– press the encoder to confirm the highlighted "Mode"
click
and go to the "rows"
– Turn the encoder to "Boiler"
INFORMATION
Zone heating [...]
Boiler [...]
Heat pump [...]
Hot water [...]
Solar thermal [...]
ˆ
Esc Back
– Press the click encoder to confirm the selection and go to
the screen showing the "System pressure"
Boiler
Return temperature – –
Power output 0
%
System pressure 0.9bar
Exhaust temp. 26
Esc Back
– check that the system pressure as shown on the pressure
gauge when the system is cold , is between 1 and 1.2 bar .
Where the value is different from 1-1.2 bar (the correct value),
open the filling valve again until this value is reached and then
shut it off again
– press the button to go back to the "Main screen"
Esc
m
CAUTION
To view the "System pressure", the row does not need
to be selected by turning the encoder
– open one or more of the hot water valves and check that the
appliance starts up
Summer
Hot water
Heating
Holiday function
Esc
– allow the appliance to operate until hot water is produced and
shut off the valves opened previously.
8
INFORMATION
Zone heating [...]
Boiler [...]
Heat pump [...]
Hot water [...]
Solar thermal [...]
ˆ
Esc Back
Boiler
Return temperature – –
°C
Power output 0
%
System pressure 0.9bar
Exhaust temp. 26
°C °C
Esc Back
Off
Winter
MAN 40°C
MAN 20.0°C
OFF
Back
1.3

Settings using the MODE button

From the "Main screen":
Fig. 9
– Press the
lection screen. Turn the
"Winter")
°C
Fig. 10
– press the
and go to the "rows"
.
– turn the
– press the
"Rows"
Fig. 11
– press the
and access the modifiable area
Zone Thu 18 Set 2014
Off
Menu Mode
button to view the "Function mode" se-
Mode
encoder to select a mode (e.g.
Summer Winter Off
Hot water MAN 40°C
Heating MAN 20.0°C
Holiday function OFF
Esc Back
click encoder to confirm the highlighted "Mode"
Winter
Hot water MAN 40°C
Heating MAN 20.0°C
Holiday function OFF
Esc Back
encoder to select "Heating" (Heating)
encoder to confirm "Heating" and access the
click
Heating
Function Mode MAN
Set AUTO comfort 20.0°C
Set AUTO reduced 18.0°C
Set MAN 20.0°C
Program. Time [...]
Esc Back
click encoder to confirm the highlighted "Row"
10:30
Fig. 12
Fig. 13
Fig. 14
