Holiday function

This function allows the user to deactivate both heating and hot
water production during a "set and activated" holiday period,
during which the antifreeze function can be active (if set).
To set the holiday function from the "Main screen":
– press the
Mode
– press the click encoder to confirm one of the Summer or
function mode
Winter
– turn the encoder to select "Holiday function"
Summer
Hot water
Heating
Holiday function
Esc
– press the encoder
(Holiday function) and go into the modifiable area
Start: 05 02 2014 15 : 00
Stop:
Enable holiday:
Hot water OFF - Heat. OFF (nofrost active)
Cancel
– turn the encoder to modify the "Data/value" which is
highlighted
– press the encoder to confirm the modification and
click
move to the next "Data/value"
Start: 05 02 2014 15 : 00
Stop:
Enable holiday:
Hot water OFF - Heat. OFF (nofrost active)
Cancel
– turn the encoder to modify the "Data/value" on the ba-
sis of the holiday start date
– press the encoder to confirm the modification and
click
move to the next "Data/value"
– continue in this way until all the necessary modifications have
been made.
10
button
Winter Off
MAN 40°C
MAN 20.0°C
OFF
Back
to confirm the "Holiday function"
click
HOLIDAY SCHEDULE
DAY MONTH YEAR HOUR
20 02 2014 15 : 00
NO
Confirm
HOLIDAY SCHEDULE
DAY MONTH YEAR HOUR
20 02 2014 15 : 00
NO
Confirm
: The user must work in a CIRCULAR manner, meaning AL-
NOTE
WAYS MOVING FORWARDS, even if a mistake is made.
– When all modifications have been made, press the
Confirm
– press the
1.3.3

Fault warnings

If a fault occurs, the screen "Anomaly in progress" (Fault in pro-
Fig. 22
gress) will appear in place of the "main screen". For the main
fault codes, a brief description and suggestions for the user are
displayed, based on the seriousness and the frequency with
which the fault reappears.
ANOMALY IN PROGRESS
5 - Technical problem
Contact customer service
Esc
Fig. 23
The fault may be transient (volatile) or it may cause an appliance
block .
To restore normal operating conditions:
– if the fault is transient, eliminate the cause of the fault
– if the fault causes a block, remove the cause of the fault and
then press the
If there is "no water in the system" or "low water pressure in the
there is a request to fill the system and then to press the
system"
button rather than the
Confirm
ANOMALY IN PROGRESS
2 - Low pressure
Fill the system as per boiler's manual instruction
Fig. 24
Esc
m
CAUTION
For a full list of faults, see "Malfunction codes and
possible solutions".
button to go back to "Holiday function"
button to go back to the "Main screen".
Esc
Zone Th 21 Sept 2014 10:30
Hot water 48°C eco
Winter automatic - set 20.0°C until 7.30
Menu Mode
ANOMALY IN PROGRESS
6 - No flame detection
Name: xxxxxxxx
Phone:yyyyyyyyy
Back Esc
button.
Reset
Reset
CONFIRM REQUEST
Confirm operation?
Charge Cancel
Fig. 25
Reset boiler
Reset
Fig. 26
button.
Confirm
Fig. 27
