Slot screw
The Slot screw (30mm) is used to fix the Conversion board to the Solder part. The setup becomes
mechanically more robust.Screw the Conversion board to the Solder part first, before the Emulation
Adapter is attached on top and watch out not to break out the Solder part, e.g., if you accidentally
hit the Emulation Adapter from the side.
