Holiday function

This function allows the user to deactivate both heating and hot
water production during a "set and activated" holiday period,
during which the antifreeze function can be active (if set).
To set the holiday function from the "Main screen" :
– press the
Mode
– press the encoder to confirm one of the Summer or
click
function mode
Winter
– turn the encoder to select "Holiday function"
Summer
Hot water
Heating
Holiday function
Esc
– press the click encoder to confirm the "Holiday function"
and go into the modifiable area
Start: 05 02 2014 15 : 00
Stop:
Enable holiday:
Hot water OFF - Heat. OFF (nofrost active)
Cancel
– turn the encoder to modify the "Data/value" which is
highlighted
– press the encoder to confirm the modification and
click
move to the next "Data/value"
Start: 05 02 2014 15 : 00
Stop:
Enable holiday:
Hot water OFF - Heat. OFF (nofrost active)
Cancel
– turn the encoder to modify the "Data/value" on the ba-
sis of the holiday start date
– press the click encoder to confirm the modification and
move to the next "Data/value"
– continue in this way until all the necessary modifications
have been made..
14
button
Winter Off
MAN 40°C
MAN 20.0°C
OFF
Back
HOLIDAY SCHEDULE
DAY MONTH YEAR HOUR
20 02 2014 15 : 00
NO
Confirm
HOLIDAY SCHEDULE
DAY MONTH YEAR HOUR
20 02 2014 15 : 00
NO
Confirm
: The user must work in a CIRCULAR manner, meaning
NOTE
ALWAYS MOVING FORWARDS, even if a mistake is made.
– When all modifications have been made, press the
Confirm
– press the
1.3.3

Fault warnings

If a fault occurs, the screen "Anomaly in progress" will appear
Fig. 22
in place of the "Main screen" . For the main fault codes, a brief
description and suggestions for the user are displayed, based
on the seriousness and the frequency with which the fault re-
appears.
ANOMALY IN PROGRESS
5 - Technical problem
Contact customer service
Esc
Fig. 23
The fault may be transient (volatile) or it may cause an appli-
ance block .
To restore normal operating conditions:
– if the fault is transient, eliminate the cause of the fault
– if the fault causes a block, remove the cause of the fault and
then press the
If there is "no water in the system" or "low water pressure in the
there is a request to fill the system and then to press
system"
the
Confirm
ANOMALY IN PROGRESS
2 - Low pressure
Fill the system as per boiler's manual instruction
Esc
Fig. 24
m
CAUTION
For a full list of faults, see "Malfunction codes and
possible solutions".
button to go back to "Holiday function"
button to go back to the "Main screen" .
Esc
Zone Th 21 Sept 2014
Hot water 48°C eco
Winter automatic - set 20.0°C until 7.30
Menu Mode
ANOMALY IN PROGRESS
6 - No flame detection
Name: xxxxxxxx
Phone:yyyyyyyyy
Back Esc
button.
Reset
button rather than the
Reset
CONFIRM REQUEST
Confirm operation?
Charge Cancel
10:30
Fig. 25
Reset boiler
Reset
Fig. 26
button.
Confirm
Fig. 27
