BUTTON (A)
(used mainly by professionally qualified technicians and NOT
by the user)
This allows users to view the "menu" select screen (e.g. Menu
) and then to operate according to what is
"GENERAL SETTINGS"
written above the button on the display (e.g.
and return to the main screen.
GENERAL SETTINGS
INFORMATION
TECHNICAL
Esc
MULTIFUNCTION ENCODER
If turned, allows the user to scroll through and select the
or the "Function mode" , or to change the values in
"Menu/rows"
the selected field.
In "Summer" mode, the DHW temperature can be adjusted.
In "Winter" mode, the DHW can be adjusted in relation to the
heating and the "Holiday function".
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
Esc Back
If pressed, confirms the selection and takes the user to
click
the submenus (e.g. "LANGUAGE" or "Hot water" ) or confirms the
modified value or entry.
MENU
GENERAL SETTINGS [...] Language
INFORMATION [...] Date and time
Visualization
TECHNICAL [...]
Factory settings
Esc Back Esc
BUTTON (B)
This allows users to view the "Function mode" screen (e.g. "Win-
ter") and then to operate according to what is written above the
button on the display (e.g.
main screen).
Summer
Hot water
Heating
Holiday function
Esc
to exit
Esc
MENU
[...]
[...]
[...]
Back
Fig. 3
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
Esc Back
Fig. 4
GENERAL SETTINGS
ENG
Winter
[...] Hot water MAN 40°C
[...] Heating MAN 20.0°C
[...] Holiday function OFF
Back Esc Back
Fig. 5
to exit and return to the
Esc
Winter Off
MAN 40°C
MAN 20.0°C
OFF
Back
Fig. 6
1.2

Start-up

1.2.1

Preliminary checks

a
WARNING
– Should it be necessary to access the areas in the
bottom part of the appliance, make sure that the
system components and pipes are not hot (risk of
burning).
– Before replenishing the heating system, put on pro-
tective gloves.
Commissioning of the Murelle Revolution 30 boiler must be car-
ried out by professionally qualified technicians, after which the
boiler can operate automatically. It may, however, be necessary
for the user to start the appliance autonomously without involv-
ing a technician: for example, after a holiday.
In this case, certain checks and the following operations must
be carried out:
– check that the gas isolation and water system valves are open.
1.2.2

Ignition

After having carried out the preliminary checks, perform the
following to start the boiler:
– set the main system switch to "ON"
– after a few seconds, the "Main screen" is shown
ON
– Press the button to view the "Function mode"
Mode
(MODE) selection screen. Turn the
the preferred mode (e.g. "Winter")
– press the click encoder to confirm "Winter"
– press the button to go back to the "Main screen"
Esc
Check the "System pressure" by doing as follows:
– press the button to view the "Menu" selection
Menu
screen
– turn the encoder to select the menu "INFORMATION"
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
Esc Back
Zone Thu 18 Set 2014 10:30
Off
1.1 bar
Menu Mode
Fig. 7
encode to select
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
Esc Back
Fig. 8
