Parts List - Analog Devices EVAL-LTM4702-AZ Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C10
3 2 C11, C12
4 4 C13, C14, C15, C16
5 2 C6, C17
6 3 C18, C23, C24
7 1 C19
8 1 C2
9 2 C21, C22
10 3 C3, C4, C5
11 1 C9
12 1 FB1
13 1 L1
14 1 R1
15 1 R10
16 1 R12
17 1 R13
18 2 R2, R5
19 1 R3
20 1 R4
21 1 R7
22 1 U1
Additional Demo Board Circuit Components
18 0 C7, C8, C20, C25
19 0 R6, R8, R9, R11
20 0 L2
Hardware: For Demo Board Only
24 2 J1, J2
26 2 JP1, JP2
27 4
28 2
29 1 PCBs
PART DESCRIPTION
CAP ., ALUM POLY HYBRID, 100μF, 25V, 20%,
6.3mm × 7.7mm, AEC-Q200
CAP . CER, 1μF, 25V, 10%, X7R, 0603, AEC-Q200
CAP . CER, 22μF, 25V, 10%, X7R, 1210
CAP . CER, 10μF, 6.3V, 20%, X7S, 0603
CAP . CER, 100μF, 10V, 20%, X5R, 1206, LOW ESR
CAP . CER, 0.1μF, 25V, 10%, X7R, 0603
CAP . CER, 2200pF, 16V, 10%, X7R, 0603
CAP . CER, 22μF, 25V, 20%, X5R, 0805, AEC-Q200
CAP FEEDTHRU, 4.7μF, 10V, 20%, 0805, 3-TERMINAL
CAP . CER, 2.2μF, 25V, 10%, X5R, 0603
CAP . CER, 1μF, 10V, 10%, X7R, 0805
IND., CHIP FERRITE BEAD, 0.015Ω, DCR, 5.1A
IND., POWER SHIELDED WIREWOUND, 0.0073Ω, DCR, 9.5A
RES., SMD, 49.9k, 1%, 1/10W, 0603, AEC-Q200
RES., SMD, 0Ω, 1%, 1/4W, 1206
RES., 1.2k, 1%, 1/10W, 0603, AEC-Q200
RES., SMD, 0Ω, JUMPER, 1/10W, 0603, AEC-Q200,
PRECISION POWER
RES., SMD, 100k, 1%, 1/10W, 0603, AEC-Q200
RES., SMD, 10k 1%, 1/10W, 0603, AEC-Q200
RES., SMD, 1Ω, 1%, 1/10W, 0603
RES., 137k, 1%, 1/10W, 0603, AEC-Q200
IC-ADI, 18V , 8A, Silent Switcher, μModule REGULATOR
IN
OPTIONAL CAPACITOR
OPTIONAL RESISTOR
OPTIONAL INDUCTOR
CONN., PCB, SMA, FEMALE JACK, RCP , 50Ω
CONN., HDR, MALE, 2 × 3, 2mm, VERT, ST, THT
STANDOFF , BRD, SPT, SNAP-FIT, 9.53mm LENGTH,
EVAL BOARD MTG
CONN., SHUNT, FEMALE, 2-POS, 2mm
FAB PRINTED CIRCUIT BOARD
DEMO MANUAL
EVAL-LTM4702-AZ
MANUFACTURER/PART NUMBER
PANASONIC, EEHZC1E101XP
TDK, CGA3E1X7R1E105K080AC
MURATA, GRM32ER71E226KE15L
TDK, C1608X7S0J106M080AC
TDK, C3216X5R1A107M160AC
SAMSUNG, CL10B104KA8NNNC
VISHAY, VJ0603Y222KXJCW1BC
MURATA, GRT21BR61E226ME13L
MURATA, NFM21PC475B1A3D
MURATAGRM188R61E225KA12D
AVX, 0805ZC105KAT2A
WURTH ELEKTRONIK, 74279228600
WURTH ELEKTRONIK, 744373240022
PANASONIC, ERJ-3EKF4992V
VISHAYWSL, 120600000ZEA9
VISHAY, CRCW06031K20FKEA
VISHAY, CRCW06030000Z0EA
PANASONIC, ERJ-3EKF1003V
PANASONIC, ERJ-3EKF1002V
YAGEO, RC0603FR-071RL
VISHAY, CRCW0603137KFKEA
ANALOG DEVICES, LTM4702EY#PBF
MOLEX, 732511350
WURTH ELEKTRONIK, 62000621121
KEYSTONE, 8832
KEYSTONE, 8831
WURTH ELEKTRONIK, 702931000
