Metric Conversions
444 METRIC CONVERSIONS METRIC CONVERSIONS Note: Use all tools on the fasteners they were made to be used on. Use metric tools on Sl metric units only. Never try to use metric tools on U.S. standard fasteners or U.S. standard tools on Sl metric units. CAUTION Potential external/internal thread mismatch condition(s) may occur with certain metric thread-inch thread fastener combinations, and with fastener combinations...
Page 454 METRIC CONVERSIONS 445 SI to U.S. Conversions 25.4 millimeters 1 inch 1.61 kilometers 1 mile .473 liter 1 pint (U.S. liquid) .946 liter 1 quart (U.S. liquid) .01639 liter 1 cubic inch 1.3558 Newton meters 1 pound-foot .746 kilowatt 1 horsepower 6.895 kilopascals 1 pound/square inch (1.8 x degrees Celsius) + 32...
Page 456 Last page Volvo Trucks North America P.O. Box 26115, Greensboro, NC 27402-6115 Volvo Trucks Canada, Ltd. 5600A Cancross Court, Missisauga, Ontario L5R 3E9 http://www.volvotrucks.com PV776-21232734 English 4.2010© Volvo Group North America, Inc., 2010...

This manual is also suitable for:

Vnl 780 Vnl 730 Vnl 670 Vnl 630 Vnl 430 Vnl 300 ... Show all

Volvo VN Operator's Manual

Quick Links

Related Manuals for Volvo VN

Summary of Contents for Volvo VN

This manual is also suitable for:

Table of Contents
