Options

Target adaptation

The Emulation Adapter adaptation to a specific target microcontroller pincount and package is
done via a Conversion board and a Solder part. Sometimes also an optional Extender and Socket
cover are available. Conversion boards connect between the Emulation Adapter and the matching
Solder part, which is being soldered on the embedded target side.
Package
MCU
(Pitch)
QFP80 (0.4
TC332
mm)
QFP100
TC323, TC333
(0.4 mm)
TC324, TC334
QFP144
(0.4 mm)
TC364
TC364
QFP144
(0.5 mm)
TC364
TC365
TC365
QFP176
TC375
(0.5 mm)
TC375
TC375
TC327, TC337,
BGA292
TC367, TC377
The embedded system can behave differently when running the user application on the Emulation
Adapter and when running it on a final mass production device without the hardware debugger
attached. An optional Socket cover makes testing this possible. The Emulation Adapter connects to
the target through the Solder part being soldered on the Target instead of the original
microcontroller. With the use of the Socket cover, the same Target setup can be tested with a mass
production device. Disconnect the Emulation Adapter and put a mass production device into the
Solder part (IANQPACK...) and cover it with the Socket cover (IAHQPACK...), which must be tightened
with the provided screws.
Note that Socket cover is not available with all target adaptations.
QFP Fixed Adaptation
This adaptation is delivered with a slot screw, which can be optionally used to achieve a more solid
and stable fixing of the Conversion board and the Solder part.
Conversion board
Type
(Ordering code)
IEA-TC377TE- Flex
TC332W Wire
IEA-TC377TE- Flex
BTQ100W Wire
IEA-TC377TE- Flex
TC334W Wire
IEA-TC377TE- Flex
TC364W4 Wire
IEA-TC377TE- Flex
TC364W5 Wire
IEA-TC377TE-
Fixed
TC364F5
IEA-TC377TE-
Fixed
TC365F5
IEA-TC377TE- Flex
TC365W5 Wire
EA-TC377TE- Flex
TC375W5 Wire
IEA-TC377TE-
Fixed
TC375F5
IEA-TC377TE- Flex
TC375FP5 PCB
IEA-TC377TE-
BGA
TC377
Connecting part Extender
(Ordering code) (Ordering code)
IAYQPACK80SE
IAYQPACK100SE
IAYQPACK144SE
IAYQPACK144SE
/
/
IA292LFBGA-
EXTENDER
Solder part Socket cover
(Ordering code) (Ordering code)
IANQPACK80SE IAHQPACK80SE
IANQPACK100SE IAHQPACK100SE
IANQPACK144SE IAHQPACK144SE
IA144TQ-SOLDER
IA176TQ-SOLDER
IA292LFBGA-
SOLDER
/
