Summary of Contents for Sime FORMAT 34I BF
- Page 1 Format 34I-34E BF...
-
Page 3: Table Of Contents
REPLACEMENT OF PARTS ..............21 SIME COMBINATION BOILERS Installer checklist Please remember to carry out the following checks after installation. -
Page 4: Technical Features And Dimensions
They are provided with direct fired ignition, and modulating temperature control, circulating pump and expansion tank. The Sime Format series wall hung boilers are fully automatic The central heating output has an adjustable output of 11.2 – power flued, wall mounted boilers for central heating and 34 kW. - Page 5 GENERAL DATA TABLE 3 - Heating data Heat Output Input (Adjustable) (Adjustable) FORMAT 34I BF 11.2 - 34 kW 45 - 145 MJ/hr FORMAT 34E BF 11.2 - 34 kW 45 - 145 MJ/hr TABLE 4 - General specifications FORMAT 34I - 34E BF...
- Page 6 HYDRAULIC CIRCUIT 1 Fan 2 Water-gas exchanger 3 Combustion chamber 4 Gas valve 5 D.H.W. exchanger 6 Divertor valve 7 NTC sensor 8 100°C safety thermostat 9 C.H. water filter 10 Air relief valve 11 Circulation pump 12 Expansion vessel 13 Safety valve 14 Drain plug 15 Water flow switch...
-
Page 7: General Requirements For Installation
GENERAL REQUIREMENTS FOR INSTALLATION 2. 1 INSTALLATION For installations where the heater is connected to larger systems, the additional volume will need to be taken into Models “34E BF” with a hermetically sealed combustion cham- account. ber and air supply circuit, may be installed outdoor. A temperature pressure relief valve may be needed. - Page 8 ELECTRICITY SUPPLY a) The available pump head is given in fig. 5. b) The appliance is equipped with an internal by-pass that The electrical connection is made to a standard 10 amp 3 operates with system heads (H) greater than 3 m. The pin outlet.
- Page 9 NOTE: If the pressure gauge indicates 2.65 bar or greater scribed limits ( Table 4 ). when the appliance is at maximum temperature with all If necessary, a pressure reducing valve should be fitted to radiators in circulation an extra expansion vessel is the mains supply before the D.H.W.
-
Page 10: Installing The Boiler
INSTALLING THE BOILER APPLIANCE PACKAGE: - boiler (assembled); - installation and servicing instructions; - users instructions; 1 Wall mounting bracket - wall mounting bracket; 2 Plastic wall plug (2 Off) 3 Woodscrew (2 Off) - fixing screws with wall plugs. 4 Washer (2 Off) 5 Adjustment screw (2 Off) 3. - Page 11 3.3. 1 Coaxial flue diaphragm the diaphragm only if the length of the coaxial flue. The boiler is normally supplied with ø 87.5 diaphragm. Insert Refer to fig. 8 for positioning. With outlet type C12, install diaphragm ø 87.5 only if the coaxial flue is less than 1.5 metres.
- Page 12 SAFETY VALVE CONNECTION any work. Warning: all components in the control panel are fed – The appliance safety valve is located towards the R.H.S. of with 240V. the boiler and the discharge pipe is supplied loose. – Remove the three screws (7) locking the control panel in place Remove the two selftapping screws and lower the control and pull the panel forward until it can be tilted downward.
- Page 13 Temperature and pressure gauge Time programmer housing Rotary switch Main PCB Earth faston Control panel protection Cover (TA) Connector (TA) Fixing screw ATTENTION: After having removed the three fixing screws, tilt the panel downward to gain access. Fig. 12...
-
Page 14: Commissioning And Testing
COMMISSIONING AND TESTING 4. 1 FILLING THE WATER SYSTEM the burner pressure. The heating input is factory set as stated in Table 4 . – Loosen the automatic air vent cap (10 fig. 2). – If the heating output is to be adjusted, proceed as follows: –... - Page 15 FINAL CHECKS – Give the “Users Instructions” to the householder. – Explain and demonstrate the lighting and shutdown proce- – Re-light and test for gas soundness. dures. – Re-fit the casing front panel and securing brackets. – Advise the householder on the efficient use of the system, –...
-
Page 16: Routine Servicing Instructions
– Pull the bottom of the case forward, to disengange the 5. 1 . 1 Model “FORMAT 34I BF” (fig. 15) lower location studs, and then lift straight up, to disen- gange the upper location studs, and withdraw the casing –... - Page 17 – Remove the three screws securing the fan. – Tilt the fan forwards and remove in a downwards direction. – Inspect the fan assembly and clean if necessary. HEAT EXCHANGER Inspect the heat exchanger, and clean if necessary as 8 SEALED CHAMBER SCREWS showed in fig.
- Page 18 described in section 8. When any service or replacement of electrical components which has required the breaking and re-making of electrical connections has taken place, the following tests must be repeated: – earth continuity; – short circuit; – polarity; – resistance to earth. CLEANING THE C.H.
-
Page 19: Fault Finding
FAULT FINDING 6. 1 EARTH CONTINUITY CHECK trace the faulty component. Appliances must be electrically disconnected, meter set on Ω IMPORTANT: (ohm) x 1 scale and adjust zero if necessary. Tests leads from These series of checks are the first electrical checks to be any appliance earth point (e.g. - Page 20 C.H. MODE - FAULT FINDING Start from cold Rotary switch set to WINTER position. Room thermostat (if fitted) calling for heat and all D.H.W. taps off. C.H. thermostat set to maximum position. Clock in the on position. After 20 seconds Flue fault.
- Page 21 D.H.W. MODE - FAULT FINDING Start from cold - rotary switch set to SUMMER position, D.H.W. thermostat set to maximum, and all D.H.W. taps OFF. Is there power Make Does Does Is there a spark at the external power the pump the fan at the ignition socket?
-
Page 22: Wiring & Functional Diagrams
(see fig. 21). Connect the unit as shown in the wiring diagram (fig. 20). KIT FOR LOW TEMPERATURE SYSTEM (optional) This kit (SIME cod. 8089830) consists of the following compo- Fig. 21 nents: thermostat at 50°C, connector and 2 fixing screws. -
Page 23: Replacement Of Parts
REPLACEMENT OF PARTS Before commencing any service operation, ISOLATE the MAIN BURNER mains electrical supply, and TURN OFF the gas supply at the main service cock. It is the law that any service work must be – Remove the main burner by following section 5. 1 . carried out by registered personnel. - Page 24 mum pressure in Table 4 . OVERHEAT THERMOSTAT Turn the nut clockwise to increase or anti-clockwise to decrease the burner pressure. The overheat thermostat is situated on the flow pipe, below – Turn the main selector switch on and off a few times (with the sealed chamber (11 fig.
- Page 25 – Drain the appliance through the drain point (14 fig. 2). – Replace the expansion vessel and re-assemble in reverse – Drain the D.H.W. circuit by opening any D.H.W. tap below order. Re-pressurise and re-commission the system as the level of the boiler. described in section 4.
- Page 26 User instructions CONTENTS 1. 1 INTRODUCTION ................. 25 OPERATING INSTRUCTIONS MINIMUM CLEARANCES ROUTINE SERVICING .
-
Page 27: Introduction
1. 1 INTRODUCTION arises. The Sime “FORMAT 34E - 34I BF” family is a fully automatic, wall mounted, room sealed, fan assisted range of combina- 1.3.2 To turn the appliance off (see fig. 24) tion boilers. -
Page 28: Routine Servicing
ROUTINE SERVICING MUST NOT be blocked and a periodic check must be made to ensure that the vents are free from obstructions. To ensure continued efficient operation of the appliance, it is recommended that it is checked and serviced as necessary at regular intervals. -
Page 29: Time Clocks (Optional)
TIME CLOCK OPTIONAL (fig. 26) Setting the time MECHANICAL 24 hr VERSION The time of day can be set by grasping the outer edge of the black dial and turning it in a clockwise direction until the cor- rect time is in line with the white pointer. Slide blue tappets IN for OFF period Setting the “switching time”... - Page 30 This Warranty is granted to you by Hunt Heating A.C.N. 000 ler, the boiler is warranted by Hunt Heating against defects 013 927, in respect of your acquisition of a Sime Central caused by the manufacturers faulty materials and/or work- Heating Boiler within the Commonwealth of Australia.
- Page 31 All descriptions and illustrations provided in this manual have been carefully prepared but we reserve the right to make changes and improvements in our products that may affect the accuracy of the information contained in this manual.
- Page 32 HUNT HEATING HYDRONIC SYSTEMS (Australia) PTY. Ltd. 11 Fiveways Boulevard, Keysborough, Victoria 3173 Telephone 1300 00 1800 - Facsimile 9798 5133 www.huntheat.com.au...
