Options
Target adaptation
The Emulation Adapter adaptation to a specific target microcontroller pincount and package
is done via a Solder part. Sometimes also an optional Extender is available. The optional
Extender connects between the Emulation Adapter and the matching Solder part, which is
being soldered on the embedded target side.
The available Solder part and the Extender are listed in the table below.
Extender (optional)
Solder part
Package (Pitch)
MCU
Type
(Ordering code)
(Ordering code)
TC327, TC337,
BGA292
BGA
IA292LFBGA-EXTENDER
IA292LFBGA-SOLDER
TC367, TC377
BGA Adaptation
Refer to the chapter
Assembly
for more information about the assembly procedure.
Extender (optional)
Solder part
