INFINEON TC234LF EMULATION ADAPTER
HARDWARE USER MANUAL
V2.2, October 2024
www.tasking.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the INFINEON TC234LF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TASKING INFINEON TC234LF

  • Page 1 INFINEON TC234LF EMULATION ADAPTER HARDWARE USER MANUAL V2.2, October 2024 www.tasking.com...
  • Page 2 Use included power cord and power supply The enclosed power supply has been approved for use by TASKING. Please contact TASKING if you need to consider an alternative power.
  • Page 3: Table Of Contents

    Configuration ......................9 Connectors ......................14 Power supply package ..................15 Standalone operation ................... 16 Measurement board ..................... 17 Mechanical information .................. 18 NQ Pack Assembly ..................... 20 HQ Pack Assembly ..................... 21 Schematics ..................... 22 Accessories ....................23 www.tasking.com...
  • Page 4: Introduction

    Introduction Infineon TC234LF Emulation Adapter primary use case is providing the trace capability for the 100-pin: · TC233 · TC223 devices featuring no trace functionality. The Emulation Adapter might differ in some peripherals from the target device; therefore, the device datasheet should be checked.
  • Page 5: Package Content

    Package content Infineon TC234LF Emulation Adapter is delivered with all components required for Standalone operation. Adaptation package for the Target board adaptation must be ordered separately. Power supply package Infineon TC234LF Emulation Adapter Power converter Power adapter Ordering code: Ordering code:...
  • Page 6: Adaptation Packages Content

    Pack. For assembly instructions please refer to HQ Pack Assembly. Flex Adaptation with Wire adapter This part provides a flexible connection of the Emulation Adapter to the Solder part as an alternative to the fixed connection. Socket cover Conversion board Connecting part Solder part (optional) www.tasking.com...
  • Page 7: Operation

    Operation Emulation Adapter offers the following setup: · Flex Adaptation (with Wire adapter) Top side of the Emulation Adapter Bottom side of the Emulation Adapter www.tasking.com...
  • Page 8: Adaptation Setups

    Adaptation setups Flex Adaptation www.tasking.com...
  • Page 9: Configuration

    Q1 socket and replace C1 (default 10 pF populated) and C2 (default 10 pF populated) accordingly. Crystal socket Q1 is by default not populated (NP). The crystal circuit is located in the corner of the emulation adapter. www.tasking.com...
  • Page 10 Note that C1 and C2 values are valid for 20MHz crystal only. If different crystal is used, the default 10 pF capacitors must be replaced with a proper value. www.tasking.com...
  • Page 11 Jumper J9 connects VAGND to VSSM and jumper J10 connects VSSM to the emulation adapter GND potential. · VAGND (pin 41) – Negative Analog Reference Voltage 0 · VDDM (pin 44) – ADC Power Supply · VSSM (pin 43) Analog Ground for VDDM www.tasking.com...
  • Page 12 (floating) while the TC234LF PORST signal is low. This ensures embedded voltage regulators EVR33 and EVR13 are active by default. As soon as the PORST line is released from the low state, the HWCFG[0:2, 6] pins get connected to the target via the emulation adapter logic. www.tasking.com...
  • Page 13 In principle, pins 3-4, 5-6, 7-8, must be bridged only but for the convenience and ease of use, all jumpers are set except for pins 25-26. Pin 26 is the polarizer key preventing incorrect connection of the IEA-PS power supply, when connected. www.tasking.com...
  • Page 14: Connectors

    Signal Direction is described from the BlueBox perspective. Be aware that debug and trace signals from the Emulation Adapter superset device are not connected to the target board. They are exposed only to the connectors on the Emulation adapter. www.tasking.com...
  • Page 15: Power Supply Package

    Be careful not to supply 5 V to the microcontroller power supply pin, which has declared a maximum voltage 3.3 V! Refer to the microcontroller documentation for detailed information on power supply. P3 connector on the Power Supply board External power supply requirements: Min Voltage Max Voltage Min Power 12 V www.tasking.com...
  • Page 16: Standalone Operation

    PS Emulation Adapter Power supply is configured properly for this particular Emulation Adapter. If a different power source is to be used, all jumpers must be removed and power source must be applied to CVDDP3/3v3 (pin 2), CVDDM (pin 4), and CVAREF (pin 6) signals. www.tasking.com...
  • Page 17: Measurement Board

    CPU signals are nicely marked) that matches your order. The black panel is placed over the Measurement board. Layout board example for the Top view of the Measurement Measurement board board Not available in every Emulation Adapter or every MCU pin count. www.tasking.com...
  • Page 18: Mechanical Information

    Mechanical information Solder part solder upper view Side view of the Solder part Solder part solder bottom view Top view of the Conversion board NQPACK Solder pad view Top view of the Emulation Adapter www.tasking.com...
  • Page 19 14.1 0.18 13.20 0.18 You must be familiar with the SMT (Surface Mount Technology) soldering to solder the NQPACK to the PCB. On request, iSYSTEM provides this service too. Emulation Adapter Unit (mm) Ordering code IEA-TC234LF-ST 32.6 47.5 IEA-TC234LFBTQ100W www.tasking.com...
  • Page 20: Nq Pack Assembly

    3. Connect the Emulation Adapter after checking for a match with the position of pin 1 for the YQPACK, and connect the Debug Adapter / Active Probe from the BlueBox to the connector on the Emulation Adapter. www.tasking.com...
  • Page 21: Hq Pack Assembly

    Target. 2. Install the Microcontroller after checking for a match with the position of pin 1 on the NQPACK. 3. Mount the HQPACK Socket Cover after checking for a match with the position of pin 1 on the Microcontroller. www.tasking.com...
  • Page 22: Schematics

    Connectors being used on the emulation adapter side are TE connectivity female connectors, part number: 0-0104652-4 (40-pin connector). The target must feature male matching connectors. Contact TASKING for technical details on the location of the three connectors.
  • Page 23: Accessories

    ADIO IC57041 Debug Adapters and Active Probes Description Ordering code Infineon DAP/DAPE II Active Probe IC71163-1 / IC57163-1 Infineon DAP 10-pin (1.27mm) IC70163 10-pin 1.27 mm Infineon DAP2 Wide Debug Adapter IC50163-2 More information about our products via sales@tasking.com. www.tasking.com...
  • Page 24 Visit our website for: · Support - support.tasking.com · Getting started - isystem.com/start · Knowledge Base - kb.tasking.com www.tasking.com www.tasking.com...
