Options
Target adaptation
The Emulation Adapter adaptation to a specific target microcontroller pincount and package is
done via a Solder part. Sometimes also an optional Extender is available. The optional Extender
connects between the Emulation Adapter and the matching Solder part, which is being soldered on
the embedded target side.
The available Solder part and the Extender are listed in the table below.
Package (Pitch)
BGA292
BGA Adaptation
Extender (optional)
MCU
Type
TC397Xx, TC387QP,
BGA
TC3E7Qx
Extender (optional)
(Ordering code)
IA292LFBGA-EXTENDER
Solder part
Solder part
(Ordering code)
IA292LFBGA-SOLDER
